6. How to assemble the ISIS Manual Breast Pump

Separate all parts and ensure pump has been cleaned
and sterilised as in section 3:
1
Wash your hands thoroughly. Insert the
white valve (g) into the pump body (f)
from underneath making sure the flat
side of the valve is downwards and the
star side is facing up.
4
Place the silicone diaphragm and stem (d)
into the pump body (f). Make sure it fits
securely around the rim by pressing
down with your fingers to ensure a
perfect seal. (This is easier if assembled
whilst wet.)
6
IMPORTANT: DO NOT LOSE THE
WHITE VALVE. YOUR PUMP WILL NOT
WORK WITHOUT IT OR IF IT IS FITTED
INCORRECTLY. If lost, spare valves are
available direct from Philips AVENT.
5
Place the forked end of the handle (e)
under the silicone diaphragm and
stem (d) and push down gently on
the handle until it clicks into place.
2
Place the pump body (f) onto
the Airflex Feeding Bottle (h).
6 6
Carefully insert the Let-down Massage
Cushion (b) into the pump funnel (f)
making sure it is perfectly sealed all
round the rim of the funnel. (This is
easier if assembled whilst wet.)
3
Twist gently clockwise until secure.
DO NOT OVERTIGHTEN!
7
Click the pump cover (c) onto the pump
body (f). To make the pump completely
stable insert the bottle into the stand (i).
