Page 1: Operating Instructions
Operating Instructions Original Operating Instructions micron 7 AOM70U00... -
Page 2: Table Of Contents
Manufacturer: HBC-radiomatic GmbH • Haller Straße 45 – 53 • 74564 Crailsheim • Germany • Tel. +49 7951 393-0 • info@radiomatic.com. HBC.radiomatic GmbH is not liable for any misprints or errors! – Specifications and design subject to change without notice. -
Page 3: Safety Instructions
Modifications to the radio system may only be carried out by specialist personnel who have been trained and authorized by HBC-radiomatic. All modifications must be documented at the factory in the radio control master file. ... -
Page 4: Fcc Notes
FCC notes Part 15.21 Statement Changes or modifications made to this equipment not expressly approved by HBC-radiomatic GmbH may void the FCC authorization to operate this equipment. Part 15.105 Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. -
Page 5: Operation
Operation ® The transmitter is equipped with an electronic radiomatic iLOG key. ® radiomatic iLOG contains all the data required for operating the transmitter. ® Operation is not possible without radiomatic iLOG! ® Depending on the version the radiomatic iLOG can also be used for operation of replacement transmitters of identical construction. -
Page 6: Deactivating The Transmitter
APPLY SMART CARD is now shown in the 2. Pull the STOP switch. display. 3. Hold your HBC Smart Card to the lower end of the transmitter (cf. illustration). 4. The status LED flashes green. The following symbols are now shown in the display: 5. -
Page 7: Display
Display Field strength Battery Status Display only for systems with feedback) Field strength ( The field strength indication provides information about the quality of the radio connection . With a The field strength indication perfect connection quality, all 5 bars of the indication are displayed green. is always visible when the transmitter is turned on Field strength is indicated in the following degrees: Perfect reception signal... - Page 8 Feedback The feedback function is used to transmit various information and data from the machine or the radio receiver to the radio transmitter. A number of symbols as well as two lines of text with 6 and 10 digits respectively are available for displaying feedback information. Feedback via symbols Symbol shines after the transmitter has been activated.
-
Page 9: Individual Display Settings
2. Pull the STOP switch. APPLY SMART CARD is now shown in the display. 3. Hold your HBC Smart Card to the lower end of the transmitter (cf. illustration). 4. The status LED flashes green. MENU is shown in the first text line, ADJUSTMENT in the second text line. - Page 10 If you want to work with the transmitter after finishing your settings, you need to deactivate the transmitter via the STOP switch and reactivate it by the standard start-up sequence or your HBC Smart Card. For safety reasons, changing directly from the settings mode to working mode is not possible.
- Page 11 Perform settings After successfully turning on the transmitter, MENU is shown in the upper line of the display. The sub-menu ADJUSTMENT is already selected in the lower text line. If the sub-menu SYSTEMDATA is shown, press once in the first step until the requested sub-menu ADJUSTMENT is displayed.
- Page 12 Editing fixed text lines In the settings mode you can edit the 2 text lines of the display. Text changes have to be performed separately for each line respectively. Text line 1 contains 6 digits, line 2 contains 10. Each digit can display both letters and numbers.
- Page 13 Retrieve system information Here you can retrieve diverse pieces of information about the radio system that can be of high value in a service case. The menu contains the following sub-menus: Indication of the transmitter’s fabrication number (FSS) Indication of the receiver’s fabrication number (FSE) ...
-
Page 14: Battery And Battery Charger
Charge the battery fully before storing it for a prolonged period. Otherwise total discharge may occur. Use only the associated HBC charger to charge the battery Charge the battery at an ambient temperature of 0 – 40 °C (32 – 104 °F). -
Page 15: Charging The Battery
QA108600 / QD108300 / QD308300 with EC type-approval The charger is supplied with a connecting cable with a matching power plug. Charging the battery 1. Connect the charger via the connecting cable to the power supply. 2. Insert the battery into the compartment. Charging will start automatically. -
Page 16: Options
Options The availability of the following functions depends on the design and configuration of your radio control system. Safety Features ® radiomatic shock-off / roll-detect / zero-g / inclination switch The safety features enable a quick shut-down of the radio control in specific emergency situations. Therefore, these intelligent functions prevent a dangerous unintended command from being given to the crane or machine. - Page 17 ® radiomatic infrakey The radio system can only be activated via an infrared link between the transmitter and the receiver. This increases the safety of operation, i.e. the machine can not become inadvertently enabled. ® radiomatic infrakey operates either with an infrared ®...
