- Page 1 OPERATION MANUAL V I B R A T I O N M E T E R www.baltech.biz...
-
Page 2: Table Of Contents
1. DEVICE DESCRIPTION 1.1 Application 1.2 Design and principle of operation 1.3 Technical data 1.3.1 Application conditions 1.3.2 Main technical data of the device BALTECH VP-3410 1.4 Delivery set 1.5 Transportation and storage 1.6 Acceptance certificate 1.7 Manufacturer’s warranty 2. OPERATION MANUAL 2.1 Appearance and operation elements of the device... -
Page 3: Device Description
DEVICE DESCRIPTION 1.1 Application The vibration meter BALTECH VP-3410 is designed to perform vibration monitoring of a wide range of machines for the purpose of checking their technical condition. The vibration meter is a simple, portable measurement device, which allows to perform the following tasks: - measurement of vibration acceleration in two frequency bands;... -
Page 4: Technical Data
- relative humidity at 25 °С, % to 95 The device is powered from 9V battery, type D (6F22, 6LF22). 1.3.2 Main technical data of the device BALTECH VP- 3410 Technical data of the device is listed in the table DEVICE TECHNICAL DATA Table 1.1... -
Page 5: Transportation And Storage
1.5 Transportation and storage The vibration meter BALTECH VP-3410 must be protected from heavy shocks and vibrations. If the vibration meter is not used for a long period of time, it is necessary to remove the battery, in order to prevent outflow of liquid from it, which may result in the device damage. -
Page 6: Operation Manual
OPERATION MANUAL 2.1 Appearance and operation elements of the device Figure 1... -
Page 7: Operation Mode
2.2 Operation mode 2.2.1 Device on/off Press the measurement button to switch on the device. The vibration meter SWITCHES OFF in a minute AUTOMATICALLY. 2.2.2 Battery monitoring If during the device operation the screen displays «BAT», it means, that the battery is low and it is necessary to replace it. -
Page 8: Measurement Mode
2.2.3 Measurement mode Press the button «SET» to select a measurement mode: acceleration, velocity or displacement; the selected mode is indicated by the arrow on the right side of the screen. Acceleration Velocity Vibration displacement Measurement mode indicator Figure 2 2.2.4 Selection of frequency range interval When measuring acceleration, you can use a button of the frequency range change. -
Page 9: Work With The Device
If necessary, replace it. Remove the shield from the magnet before mounting the sensor. 2.3.2 Sensor mounting The vibration meter BALTECH VP-3410 uses the acceleration sensor, which is connected to the electronic device via low noise cable. The sensor can be mounted on the measurement object in the following way: 1. -
Page 10: Execution Of Measurement
2.3.3 Execution of measurement 1. Hold the measurement button during 10 seconds, after this the vibration meter is ready for measurement; 2. Press the measurement button and hold it, mount the sensor on the measurement object. The screen will display the measurement results;... -
Page 11: Information About Maintenance And Repair
Date, Scope of work signature TRAINING For efficient and qualitative operation of the device BALTECH VP-3410, we recommend you to pay attention to: - Specialists who work with the device must be certified on the course «Reliability technologies» in the BALTECH training centre. - Page 12 BALTECH GmbH Kronsforder Allee 45, 23560 Lübeck Germany Tel: +49 (0) 451-370-87-700 E-Mail: info@baltech.biz www.baltech.biz...
