- Page 1 Continental Automotive GmbH I BS PG3 CFRF WM User Manual of the Continental Transmitter TYPE 451 TX 5WK45146 I:\POSTZULA\z1_Projekte\B_Abgeschlossen\Abgeschlossene_Projekte_(2005_2009)\Smart_W451\Smart_W451_Key\Technische_Doku_doc\2012_06_Func_Sm artW451TX_434_MHz.doc Page 1 of 5...
- Page 2 Continental Automotive GmbH I BS PG3 CFRF WM 1. General Description of the RF Transmitter The described system is a radio-frequency remote control (usually called Remote Keyless Entry system) for central doors locking / unlocking destined to equip the Smart W451 car line. The...
-
Page 3: Power Supply
Continental Automotive GmbH I BS PG3 CFRF WM 3. Power Supply The transmitter is provided with 1 lithium battery (CR 2016) that gives a power supply of +3V. The key is protected against polarity reversal due to wrong battery insertion by mechanical means. -
Page 4: Mechanical Design
Continental Automotive GmbH I BS PG3 CFRF WM 6. Mechanical Design Top view Unlock Lock Trunk Key Blade (VALEO) Bottom view Side view 7. Technical Data Carrier frequency: 433 MHz ± 81ppm (ECE), Output power : < 10mW Type of modulation:... -
Page 5: Label Design
Continental Automotive GmbH I BS PG3 CFRF WM 8. Label Design Continental 451 TX 5WK45146 I:\POSTZULA\z1_Projekte\B_Abgeschlossen\Abgeschlossene_Projekte_(2005_2009)\Smart_W451\Smart_W451_Key\Technische_Doku_doc\2012_06_Func_Sm artW451TX_434_MHz.doc Page 5 of 5...
