The multifunctional weather station is equipped with many functions providing thorough weather information
to you. The receiver unit has a clear, easy-to-read display that shows weather forecast, indoor temperature,
relative humidity, pressure, moon phase, time and date, as well as the temperature and relative humidity
measured and transmitted by the sensor. It is able to receive and display readings from up to 3 remote sensors.
The receiver unit retains the minimum and maximum temperatures and relative humidity readings measured at
various locations. The 433 MHz technology means no wire installation is required and you can place the
sensors anywhere you like.
With radio controlled function, the current time and date are automatically synchronized with the time signal
transmitted from Frankfurt (DCF77). The signal can cover a distance of about 1500 km from the Frankfurt
transmitter.
MAIN FEATURES:
WEATHTER STATION:
1.
TIME:
-
Press it once to view the year.
-
Press and hold it for 2 seconds to enter the time setting mode.
2.
ALARM:
-
Press it to switch to alarm and temperature alarm.
-
In alarm mode, press and hold it for 2 seconds to enter the alarm and pre-alarm setting mode.
3.
UP:
-
In normal time mode, press it to choose between channel (1), (2) and (3).
-
In setting mode, press it to increase the setting value.
-
In alarm mode, press it to turn on/off alarm and snooze.
4.
DOWN:
-
Press and hold it for 3 seconds, release, then press it to change the weather indicator.
-
In alarm mode, press it to turn on/off alarm and snooze.
1
WIRELESS WEATHER STATION
C-8105
USER'S INSTRUCTIONS
Advertisement
Table of Contents
Related Manuals for Chung’s Electronic C-8105
Summary of Contents for Chung’s Electronic C-8105
- Page 1 WIRELESS WEATHER STATION C-8105 USER’S INSTRUCTIONS The multifunctional weather station is equipped with many functions providing thorough weather information to you. The receiver unit has a clear, easy-to-read display that shows weather forecast, indoor temperature, relative humidity, pressure, moon phase, time and date, as well as the temperature and relative humidity measured and transmitted by the sensor.
- Page 2 HISTORY: Checking the past 24 hours pressure records. MAX/MIN : Press it once to check max./ min. temperature record. Press and hold it for 3 seconds to delete the max. and min. record. SNOOZE • LIGHT: Press it once, EL backlight keeps on for 5 seconds. Press it to stop alarm when it is sounding.
-
Page 3: Before You Begin
TRANSMITTER: 1. LED indicator: Flashes when the remote unit transmits a reading. 2. Two-line LCD: Displays the current temperature and humidity monitored by the remote unit. 3. Channel slide switch: Assign the transmitter Channel 1, Channel 2 or Channel 3. 4. -
Page 4: Weather Station
6. Re-fix the battery compartment door, and secure its screws in evenly and diagonally. NOTE: 1. Once the channel is assigned to a transmitter, you can only change it by removing the batteries or resetting the unit. 2. Avoid placing the transmitter in direct sunlight, rain or snow. WEATHER STATION: 1. -
Page 5: Reception Of Radio Controlled Time Signal
NOTE: 1. Do not set the weather indicator when it is raining. Raining will give unstable data. 2. Do not set the weather indicator in nighttime. RECEPTION OF RADIO CONTROLLED TIME SIGNAL The time and date are radio-controlled. The current time and date are automatically synchronized with the time signal transmitted from Frankfurt, Germany (DCF77), provided the device is within about of 1500 km range of the transmitter. -
Page 6: Manual Time Setting
MANUAL TIME SETTING If you are out of the reach of the Radio Controlled Tranmsitter or if the reception is not reachable, the time can be set manually. As soon as the transmitter is received again, the clock will automatically synchronise with the received time. -
Page 7: Setting The Temperature Alarm
SETTING THE TEMPERATURE ALARM Use this function to be woken up at a determined period of time earlier (1-30 minutes), if one of the transmitter‘s temperatures is below -1 °C. 1. In normal time mode, press ALARM key twice to enter pre-alarm mode, press UP or DOWN key to turn pre-alarm on. -
Page 8: Weather Trend
1. Press MAX/MIN key to check Maximum temperature and humidity records. Press it twice to check the Minimum records. Press it thrice to exit. 2. Press and hold MAX/MIN key for 3 seconds to delete the records. MAX. Temperature / humidity record MIN. - Page 9 3. The “Sunny” icon, when applies to nighttime, implies clear weather. Slightly cloudy Cloudy Rainy Storm Sunny NOTE:THE COMFORT-LEVEL ICONS The comfort level icons COMFORT, DRY and WET will tell you what the current environment is. Comfort level Icon displayed Temperature Range Humidity Range Current...
- Page 10 ABOUT THE MOON PHASE The unit has 8 different moon phases. It will change according to the lunar calendar. 1. New moon 2. Waxing crescent 3. First quarter 4. Waxing Gibbous 5. Full moon 6. Waning Gibbous 7. Last quarter 8.
- Page 11 NOTE Under the environment with radio frequency interference, the sample could not maintain communication link and resume to normal when interference stops. FCC Remarks: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
-
Page 12: Remote Sensor
0 °C to +45 °C Recommended operating range: 0.1 °C / 1°F (above 0 °C) Temperature resolution: 1 °C / °F (below 0 °C) Indoor relative humidity measurement range: 20% RH to 90% RH Recommended operating range: 20% RH to 90% RH Resolution: 1% RH REMOTE SENSOR...
