B L U E T A K E
BT007Si / BT009Si
Bluetooth USB Adapter
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BT007Si and is the answer not in the manual?

Questions and answers

Related Manuals for Bluetake Technology BT007Si

Summary of Contents for Bluetake Technology BT007Si

  • Page 1 B L U E T A K E BT007Si / BT009Si Bluetooth USB Adapter User Manual...
  • Page 2 Bluetake Technology Co., Ltd. Product warranty or service will not be extended if: (1) the product is repaired, modified or alt ered, unless such repair, modification of alteration is authorized in writing by Bluetake ;...

  • Page 3: Table Of Contents

    BLUETAKE BT007Si / BT009Si Bluetooth USB Adapter – User Manual Contents Getting Start……………………………………..……………….4 Package Checklist……………………………………………….4 1. Introduction……………..…………………………5 1.1 Safety Precautions…………………….………………………………..6 1.2 System Requirements…………..…………………….…………….…...6 1.3 Product Specification……………….…………………………………...7 2. Bluetooth Software Installation………..…….8 2.1 Install the Software……………………………………………………….8 2.2 Insert the Bluetooth USB Adapter……………………………………..9 3.
  • Page 4 BLUETAKE BT007Si / BT009Si Bluetooth USB Adapter – User Manual 4. Bluetooth Service Usage…………………..…..25 4.1 AV Headphone…………………………………………………………...25 4.2 Basic Imaging……………………………………………………………26 4.3 Dial-up Networking…………………………………..………………….27 4.4 FAX…………………………………………………………………………29 4.5 File Transfer………………………………………………………………29 4.6 Headset……………………………………………………………………33 4.7 Human Interface Device………………………………………………..34 4.8 LAN Access………………………………………………………………35 4.9 Object Push………………………………………………………………38 4.10 Personal Area Networking……………………………………………..42...

  • Page 5: Getting Start

    BLUETAKE BT007Si / BT009Si Bluetooth USB Adapter – User Manual Getting Start ® Thank you for purchasing this versatile Bluetooth wireless communication product manufactured by Bluetake Technology Co., Ltd. Before starting, please read this User Manual carefully to understand how to properly setup and use this product.

  • Page 6: Introduction

    BLUETAKE BT007Si / BT009Si Bluetooth USB Adapter The BLUETAKE BT007Si / BT009Si Bluetooth USB Adapter is a compact and multipurpose product providing an efficient and easy solution for wireless applications.

  • Page 7: Safety Precautions

    BLUETAKE BT007Si / BT009Si Bluetooth USB Adapter – User Manual 1.1 Safety Precautions Please follow the safety precautions carefully before you use the “Bluetooth USB Adapter” device and the application software. Please make sure that you use the product correctly.

  • Page 8: Product Specification

    BLUETAKE BT007Si / BT009Si Bluetooth USB Adapter – User Manual 1.3 Product Specification Product BLUETAKE BT007Si / BT009Si Bluetooth USB Adapter General Radio - BT007Si: Bluetooth Class I, up to 100 meters radio coverage in open space - BT009Si: Bluetooth Class II, up to 10 meters radio coverage in open space - Carrier Frequency: 2.4 ~ 2.483GHz...

  • Page 9: Bluetooth Software Installation

    IMPORTANT! If you have any Bluetooth software previously installed on your computer, you must completely remove it first! 1. Insert the BT007Si / BT009Si Utility CD into the CD drive of your computer. The install application will automatically start. (If the install application does not stat automatically, please open “My Computer”...

  • Page 10: Insert The Bluetooth Usb Adapter

    BLUETAKE BT007Si / BT009Si Bluetooth USB Adapter – User Manual 2.2 Insert the Bluetooth USB Adapter IMPORTANT! Be sure to install the BlueSoleil Bluetooth software and restart the computer BEFORE you insert the Bluetooth USB adapter! [Windows XP/2000/ME/98SE operating system] 1.
  • Page 11 Bluetooth USB adapter. 2. Insert the USB adapter into the USB port of your computer. 3. The Hardware Update Wizard will automatically start and install the BT007Si / 009Si driver, after driver is installed, a “Bluetooth started” screen will shown on...

  • Page 12: Bluesoleil Console

    BLUETAKE BT007Si / BT009Si Bluetooth USB Adapter – User Manual 3. BlueSoleil Console BlueSoleil is an Windows-based software from IVT that allows your Bluetooth® enabled desktop or notebook computer to wirelessly connect to other Bluetooth enabled devices. BlueSoleil allows MS Windows users to wirelessly access a wide variety of Bluetooth enabled digital devices, such as cameras, mobile phones, headsets, printers, and GPS receivers.
  • Page 13 BLUETAKE BT007Si / BT009Si Bluetooth USB Adapter – User Manual √ File Transfer √ √ Headset* √ √ Human Interface Device √ LAN Access √ √ Object Push √ √ Personal Area Networking √ √ Printer √ Serial Port √...

  • Page 14: Bluesoleil Main Window

    BLUETAKE BT007Si / BT009Si Bluetooth USB Adapter – User Manual 3.2 BlueSoleil Main Window By default, BlueSoleil starts with the Main Window open. Use the Main Window to perform your primary connection operations. The Main Window displays the local device (red ball) as well as the remote devices detected in range. Different icons distinguish different types of remote devices.

