Viking SR-IP Product Manual

Designed, Manufactured and Supported in the USA
VIKING
C O M M U N I C A T I O N & S E C U R I T Y S O L U T I O N S
SIP Audible Ringer with Visual Ring Indication
and Remote Strobe Light Control
The SR-IP is a SIP compliant PoE powered audio
device for providing audible and visual ring indication
for SIP VoIP phone systems. When registered with a
SIP server, the SR-IP will ring in one of 4 programmable
ring patterns and flash a bright red LED upon ring
detection. During ring detection the units internal relay
contacts will also activate providing a trigger for a Viking
Model SL -2 Strobe light or LPL-1 visual ring indicator.
Equipped with a high efficiency Class D power amplifier
and high quality loud speaker, the SR-IP is typically
louder than a telephone speaker. The advanced
features of the SR-IP include programmable Automatic
Gain Control (AGC) technology which automatically
increases ring volume to compensate for moderate
background ambient noise. The AGC feature is ideal for
Installation requires the assistance of a Network Administrator / IT Technician.
!
Features
• Programming software included
• 2 Amp relay contacts for Viking LPL-1or SL-2 strobe
light control
• Bright red visual ring indicator LED
• SIP compliant (see page 2 for list of compatible IP-PBX
phone systems)
• PoE powered (class 2, <6.5 watts)
• Automatic Gain Control (AGC) to automatically increase
ring volume to compensate for ambient noise
• Network downloadable firmware
• Surface mounts to a single gang or 4" x 4" electrical box or
directly to a wall or post
• Remotely programmable
• Extended temperature range (-40°F to 140°F)
• Remotely adjust ringer volume
• Four programmable ring cadences: normal (2 sec ON / 4
sec OFF), double, short-short-long, short-long-short
• Optional LPL-1 Remote Visual Ring Indicator (DOD# 640)
• Optional SL-2 (DOD# 242) or BLK-4-EWP (DOD# 654)
strobe light kits available
• Diagnostics (for testing mic, speaker & relay)
PRODUCT MANUAL
variable noise environments (offices, classrooms,
restaurants, etc.), and ensures that ringing is heard but
not unnecessarily loud.
• Ringer for variable noise enviroments
• Visual Ring Indicator for quiet areas
Power: PoE class 2 (<6.5 watts)
Maximum Sound Pressure: 93 dB SPL @ 1m.
applications requiring louder ring, see Viking model PA-IP.
Relay Output: SPDT contact , 2A @30VDC / 250VAC max
Dimensions: 140mm x 115mm x 38mm (5.5" x 4.5" x 1.5")
Operating Temperature: -40° C to 60° C (-40°F to 140°F)
Humidity: 5% to 95% non-condensing
Audio Codecs: G711u, G711a, G722
Network Compliance:
RFC3261, 100BASE-TX with auto cross over
Connections: (1) RJ45 10/100 Base-T, (3) gel-filled butt
connectors
Applications
(Offices, Classrooms, etc.)
(Hospitals, Churches, Theaters, etc.)
www.vikingelectronics.com
Information: (715) 386-8861
Specifications
SR-IP
SIP Audible Ringer/
Visual Ring Indicator
August 23, 2017
IEEE 802.3 af PoE, SIP 2.0
Note: For
