Installing the Rear View Camera (RVC)
Attached are instructions how to take apart the trunk lid. You have to replace the factory trunk
handle with the new one (in the process move the switch from your original trunk handle to the
new one) and then run the camera cable all the way to the dashboard under various trim pieces,
through the rear seats and under the door sills. Then
connect the yellow RCA cable from the rear
camera extension cable to the yellow RCA socket marked (R-CAM) in the RCA harness and also
connect the rear camera power connector to the respective R-CAM power socket on the RCA
Harness.
BimmerTech
Phone: +1(646) 439-7920 • www.bimmer-tech.net
