- Page 1 Installation Manual Swing Gate Operator SCISSOR ARM ROTARY ARM Automatic Entrence Solution Provider DESIGN MANUFACTURE SALES SERVICE 24 x 7 Service Support +91 755 00 22 007 | +91 733 88 52 901 – 905...
-
Page 2: Important Safety Message
IMPORTANT SAFETY MESSAGE Thank you for your purchase of our automatic gate equipment. Your automatic gate operator has been designed and manufactured to comply with stringent safety requirements for compliance to the Australian standard. It is essential that you make yourself familiar with and at least once a week or more regularly check the safety features of the gate to ensure safety of the users. If you find that the gate operator is unsafe then it must be rendered to a safe condition by either leaving it fully open or fully shut. Always engage Auto Ingress authorized service technician for periodic inspections and maintenance of this equipment. We recommend services every quarter of the year to ensure safety of users and longevity of operator life cycle. -
Page 3: Other Precautions
Caution • CAUTION! For personal safety, it is important to follow all the instructions carefully. Incorrect installation or misuse of the product may cause serious harm to people. • Don’t use the gate in a place subject to dampness, vibration or corrosive gas, otherwise it may cause accidents such as fire , electric shocks or fall. • Make sure that suitable space be available after the gate is opened, otherwise user’s fingers may be squeezed by the gate leaf. • Don ‘t cut off power when the gate is in operation , otherwise it may result in accident to passers-by. • Please stick the adhesive sticker on the gate leaf firmly . If not, it may cause injury to the passer-by who didn’t pay attention to the gate leaf. • D on’t connect an external electric device to the micro controler as it may cause fire . • Keep the instructions in a safe place for future reference. • T his product was designed and manufactured strictly for the use indicated in this document. Any other usage not expressly indicated in this Document, may damage the product and/or be a source of danger. - Page 4 Scissor Arm Installation : Motor : Mounting bracket : Straight arm : Bending arm : Front bracket : Release Dimensions Installation • Before using the machine, check power supply, grounding, voltage, etc. • C heck whether it is connected according to the demand of wiring diagram. • T he gate should be pulled easily and smoothly manually when the operator is fitted and the gears are released. • The product must be installed by Auto Ingress authorised technician. Australian Technology...
- Page 5 Standard installation layout : Motor : Control box : Transmitters : Photocell (Optional) : Alarm lamp (Optional) Installation dimensions Australian Technology...
- Page 6 Fix the mounting bracket Fix the straight arm : Motor : Straight arm : M10 x 20 : φ 10 Gasket Fix the Motor’s : Motor : M8 x 160 : Mounting bracket : M8 nut Australian Technology...
- Page 7 Connect the bending arm : Motor : Straight arm : M8 nut : φ 8 Gasket : Bending arm : M8 x 45 Connect the Front Brackt : Bending arm : M8 nut : φ 8 Gasket : Front Bracketr ...
- Page 8 How to release : Gate : Motor : Relese : Bending arm Fix the Front Brackt Australian Technology...
- Page 9 Limit switch adjustment Attention : lf the operator move in an opposition way, you should change the connection as follow: T he billowing is a Right motor’s limit switch adjustment, Before adjusting, release the gears, and open the gate manually. For left motor, all direction, are contrary. Step I, C lose thc door completely, and confirm which one is t he Close Limit Block according to the situation, then loosen the screw adjustor on Close Limit Block. Australian Technology...
-
Page 10: Limit Switch Adjustment
Limit switch adjustment Slep 2, O pen the door completeIy, and confirm which one is the open Limit Block according to the situation, then loosen the screw adjustor on Open Limit Block. Slep 3, C ouple the gears, turn on the power adjust more accurately by “Fine adjustor”, then tighten the “Screw adjustor”... - Page 11 Control Unit Wiring Diagram (I) “LIGHT” for a Flash lamp,24VDC. (2) “MOTOR 1 “, “MOTOR 2” for 2 motors 24VDC. (3) “LIMIT 1”, “LIMIT 2” for the magnetic limit switch on motor 1, motor 2. (It is useful only for the motors with magnetic limit switch.) (4) “PHOTOCELL” for infrared protect device. (5) “ BUTTON”for wall switch. “PUSH 1 “control double-leaf gate, step-by-step “PUSH 2”control single leaf gate which must be the priority of opening one step-by-step. (6) “ E_ LOCK” for electronic lock, It can be convected with electronic lock which power is 24VDC. (7) C onnection of motor for single-leaf : If the gate is only 1 leaf, the motor must be connected with “Motor1”, and the “dip 2” on “S5” must be OFF. (8) C onnection of motor for double-leaf : Ifthe gate is two leaves, first, it must be confirmed which one leaf is the priority openning one. Then, the priority openning leaf must be connected with “MOTOR1”, the otherone is connected with “MOTOR2”. And the “dip2” on “S5” must be “ON”. Australian Technology...
- Page 12 (OPEN FIRST) (OPEN FIRST) Australian Technology...
- Page 13 Rotary Arm Instalition Dimensions Installation • Before using the machine, check power supply, grounding, voltage, etc. • C heck whether it is connected according to the demand of wiring diagram. • T he gate should be pulled easily and smoothly manually when the operator is fitted and the gears are released. • The product must be installed by Auto Ingress authorised technician. Australian Technology...
-
Page 14: Standard Installation Layout
Standard installation layout Australian Technology... -
Page 15: Installation Dimensions
Installation dimensions Installation Australian Technology... - Page 16 Australian Technology...
- Page 17 Australian Technology...
- Page 18 Control Unit Wiring Diagram (I) “LIGHT” for a Flash lamp,24VDC. (2) “MOTOR 1 “, “MOTOR 2” for 2 motors 24VDC. (3) “LIMIT 1”, “LIMIT 2” for the magnetic limit switch on motor 1, motor 2. (It is useful only for the motors with magnetic limit switch.) (4) “PHOTOCELL” for infrared protect device. (5) “ BUTTON”for wall switch. “PUSH 1 “control double-leaf gate with “step-by-step” “PUSH 2”controls single leaf gate which must be the priority of opening one with “step-by-step”. (6) “ E_ LOCK” for electric lock, It can be connected with electric lock which power is 24VAC or 24VDC. (7) C onnection of motor for single-leaf : If the gate is 1 leaf, first, it must be connected with “Motor1”, and the “dip 2” on “S4” must be OFF. (8) C onnection of motor for double-leaf : If the gate is the priority openning leaf must be connected with “MOTOR1”, the otherone is connected with “MOTOR2”. And the “dip2” on “S4” must be “ON”. Australian Technology...
- Page 19 Right Open First Left Open First Australian Technology...
- Page 20 Meaning of display Australian Technology...
- Page 21 Head Office - Australia Indian Office Auto Ingress India Pvt Ltd B-4/32, SIDCO Industrial Estate, Maraimalai Nagar, Chennai - 603209 Tamil Nadu, India Phone: +91 44 2745 2151, Mobile: +91 755 00 22 007 | +91 733 88 52 901 – 905...
