Skybrake DD2+ User Manual

Product descriPtion

SKYBRAKE DD2+ is a high security level vehicle protection
system with an anti-theft function for both parked and moving
vehicles. A vehicle equipped with this immobilizer can only be
used if the personal transceiver (PT) is within range, either inside
the vehicle or no further than 2 m away. If the engine is switched
on without the PT, the engine will operate as shown below:
engine Anti-theft
operation function
1) 50 seconds (programmable from 35 to 65 sec) Switched off
2) Until the car begins moving Switched off
3) 50 seconds (programmable from 35 to 65 sec) Switched on
4) Until the car begins moving Switched on
After which it will be immediately immobilized and the system
will warn the driver by buzzer signals and flashing of the status
LED (if installed).
Depending on DD2+ settings, after switching on the ignition
the device will warn the driver of the presence of the PT by a
buzzer and LED signals:
sound signal
and light diode confirmation
1) one time short ( 0.1 sec),
2) one time long (0.3 sec)
3) silence
4) two times
using the Product
If you wish to drive, the PT of the SKYBRAKE DD2+ immobilizer
must be located inside the vehicle.
If the SKYBRAKE DD2+ is equipped with motion detector, the
system allows you to start the engine without the PT, but at
each attempt to drive, the engine will be immobilized. After the
engine's immobilization, the system allows you to start the engi-
ne again by turning off and on the ignition, but at each attempt
to drive, the engine will be immobilized again. If the engine is
started without the PT more than 8 times, the system becomes
immobilized until the PT is within range or the personal emer-
gency disabling code (PIN code) is used.
if sKYBrAKe dd2+ is equipped with motion detector, be-
fore driving the vehicle, wait for the signals confirming the
Motion
presence of the Pt!
detector
Switched off
If the SKYBRAKE DD2+ is not equipped with motion detector or
Switched on
the motion detector is turned off, the system allows you to start
Switched off
the engine without the PT, but after 50 seconds the engine will
Switched on
be immobilized. Driving the vehicle is not possible until the PT
is within range or the personal emergency disabling code (PIN
code) is used.
sKYBrAKe dd2+ warns the driver of the non-presence of
the Pt in the receiving range in the following order:
1. Activation:
ned on and the system is waiting for a signal from the PT, there
Anti-theft Motion
are no sound or light indications, and the vehicle's engine is not
function detector
immobilized. Activation time is 18 seconds.
Switched off Switched off
Switched off Switched on
2. Warning:
Switched on Switched off
a) Initial warning signals. The time during which, the system
Switched on Switched on
warns the vehicle's driver about the non-presence of the PT wit-
hin receiving range. Long sound signals are emitted; the vehicle
engine is not immobilized. The length of the initial warning sig-
nals is 1 minute.
b) Final warning signals. The time during which, the system
warns the vehicle's driver about the non-presence of the PT wi-
thin receiving range. Brief and regular light and sound signals
are emitted; the vehicle engine is not immobilized. The length
The time during which the vehicle ignition is tur-
The warning signals consists of two parts:
Auto Immobilizer
SKYBRAKE DD2+
of the final warning signals is variable (the factory setting is 32
seconds).
3. Panic:
The time during which the system warns the vehicle's
driver about the non-presence of the PT within receiving range.
Uninterrupted series (5 signals) of sound and light signals are
emitted, the vehicle engine is immobilized.
If while you are driving warning signals start emitting inside the
vehicle, immediately stop by the side of the road in line with
road safety rules and switch off the ignition. Make sure that the
PT is within range. Turn on the ignition and wait for the signals
confirming that the PT has been located. If warning signals indi-
cate that the PT is out of range, immediately contact the system
installer or manufacturer.
If SKYBRAKE DD2+ is equipped with motion detector and panic
mode is activated while the vehicle is in motion, vehicle's engi-
ne will only be immobilized when the vehicle's speed will be 0
km/h; remains the same at least 10 seconds and motion begins
again. If system is not equipped with motion detector and panic
mode is activated, the engine will be immobilized immediately
as panic mode starts.
When the SKYBRAKE DD2+ immobilizer has blocked the engine
you will hear a series of uninterrupted signals.
Anti-theft function.
The anti-theft function will automatically proceed when the PT
is taken out of range with the ignition switched on. For the first
50 seconds, the system will continue to wait for a signal from the
PT. Then the driver will be warned (warning algorithm) – activa-
tion, warning and panic. If the motion detector(if equipped) is
turned on, the engine will be immobilized when vehicle's spe-
ed becomes to 0 km/h and as soon as motion starts again. If
the motion detector is turned off , the engine will be blocked as