  • Page 15: Start Bluesoleil

    BLUETAKE BT007Si / BT009Si Bluetooth USB Adapter – User Manual Services — Icon Meanings White — Idle. The normal state. Yellow — Available. The service is available on the selected device. Green — Connected. The service is active in a connection with the remote device.

  • Page 16: Search For Other Bluetooth Enabled Devices

    BLUETAKE BT007Si / BT009Si Bluetooth USB Adapter – User Manual 3.4 Search for Other Bluetooth Enabled Devices Before it can connect, your computer must first detect other Bluetooth enabled devices in range. 3.4.1 Initiate a Device Search 1. Make sure that the Bluetooth enabled device you wish to connect to is turned on, with sufficient battery power, and set in discoverable mode.
  • Page 17 BLUETAKE BT007Si / BT009Si Bluetooth USB Adapter – User Manual 3. After a few seconds, an icon will appear around the center ball for each Bluetooth enabled device detected within the radio range. Note: - The Main Window can display only eight discovered devices at a time. If BlueSoleil discovered more than eight devices, use the scroll bar to view the remaining devices discovered by BlueSoleil.

  • Page 18: Establish Connection

    BLUETAKE BT007Si / BT009Si Bluetooth USB Adapter – User Manual - If you start another search by pressing F5, then the list of previously detected devices will be cleared. 3.5 Establish Connection Note: These are generic instructions for any type of Bluetooth enabled device. Refer to the instructions in Chapter 4 for specific details for the type of service you plan to use.
  • Page 19 BLUETAKE BT007Si / BT009Si Bluetooth USB Adapter – User Manual 2. If the icon for a service is highlighted (yellow), then the service has already been started. If the icon is white, then you need to start the service in order to use it.
  • Page 20 BLUETAKE BT007Si / BT009Si Bluetooth USB Adapter – User Manual 1. Return to the Main Window. Click View | Main Window. 2. Double-click on the icon for the device you wish to connect to. BlueSoleil will begin to search for information about which services the device supports.
  • Page 21 BLUETAKE BT007Si / BT009Si Bluetooth USB Adapter – User Manual 3. After the search, icons will be highlighted (yellow) at the top of the BlueSoleil Main Window for services that are supported by the device. Verify that the service you want to use is supported.
  • Page 22 BLUETAKE BT007Si / BT009Si Bluetooth USB Adapter – User Manual 7. When the devices have successfully connected, the device icon in the Main Window will turn green, and a green line will appear between the red ball and the device icon. A red dot will travel along the green line from the client to the server.
  • Page 23 BLUETAKE BT007Si / BT009Si Bluetooth USB Adapter – User Manual Note: You can only disconnect this way if your computer is acting as a client device. If your computer is acting as a server device, then you can disconnect in BlueSoleil by clicking View | Service Window, then right-clicking on the service icon.

  • Page 24: Bluetooth Security

    BLUETAKE BT007Si / BT009Si Bluetooth USB Adapter – User Manual 3.6 Bluetooth Security To modify your connection’s security settings, click My Bluetooth | Security. BlueSoleil offers three security levels: Low (Security Mode 1, Non-secure) No security procedure is needed for connections.
  • Page 25 BLUETAKE BT007Si / BT009Si Bluetooth USB Adapter – User Manual Note: In Security Mode 2, the user can add each authenticated device into a trusted device list to expedite future connections.

  • Page 26: Bluetooth Service Usage

    BLUETAKE BT007Si / BT009Si Bluetooth USB Adapter – User Manual 4. Bluetooth Service Usage 4.1 AV Headphone The AV Headphone Profile enables use of a Bluetooth enabled headphone to listen to high-quality stereo music played on a computer. Typical Usage - Listen to music using a Bluetooth enabled AV headphone.

  • Page 27: Basic Imaging

    BLUETAKE BT007Si / BT009Si Bluetooth USB Adapter – User Manual 4.2 Basic Imaging The Basic Imaging Profile (BIP) enables users to receive pictures from a Bluetooth enabled digital camera, mobile phone, or other compatible device. It also enables remote control of shooting, display, and other imaging functions.

  • Page 28: Dial-Up Networking

    BLUETAKE BT007Si / BT009Si Bluetooth USB Adapter – User Manual - Receive Pictures Step 1: Assign the directory where you would like to save image files pushed from the client device. Click My Services | Properties. Click on the Basic Image Push tab. In the Set the image directory field, browse to select the file location.
  • Page 29 BLUETAKE BT007Si / BT009Si Bluetooth USB Adapter – User Manual Note: After you successfully connect, you can also select Save Connection As Shortcuts to create a desktop dial-up shortcut. This would allow you to conveniently dial up and connect by simply clicking on the shortcut, without having to manually start BlueSoleil.

  • Page 30: Fax

    BLUETAKE BT007Si / BT009Si Bluetooth USB Adapter – User Manual 4.4 FAX The Bluetooth Fax Profile enables users to send faxes from a computer via a Bluetooth enabled mobile phone or modem. Typical Usage - Send fax via a Bluetooth enabled mobile phone.
