User's Guide
PlugLink 9550 Wireless Access Point
PL9550-WAP
Version: 1.01
©
Copyright 2005. Asoka USA Corporation. All rights reserved. Asoka USA Corporation reserves the
right to modify product offerings or specifications without advance notice. No part of this publication may
be produced in any format without the express written permission of Asoka USA Corporation.
Advertisement
Table of Contents
Related Manuals for Asoka PlugLink 9550
Summary of Contents for Asoka PlugLink 9550
- Page 1 Copyright 2005. Asoka USA Corporation. All rights reserved. Asoka USA Corporation reserves the right to modify product offerings or specifications without advance notice. No part of this publication may be produced in any format without the express written permission of Asoka USA Corporation.
- Page 2 FCC Caution: 1. This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
-
Page 3: Table Of Contents
Asoka® User’s Guide PlugLink 9550 Wireless Access Point PL9550-WAP Introduction ......................4 1.1 Features....................... 4 1.2 Package ....................... 4 2. Hardware Installation ....................5 2.1 The Front Panel ....................5 2.2 Connect Device and PC..................5 3. Wireless AP Configuration ..................5 3.1 Logging in ...................... - Page 4 Asoka® User’s Guide PlugLink 9550 Wireless Access Point PL9550-WAP Technical Support You can download latest software from our website. If you have any question or difficulty during installation or using PlugLink PL9550-WAP, please contact our technical support engineer. About User’s Manual User’s Manual of PL9550-WAP is released in December, 2005, the version is 1.01.
-
Page 5: Introduction
Asoka® User’s Guide PlugLink 9550 Wireless Access Point PL9550-WAP Introduction Thanks for your selection of AsokaUSA PlugLink PL9550-WAP. We are devoting to provide powerful, high-performance and applied power line networding system. The product is designed for home, hotel, office, apartment . It provides a full local network solution with PLC technical. -
Page 6: Hardware Installation
“255.255.255.0”. f. Use laptop or PC with wireless card to connect the wireless AP, the default ESSID is “Asoka” and is without encryption or authenticate key. 3. Wireless AP Configuration The Wireless AP provides Web-based GUI for user to configure the device. It means user can use any web explorer (Internet Explorer ,Netscape Communicator etc. -
Page 7: System
Asoka® User’s Guide PlugLink 9550 Wireless Access Point PL9550-WAP Figure 1. system login The default User ID is “admin” and the default Password is “welcome”. Please remember to modify User ID and Password after you login successfully first time. 3.2 System System configuration provides interface to view the general configuration and status and set general configuration of the device including Date &... -
Page 8: Time
Asoka® User’s Guide PlugLink 9550 Wireless Access Point PL9550-WAP Figure 2. system details From the page, we can find that there is one main menu in the upper part for configuration. The submenu in the left part of the page show all items for each menu selected. -
Page 9: System Logs
Asoka® User’s Guide PlugLink 9550 Wireless Access Point PL9550-WAP The upper form shows how to change system user ID and Password Input old user id in the first text box Input new user id in the second text box (input old user id means keep user id without... -
Page 10: Backup
Asoka® User’s Guide PlugLink 9550 Wireless Access Point PL9550-WAP Figure 5. System Reset To reset system, click button “System Reset”. If you confirm your decision, please wait a minute for the system reboot. To restore the factory setting to the gateway, click button “Factory Default”. If you confirm your decision, please wait a minute because the system should be rebooted. -
Page 11: Wireless
Asoka® User’s Guide PlugLink 9550 Wireless Access Point PL9550-WAP Figure 7. Firmware upgrade Click button “Browser” to select firmware file, then one windows dialog will be popped up for user to select local file Check the ‘clear old configuration’ box to clear old configuration saved in the device and restore with factory default during upgrade. -
Page 12: Wireless Security
Asoka® User’s Guide PlugLink 9550 Wireless Access Point PL9550-WAP The screen contains the following details. Wlan Interface: To enable or disable wireless part of the device. Select the check box to enable wireless function. Channel Id: Identifies the channel on which the AP communicates. Each wireless client must use the same channel to enable communication. -
Page 13: Ip Address
Asoka® User’s Guide PlugLink 9550 Wireless Access Point PL9550-WAP Figure 9. Wireless Security The screen contains the following details. Encryption Type Determines the type of security encryption algorithms for the key index. This security setting encrypts your wireless transmission. None, WEP are available only when Open System or Pre-shared KEY (PSK) is selected for authentication type. -
Page 14: Ip Address
Asoka® User’s Guide PlugLink 9550 Wireless Access Point PL9550-WAP 3.4.1 IP Address To configure the IP Address of the Wireless AP, click on the link IP Address in the left submenu, a screen is displayed as shown in Figure 11. - Page 15 Asoka® User’s Guide PlugLink 9550 Wireless Access Point PL9550-WAP link Device Scan in the left submenu, a screen is displayed as shown in Figure 13. Figure 13. Scan devices The screen contains the following details. Scanned Devices: The No. of the device have been scanned...
