2004-8-31 T-9701 USER MANUAL Page: 7
Battery Level Indicator
4 levels battery indicator for showing the capacity of the battery
Full
2/3
1/3
low battery warning. Replace all four batteries.
Turn On/Off The T-9701
To turn on the T-9701, press the ON/OFF key for 2 seconds. The T-9701 will beep
and enter to reception mode.
To turn off the T-9701, press the ON/OFF key until the LCD display is cleared.
Backlight Of LCD Display
The screen will light for 10 seconds whenever the any key is pressed. You can
extinguish the backlight by pressing the any key again.
Set The Main Channel And CTCSS Codes
The T-9701 have 14 main channels and 38 CTCSS codes (CTCSS 00 means no code
is checked). You can only communicate the group of correspondent with same main
channel and CTCSS code. If your CTCSS code is 00, you can hear all messages of
the main channel but other people cannot hear your message if their CTCSS code is
not 00.
To set the main channel:
1. Press key 1 time, the main channel number will flash.
or
2. Press key to select your desired main channel.
3. Press PTT key to confirm the selection.
To set the CTCSS code:
