- Page 1 Continental Automotive France SAS Interior Division- Body & Security User Manual of the Continental Radio Frequency Transmitter Model: TXN1 (433.92 MHz) TXN2 (315 MHz) August 17, 2015...
- Page 2 This document gives an overview of the different device operation modes and the RF transmissions performance of the key model TXN1 and TXN2. In this document the device is referenced as "key", even if the mechanical backup key might be separated from it.
-
Page 3: Operating Modes
Continental Automotive France SAS Interior Division- Body & Security 2 Operating modes The key has three main operating modes which differ regarding of the signal transmitting with the • Immo Immobilizer transponder mode • Remote keyless functionality • PASE Passive key functionality Immobilizer Transponder mode When the key is operating as an immobilizer transponder, the communication is done via a "contact... - Page 4 Continental Automotive France SAS Interior Division- Body & Security 3 Button functions The validation of the accurate frequency deviation and the measurement of the transmission function of the key are implemented basing on RF test software. The graphic below shows the functionality of the buttons.
- Page 5 Continental Automotive France SAS Continental Automotive France SAS Interior Division- Body & Security Body & Security Lock/Unlock/Panic S180144502 433.92 MHz Lock/Unlock S180144600 315 MHz Lock/Unlock/PSD-L S180144601 315 MHz Lock/Unlock/PSD- S180144602 L/PSD-R 315 MHz Lock/Unlock/PSD-L S180144603 433.92 MHz Lock/Unlock/PSD- S180144604 L/PSD-R 433.92 MHz...
- Page 6 Continental Automotive France SAS Interior Division- Body & Security S180144700 Lock/Unlock/PBD 433.92 MHz S180144701 Lock/Unlock/PBD/P 433.92 MHz S180144702 RES/Lock/Unlock/PBD 433.92 MHz S180144703 RES/Lock/Unlock/PBD/P 433.92 MHz August 17, 2015...
- Page 7 Continental Automotive France SAS Interior Division- Body & Security 5 Label Information Continental Model: TXN1 USA/Canada Continental Model: TXN1 FCC ID: KR5TXN1 IC:7812D-TXN1 6 Owner Manual Owner Manual USA/Canada FCC ID: KR5TXN1 IC:7812D–TXN1 This device complies with Part 15 of the FCC Rules and Industry Canada licence-exempt RSS standard(s).
- Page 8 Cet appareil numérique de classe B est conforme à la norme canadienne NMB-003. Continental Automotive GmbH has not approved any changes or modifications to this device by the user. Any changes or modifications could void the user’s authority to operate the equipment.
