Stretch FireWire
User's Manual
M4-200 & 201
Doc No. : OEB-D150102-M4 / Rev1.2
®
TM
Manual Contents
__________________________________________
Manual Contents
Pictorials
Figure 1 - Firewire repeater system
with optional fiber cables
Figure 2 - End View of M4-200 Repeater
Figure 3 - Side View of M4-200 Repeater
Figure 4 - End View of M4-201 Repeater
Figure 5 - Side View of M4-201 Repeater
1- 0 Manual Contents
1-0
1-1
1-2
1-3
1-6
1-7
1-8
1-9
1-1
1-3
1-3
1-4
1-5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Stretch FireWire M4-200 and is the answer not in the manual?

Questions and answers

Related Manuals for opticis Stretch FireWire M4-200

Summary of Contents for opticis Stretch FireWire M4-200

  • Page 1: Table Of Contents

    ® Installation Troubleshooting, Maintenance, Technical Support Product Specifications Warranty Information Certifications www.opticis.com Pictorials Figure 1 – Firewire repeater system with optional fiber cables Stretch FireWire Figure 2 – End View of M4-200 Repeater Figure 3 – Side View of M4-200 Repeater Figure 4 –...

  • Page 2: Welcome, Product Description

    Welcome! System Requirements for Setup  Hardware requirements Congratulations on your purchase of the Stretch Firewire M4-200/201 Optical FireWire Repeater System. This manual contains information that will  You have to have a 1394(a/b) controller having a DS / bilingual assist you in installing and operating the product.

  • Page 3: Installation

    Rx (M4-200) to Tx (M4-201) Step 5 If there are non-Opticis external power supplies to be attached, do so now. e.g. block power supplies for laptop Firewire PC cards, downstream appliances, etc. Do NOT attach the Opticis power supplies until instructed to do so.

  • Page 4: Troubleshooting, Maintenance, Technical Support

    Step 3 Troubleshooting If there are non-Opticis external power supplies to be attached, do so now. e.g. block power supplies for laptop Firewire PC cards, downstream The Power LEDs are not illuminated. appliances, etc. Do NOT attach the Opticis power supplies until instructed to Ensure that all AC and DC plugs and jacks used by external power supplies do so.

  • Page 5: Product Specifications

     Fully supports provisions of IEEE1394b-2002 one (1) year from the date of purchase from Opticis or its authorized resellers. M4-200: 2 bilingual ports, M4-201: 1 bilingual port If a product does not work as warranted during the applicable warranty period, ...

  • Page 6: Www.opticis.com

    Certification of Eye Safety This laser product is inside implemented by using 1310, 1550nm LD Transceivers, manufactured by Opticis Co., Ltd., which are all certified by CDRH/FDA referred as classified in Laser Class 1 (IEC60825-1). Caution – Use of controls or adjustments or performances of procedures other than those specified herein may result in hazardous radiation exposure.