- Page 18 Diagonal movements are not possible. User identification The "user identification" function with the HBC Smart Card enables a simple personalization of the radio system as well as the storage of all user profiles in the radio system. Safety relevant functions can be released to authorized personnel only and unauthorized users can be protected of potentially dangerous situations.
-
Page 19: Frequency Management
Frequency Management Fixed Frequency If the identification plate in the battery compartment of the transmitter shows a frequency value (e.g. 433,500 MHz), the transmitter operates with a fixed frequency. Please contact you service department if the frequency has to be changed because the radio channel is already assigned to another user. -
Page 20: Catch-Release
Catch-Release Via the Catch-Release option two or more transmitters can control a machine alternately. When the receiver is switched on, the machine can initially be controlled via any associated transmitter. Once the receiver was taken over by one transmitter, the other transmitters no longer have access. Take over machine 1.... -
Page 21: Tandem Operation
Tandem Operation Tandem Operation T1 The radio system consists of 1 transmitter and 2 receivers for 2 machines. The transmitter can control the machines individually or in parallel The machines are selected at the transmitter via a rotary switch: only machine A machine A + machine B only machine B Tandem Operation T2... - Page 22 Tandem Operation TM/TS The radio system consists of 2 transmitters and 2 receivers for 2 machines. One transmitter is a master transmitter and can control the machines individually or in parallel. The other transmitter is a slave transmitter and can only control machine B. In order to be able to switch to machine B or A+B at the master transmitter, the key must be removed from the slave transmitter and inserted in the master transmitter.
-
Page 23: Catch-Release-Tandem Operation
Catch-Release-Tandem Operation With the Catch-Release-Tandem Operation two or more transmitters can control several machines alternately. Each machine is equipped with a receiver that can receiver and monitor all transmitter frequencies. After activating the receivers all transmitters have equal access to the radio control system. Take over machine 1.... -
Page 24: Cable Control
Cable Control With a cable you can generate a direct data connection between transmitter receiver. radio transmission is disabled. At the same time, the power supply of the transmitter is provided through the cable, as well. Connecting the cable 1. Switch the transmitter off. 2.... -
Page 25: Address Changeover Via Coding Plug
Address Changeover via Coding Plug The coding plug activates a preselected frequency and address coding in the transmitter which corresponds with the data of the respective receiver. If the coding plug is inserted in a spare transmitter, it will receive the same data as the original transmitter. -
Page 26: Slewing Gear Release
Slewing Gear Release Note: Whenever the command "slewing gear release" is actuated by means of the radio control, it is important that the respective check be made. Due to the above, a clearly visible indicator lamp should be installed on the machine. Feedback by LED Using this function, system or machine data can be displayed on the transmitter by LEDs. -
Page 27: Technical Data
Technical Data Unique system addresses over 1.000.000 combinations Supply voltage 3,6 V EMS category The mains supply is cut off by a STOP switch. Therefore, the criteria for an elimination of errors according to EN ISO 13849-2 chapter D.5.3., table D.8 (non-opening of contacts) are met. -
Page 28: Dimensions
Dimensions... -
Page 29: Troubleshooting
Check if all connecting cables and cable junctions carried out. Interruption in the are tight. connecting cable to the machine. If none of the measures mentioned resolve the problem, then please contact your service technician, dealer or HBC-radiomatic, Inc. -
Page 30: Maintenance
Never try to repair the electronics of the radio control system! Opening the transmitter or receiver housing terminates the manufacturer guarantee. Send any defective or faulty equipment to your local distributor or to HBC-radiomatic, Inc. They are experts and have the necessary know-how and OEM spare parts. ... -
Page 31: Hbc-Radiomatic Gmbh
Returns will only be accepted CIF Crailsheim, Germany. Preferred shipping via DPD and UPS Standard. Please use the original HBC packaging if possible. Please use proper packaging to avoid electrostatic discharge hazards with pcbs and/or modules. Warranty claims may not be accepted in case of improper packaging. - Page 32 Bitte liefern Sie die Ware frei Haus an uns zurück! Bevorzugte Speditionen: DPD und UPS Standard. Verwenden Sie mög- lichst die original HBC Umverpackung für die Rücklieferung. Für elektronische Bauteile und/oder Platinen ist eine ESD-Schutz- Verpackung zu verwenden. Garantieansprüche können bei Fehlen der ESD-Schutz-Verpackung erlöschen.
