- Page 1 BootiQue Active System USER MANUAL...
-
Page 2: Table Of Contents
Contents Important Information........3-4 Introduction Unpacking Mounting Environment Precautions Operating Instructions........5-7 Amplifi er Front LED Panel Remote Controlled Wall Panel Remote Contro Operating Diagram..........8 Specifi cations............. 9 Notes............... 10... -
Page 3: User Manual
EMC Immunity EN55103-2 (1996) • Auto Power off • Attractive styling Electrical Safety EN60065 (1998) Wellington Close • Parkgate • Knutsford Cheshire • WA16 8XL • England Tel: +44 (0)1565 654641 • Fax: +44 (0)1565 755641 Email: info@ohm.co.uk • Website: www.ohm.co.uk... -
Page 4: Unpacking
Congratulations on having purchased an OHM BootiQue Active System Please read this manual and familiarise yourself with the operation of your OHM BootiQue Active System before you attempt to power up this unit. For your own safety we recommend you take the time to read all the warnings and precautions on the page opposite and study the connection details to ensure correct usage and avoid any misuse which may invalidate your warranty. -
Page 5: Operating Instructions
BootiQue Active System OPERATING INSTRUCTIONS AMP PANEL 1 Master Gain 6 Phase Reverse Selector Adjusts the output volume level of the system. 0° - 180° Reverses the phase of the sub. 7 B/Sat EQ Selector 2 Mid-Hi Gain Setting the on/off selector to on will engage... -
Page 6: Amplifi Er
AMP PANEL Continued 8 Auto Power Switch 14 Fire Alarm Muting Senses if signal is present and switches on or Allows the unit to be installed in a location off accordingly. Unit remains in standby mode covered by a voice alarm fi re system with a until a power source is detected. -
Page 7: Remote Control Operation
BootiQue Active System WALL PANEL 1 USB Input Socket USB socket to take USB peripherals such as mp3 players and Flash Drives with MP3 tracks on. When used with a fl ash drive the remote control is used to control track selection and navigation. -
Page 8: Operating Diagram
BootiQue Subwoofer Cabinet panel via phono inputs. Remote control. Controls the BootQue system via the wall panel Satellite speakers up to 4 per side wired in parallel to create 4 ohm. Connect to BootiQue via speaker out binding posts. Left Right... -
Page 9: Specifi Cations
Bass sat 2x60 Watts Output 4 Ohms 1kHz Bass Subwoofer 180 Watts THD<0.1% Stereo Mode Bass sat 2x85 Watts Frequency Response 20Hz-130Hz -3dB @ 1 Watt Into 8 Ohm Input Sensitivity 0.775V/1.1V/26dB THD+N <0.02%@1kHz Damping Factor >250 @ 400Hz into 8 Ohm IMD into 8 Ohm Unbalanced <0.08%@100W... -
Page 10: Notes
Dealer Stamp...
