Port Triggers - Spectrum RAC2V1A User Manual

Port Forwarding Table
Enable
Description
WAN
Inbound Port
Type
Private IP
Address
Private Port

Port Triggers

RAC2V1A Router User Guide
Clear this checkbox if you want to stop forwarding
not
this port but do
table.
Enter a name for the port you want to forward.
Choose whether the port forward should be
directed to a client on the default LAN (192.168.1.x)
or on a Routing Information Protocol (RIP) gateway.
Enter the inbound port range for the port you want
to forward. It should be the same range as the local
port.
Set the format for the port. Options are TCP, UDP,
or BOTH.
Enter the IP address of the machine on the LAN
where you want the connections to go.
Enter the private port range for port you want to
forward. It should be the same range as the inbound
port.
Router Configuration Screen Descriptions
want to remove it from the
61
