Summary of Contents for FURIOUS VTX 700mW
- Page 1 STEALTH LONG RANGE VTX 700mW Video Transmitter USER MANUAL VERSION 1.0 Please contact us if you need further assistance: Tech support: tech@furiousfpv.com Sales support: sales@furiousfpv.com Website: http://furiousfpv.com/...
-
Page 2: Table Of Contents
CONTENTS Introduction ........................2 Features .......................... 2 Specifications ........................2 Pinouts ........................... 4 Dimensions ........................4 Weight ..........................5 Connections ........................5 Using Fortini F4 OSD: .................... 5 Using Fortini F4: ....................7 Using Radiance Dshot Version: ................8 ... -
Page 3: Introduction
Stealth Long Range VTx - Explore New Worlds. Push your FPV like never before! With 700mW of long range adjustable output power, the all new Furious FPV Stealth Long Range VTx is the ultimate FPV VTx to push your FPV experience to the outer limits and beyond. - Page 4 Massively Adjustable mW Output Pick your poison. With (3) power output selections of 25mW, 200mW and 700mW of long range FPV power, the Stealth Long Range VTx offers the perfect output for race ready madness or long range flight - all with instantaneous ease. The Ultimate In Long Range With a massive 700mW of output power available, the Stealth Long Range VTx pushes your FPV to the extreme, offering a zero compromise design when going the...
-
Page 5: Pinouts
Pinouts Dimensions... -
Page 6: Weight
Weight Connections Using Fortini F4 OSD: Using 5V from VTx to power camera... - Page 7 Using battery from VTx to power camera You can buy Fortini F4 OSD right here: https://goo.gl/2cQ7Dm...
-
Page 8: Using Fortini F4
Using Fortini F4: You can buy Fortini F4 right here: https://goo.gl/H5QgX8... -
Page 9: Using Radiance Dshot Version
Using Radiance Dshot Version:... -
Page 10: Using Raceflight Fc
Using RaceFlight FC:... -
Page 11: Using Kiss Fc V2
Using KISS FC V2:... -
Page 12: Leds Status Table
LEDs Status Table LED Flash Codes for Channel, Band and Power Table1: Led Colors For Configurations Table2: Current Power Status Table3: Notification Signals Bands, Channels and Frequencies: Band Band A 5865 5845 5825 5805 5785 5765 5745 5725 Band B 5733 5752 5771... -
Page 13: Set Frequency And Power For Stealth Long Range Vtx
Set Frequency And Power For Stealth Long Range VTX Option 1: Configure Stealth Long Range VTx by button NOTE: You need Unlock Stealth Long Range VTx to use full frequency and 200mW,700mW power... -
Page 14: Option 2: Configure Stealth Long Range Vtx By App On Smartphone
Option 2: Configure Stealth Long Range VTx by app on Smartphone This is the first app to configure for VTx in the world at the moment of talking, Android: https://goo.gl/XS7hic iOS: https://goo.gl/2prmi8 Step1: You need connect your Stealth Long Range VTx with Bluetooth module Step2: DOWNLOAD app Imagination Configurator iOS app Android app... - Page 15 Step4: Change Name and Password To change your Device Name and Password, please hit “PROFILE” tab on app. You can use 12 character for Name and 6 numbers for Password. Hit BACK on your mobile to come back to home menu. Step5: Select your style quad at home screen using - Racing: Only Pitmode/25mW with frequency use for Racing quad - Freestyle: Pitmode/25mW/200mW/700mW with 40CH/5 Bands...
- Page 16 Step7: Configure your Stealth Long Range VTx with app Meaning of icons on app: Start-up have a pop-up with 3 selections for VTx power when you plug battery Pitmode: When plug battery, VTx will be working with Pitmode 0.1mW ...
-
Page 17: Option 3: Configure Stealth Long Range Vtx By Transmitter Taranis
Betaflight using LUA script and Smart Port. In this tutorial, we are going to show you how. Furious FPV uses this article is written by Artur Banach, Oscar and editted by Furious FPV. This guide is written specifically for Betaflight firmware - Fortini F4 OSD. -
Page 18: Update Taranis Opentx Firmware
Update Taranis OpenTX Firmware Your Taranis TX has to be updated to the latest OpenTX firmware. The process is simple, and it’s covered here: https://oscarliang.com/flash-opentx-firmware-taranis/ Download LUA Script for Betaflight The LUA script for Betaflight can be downloaded here: https://github.com/betaflight/betaflight-tx-lua-scripts/releases *Note: Don't copy the contents of this repository onto your SDCard Unzip the files from the link above and drag the contents to your radio. -
Page 19: Betaflight Configurator Settings
Betaflight Configurator Settings First of all, make sure that SmartPort is setup properly: 1. In Betaflight Configurator, Ports tab, find the UART where you have connected S.PORT to, then select SmartPort at “Telemetry Output” column 2. Enable option TELEMETRY in Configuration tab Extra Steps for VTx setup Go to Ports tab, find the UART4 you connected FC to the VTx and choose IRC TRAMP [Auto] in “Peripherals”... - Page 20 6. Select “bf” and hit [ENT] 7. Long-press [EXIT] to return to your model screen To invoke the script, simply long-press the [PAGE] button from the model screen. (LUA script is triggered by entering Telemetry Screen 1). Page 1 of the script is for VTx settings. After making VTx setting changes on your Taranis, you can save it by long pressing the MENU button.
