On-Go UCH-300 Quick Start Manual

Universal communication hub
Hide thumbs

Advertisement

Quick Links

Download this manual
Universal Communication Hub UCH-300
Quick Start Guide
On-Go Inc.
P.O.Box 341726
Bethesda, MD 20817
USA
Tel:
+1.301.469.1468
Fax:
+1.301.469.8085
www.on-go.com
Note: The information in this document applies to UCH-300 product. UCH-300 LITE does
not support all the features in the UCH-300. Those features that are not supported by
UCH-300 LITE are in GREEN.

Advertisement

loading
Need help?

Need help?

Do you have a question about the UCH-300 and is the answer not in the manual?

Questions and answers

Related Manuals for On-Go UCH-300

Summary of Contents for On-Go UCH-300

  • Page 1 Bethesda, MD 20817 Tel: +1.301.469.1468 Fax: +1.301.469.8085 www.on-go.com Note: The information in this document applies to UCH-300 product. UCH-300 LITE does not support all the features in the UCH-300. Those features that are not supported by UCH-300 LITE are in GREEN.
  • Page 2 Universal Communication Hub Interface (** Indicates features enabled on the UCH-300 Only) 1. Front View LED Indicators (1-4) LCD Display Speaker Battery Door (located on back of interface) **Compact Flash Port (located on bottom of interface) 2. Right Side View 3.
  • Page 3 Network Routing (Ethernet or Wireless LAN) • Data aggregation UCH-300 LITE has only Serial (DB9) port and Modem (RJ11) port enabled. It provides only data and fax capability. In this document, the text marked GREEN means it only applies to UCH- 300 only.
  • Page 4 (especially due to loss of power). Updating Software from Serial Port In some cases, where software needs to be updated, UCH-300 provides a field update capability. This capability is only available from APPLICATION software version 1.6.x. This should only be performed by qualified technical staff, otherwise it could cause irreversible damage to the software and can only be repaired by the manufacturer.

  • Page 5: Operating System

    c. The computer needs to set the port to 115,200 baud rate, 8 bit, no parity and hardware (RTS/CTS) flow control d. Take the phone/fax machine offhook, enter ##9*PIN* then hangup (PIN is provided only to qualified service provider technical staff) e.
  • Page 6 The system will dump out the configuration in unihub.cfg and log in unihub.log. They can then be viewed on a PC for further diagnosis Application 2.1.1 Store and Forward Fax Store and forward fax means the fax is stored and relayed over data network. This mechanism is typically preferred when a.

  • Page 7: Message Management

    2. [APPLICATION/SF-FAX] P2P type – Set to LOCAL if the call is to be sent to a UCH-300 that has a fax machine connected to RJ11 port. If this is set to OFF, P2P function will not work.
  • Page 8 When incoming message is received from the network, it is put in the Incoming queue. If it cannot be printed for some reason (fax is disconnected, fax is out of paper, fax is turned off), it will be moved to FromNetworkFail Queue. All of these messages in various queues can be managed by pressing the NETWORK action key (6).
  • Page 9 To enable the daisychain capability, the Upstream Serial port has to be configured with two parameters: a. Daisychain: CFCARD b. Signature Wait: 5 Also, the Local CF Card application has to be set to V-MODEM (Virtual Modem). With the popularity of GPS, GPS receivers can be bought on the market fairly inexpensively. The Universal Communication Hub can interface to a NMEA based GPS receiver (for example: http://www.rayming.com/products/tripnav_tn200.htm), either the USB based or Compactflash based, process the information, and communicate that information to configured destination.
  • Page 10 The format of the GPS information includes: Unihub rcv_time, offset from last unihub gps data time, unihub gps message counter, current year based on GPS receiver message current month based on GPS receiver message current day based on GPS receiver message current hours based on GPS receiver message current minutes based on GPS receiver message current seconds based on GPS receiver message...
  • Page 11 As a local port, the Universal Communication Hub can behave like a Wireless LAN Access Point if a PRISM based WIFI compact flash card is plugged in the compact flash slot. Most of the CF based WIFI card are PRISM chipset based, like DLINK DCF-660W. In addition to the Ethernet type of configuration, this port needs ESSID, WEP and Channel configuration.
