In the State of Massachusetts, the following installation instructions apply:
Installations and repairs must be performed by a qualified or licensed contractor, plumber, or gasfitter qualified or licensed by
the State of Massachusetts.
If using a ball valve, it shall be a T-handle type.
A flexible gas connector, when used, must not exceed 3 feet.
Tools and Parts
Gather the required tools and parts before starting installation.
Read and follow the instructions provided with any tools listed here.
Tools Needed
Adjustable wrench
Tape measure
Marker or pencil
Pipe wrench
Flat-blade screwdriver
¹⁵⁄₁₆" combination wrench
Wrench or channel lock
pliers
Pipe-joint compound
resistant to LP gas
Noncorrosive leak-
detection solution
Parts Supplied
Check that all parts are included.
Gas pressure regulator
Burner grates
Burner bases and burner caps
Griddle drip tray (on griddle models)
Foam tape
LP orifice package (W10393255)
Conversion label (W10393342)
NOTE: The cooktop is manufactured for use with Natural gas. To
convert to LP gas, see the "Gas Conversions" section.
Optional Backguards
48" (121.9 cm) models must be installed with a backsplash if
installing at zero clearance to a combustible backwall. See
"Cabinet Dimensions" in the "Location Requirements" section for

installation requirements.

36" (91.4 cm) Retractable Backguard
Order Part Number 8284756
48" (121.9 cm) Retractable Backguard
Order Part Number 8284755
9" (22.9 cm) Backguard for 36" (91.4 cm) Cooktops
Order Part Number W10115776
9" (22.9 cm) Backguard for 48" (121.9 cm) Cooktops
Order Part Number W10115777
33½" (85.0 cm) Retractable Backguard with Wire Shelf for
36" (91.4 cm) Cooktops
Order Part Number W10285448
33½" (85.0 cm) Retractable Backguard with Wire Shelf for
48" (121.9 cm) Cooktops
Order Part Number W10285449
INSTALLATION REQUIREMENTS
For LP/Natural Gas
Conversions
Adjustable wrench
³⁄₈" drive ratchet
½" deep-well socket
7 mm nut driver
Masking tape
To order, see the "Assistance or Service" section of the Use and
Care Guide.
Check local codes and consult gas supplier. Check existing gas
supply and electrical supply. See "Electrical Requirements" and
"Gas Supply Requirements" sections.
High Altitude Conversion
To convert the cooktop for elevations above 6,560 ft (1999.5 m),
order a High Altitude Conversion Kit.
Part Number W10394296 - LP high altitude
Part Number W10394295 - Natural gas high altitude
To order, see the "Assistance or Service" section of the Use and
Care Guide.
Location Requirements
IMPORTANT: Observe all governing codes and ordinances. Do
not obstruct flow of combustion and ventilation air.
It is the installer's responsibility to comply with installation
clearances specified on the model/serial rating plate. The
model/serial rating plate is located on the underside of the
cooktop burner base.
It is recommended that a 600 CFM or larger vent hood be
installed above the cooktop.
It is not recommended that a microwave hood combination
be mounted above the cooktop.
The cooktop should be installed in a location away from
strong draft areas, such as windows, doors and strong
heating vents or fans.
All openings in the wall or floor where cooktop is to be
installed must be sealed.
Cabinet opening dimensions that are shown must be used.
Given dimensions are minimum clearances.
Grounded electrical supply is required. See "Electrical
Requirements" section.
Proper gas supply connection must be available. See "Gas
Supply Requirements" section.
The cooktop is designed to hang from the countertop by its
side or rear flanges.
The gas and electric supply should be located as shown in
"Gas and Electric Connection Locations" section so that they
are accessible without requiring removal of the cooktop.
Provide cutout in left rear corner of cutout enclosure as
shown to provide clearance for gas inlet, power supply cord,
and to allow the rating label to be visible.
IMPORTANT: To avoid damage to your cabinets, check with your
builder or cabinet supplier to make sure that the materials used
will not discolor, delaminate or sustain other damage.
