PROFESSIONAL RAIN GAUGE
RADIO-CONTROLLED CLOCK
PRELIMINARY VERSION 2014-12-31
DISPLAY MAIN UNIT
GAUGE RAIN SENSOR
USER MANUAL
C8437
C3101
CONTENTS
INTRODUCTION...................................................................................................................................................................1
PRODUCT FEATURES........................................................................................................................................................1
OVERVIEW...........................................................................................................................................................................2
LCD DISPLAY.......................................................................................................................................................................3
INSTALLATION OF WIRELESS SENSOR..........................................................................................................................4
DISPLAY MAIN UNIT............................................................................................................................................................5
WIRELESS SIGNAL RECEPTION.......................................................................................................................................6
RAINFALL.............................................................................................................................................................................7
HISTORY DATA OF ALL RECORD IN THE PAST 24 HOURS..........................................................................................7
MAXIMUM / MINIMUM MEMORY FUNCTION....................................................................................................................8
HI / LO ALERT......................................................................................................................................................................8
DATACLEARING..................................................................................................................................................................9
MAINTENANCE OF RAIN COLLECTOR.............................................................................................................................9
TROUBLESHOOTING..........................................................................................................................................................9
PRECAUTIONS....................................................................................................................................................................9
SPECIFICATIONS..............................................................................................................................................................10
Advertisement
Table of Contents
Related Manuals for Chung’s Electronic C3101
Summary of Contents for Chung’s Electronic C3101
- Page 1 PRELIMINARY VERSION 2014-12-31 HISTORY DATA OF ALL RECORD IN THE PAST 24 HOURS..................7 MAXIMUM / MINIMUM MEMORY FUNCTION........................8 HI / LO ALERT..................................8 DATACLEARING..................................9 MAINTENANCE OF RAIN COLLECTOR..........................9 TROUBLESHOOTING................................9 PRECAUTIONS..................................9 SPECIFICATIONS................................10 C8437 DISPLAY MAIN UNIT C3101 GAUGE RAIN SENSOR USER MANUAL...
-
Page 2: Introduction
INTRODUCTION OVERVIEW Display Main Unit Thank you for selecting the Professional Rain Gauge Sensor. The device contains a wireless self-emptying rain collector for measuring rainfall and temperature, and a Display Main 1. LCD display with backlight Unit. The wireless rain collector sensor is fully assembled and calibrated for your easy installation. It transmits data by a 2. -
Page 3: Lcd Display
LCD DISPLAY INSTALLATION OF WIRELESS RAIN GUAGE SENSOR Normal Time and Calendar Your wireless rain gauge sensor measures rainfall and temperature for you. It’s fully assembled and calibrated for your easy installation. 1. SINCE icon Battery and Installation 2. HISTORY icon 3. -
Page 4: Display Main Unit
DISPLAY MAIN UNIT To Manually Set the Clock / Time Zone Selection Stand and Batteries Installation 1. Press and hold [ CLOCK ] button for 2 seconds until “12 or 24 Hr” flashes. 2. Use [ UP ] / [ DOWN ] button to adjust, and press [ CLOCK ] button to proceed to the next setting. The unit is designed for desktop or wall mount for easy viewing. -
Page 5: Wireless Signal Reception
● MONTH The MONTH display indicates the total rainfall within a month To Clear Individual Records ● YEAR The YEAR display indicates the total rainfall within a year While displaying the maximum/minimum records, press and hold [ MEM ] button for 2 seconds to clear the individual record. NOTE: User can select the measurement unit for rainfall by sliding the [ MM/IN ] switch. -
Page 6: Dataclearing
DATA CLEARING • When disposing of this product, ensure it is collected separately for special treatment. • Placement of this product on certain types of wood may result in damage to its finishing for which manufacture will not During installation of the wireless sensor, the sensors were likely to be triggered, resulting in erroneous rainfall and wind be responsible. - Page 7 WIRELESS SENSOR Dimensions 109 x 200 x 109 mm (W x H x D) Weight 372g without batteries Battery 4 x AA size 1.5V battery Frequency 868 MHz (European) / 915 MHz (North American) / 917 MHz (Australian) Transmission Every 12 seconds OUTDOOR TEMPERATURE Temp.
