- Page 1 SKYBRAKE TOUCH User manual - version 1.0...
-
Page 2: Table Of Contents
TABLE OF CONTENTS PRODUCT WARRANTY SYSTEM COMPONENTS Keypad module Passive arming Replacement battery STARTING YOUR VEHICLE Using the keypad PIN code Using Personal Transceiver PIN CODES Code definitions Additional users chart CHANGING PIN CODES Re-setting the Master PIN code from the Factory default “0000” PIN code Changing the Master PIN code Adding an additional user PIN code Change the user PIN code... -
Page 3: Product Warranty
4 minutes (approx), the system will re-arm itself, thus requiring an authorisation code or Personal Transceiver. PRODUCT WARRANTY The warranty for the Skybrake TOUCH is 24 months from the Personal Transceiver date of installation. The warranty is valid in the event that... -
Page 4: Starting Your Vehicle
STARTING YOUR VEHICLE Using the keypad PIN code PIN codes: The Skybrake TOUCH keypad can store up to 5 To disarm the security system, the correct PIN code must be User codes and one Master code, the Master code is used to entered. -
Page 5: Additional Users Chart
Customer Up to five additional PIN codes can be stored in the Skybrake memory slot codes TOUCH keypad. In order to add a new user PIN code, proceed Master PIN code as follows: PIN code for User1 1. Turn the ignition ON 2. -
Page 6: Change The User Pin Code
Change the user PIN code In order to change user PIN code, proceed as follows: 1. Turn the ignition ON 2. Enter existing Master PIN code, and then press # to confirm it. If the Master PIN code has been entered correctly, the keypad will emit two short beeps. -
Page 7: Fault Finding Chart
Also there are sound notifications used to show the security system status (see table): Operation Sound signal System ready (after ignition switched ON) 1 short beep Pressing any soft key 1 short beep Confirming correct PIN code 2 short beeps Confirming incorrect PIN code 1 long beep Confirming correct Overriding PIN code... -
Page 8: Technical Parameters
TECHNICAL PARAMETERS Keypad module: Parameter name Value Operating frequency 2,4 GHz Operating range ~ 5 metres Operating voltage 8-40 V Current consumption 120 mA Operating temperature -40° ... +85°C Dimensions 72x52x13 mm Blocking module: Parameter name Value Operating frequency 2,4 GHz Operating range ~ 5 metres Operating voltage...
