Summary of Contents for Bluetake Technology BT007Ex
- Page 1 B L U E T A K E BT007Ex / BT009Ex Enhanced Data Rate (EDR) Bluetooth USB Adapter User Manual...
- Page 2 Bluetake Technology Co., Ltd. Product warranty or service will not be extended if: (1) the product is repaired, modified or alt ered, unless such repair, modification of alteration is authorized in writing by Bluetake ;...
-
Page 3: Table Of Contents
BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual Contents Getting Start……………………………………..……………….3 Package Checklist……………………………………………….3 1. Introduction……………..…………………………4 1.1 Safety Precautions…………………….………………………………..5 1.2 System Requirements…………..…………………….…………….…...5 1.3 Product Specification……………….…………………………………...6 2. Bluetooth Software Installation………..…….8 2.1 Install the Software……………………………………………………….8 3. Toshiba Bluetooth Utility Contents………..10 3.1 Bluetooth Functions………………………………………………….10 3.2 Introduction of the Bluetooth Utility Contents…………………..12... -
Page 4: Getting Start
BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual Getting Start ® Thank you for purchasing this versatile Bluetooth wireless communication product manufactured by Bluetake Technology Co., Ltd. Before starting, please read this User Manual carefully to understand how to properly setup and use this product. -
Page 5: Introduction
Any digital device that utilizes the Bluetooth wireless technology will be able to take advantage of this technology. BLUETAKE BT007Ex/BT009Ex Bluetooth EDR USB Adapter The BLUETAKE BT007Ex/BT009Ex Bluetooth EDR USB Adapter is a compact and multipurpose product providing an efficient and easy solution for wireless applications. -
Page 6: Safety Precautions
BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual 1.1 Safety Precautions Please follow the safety precautions carefully before you use the “Bluetooth EDR USB Adapter” device and the application software. Please make sure that you use the product correctly. Please follow regional rules for Bluetooth wireless technology use. -
Page 7: Product Specification
BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual 1.3 Product Specification 1.3.1 General Specification - General Radio: Bluetooth Class 1: 100 meters (300 feet) in open space - Carrier Frequency: 2.4 ~ 2.483GHz - Data Rate: Up to 3Mbps - Bluetooth Standard: Bluetooth v2.0 + EDR (Enhanced Data rate) - Page 8 BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual - Toshiba Bluetooth Stack for Windows supported Profiles Operation Systems Profiles Descriptions Windows Windows XP/2000 98SE/ME Serial Port Dial Up LAN access (Bluetooth v1.1) Mouse, keyboard and others HCRP Printing Object push...
-
Page 9: Bluetooth Software Installation
BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual 2. Bluetooth Software Installation 2.1 Install the Software IMPORTANT! If you have any Bluetooth software previously installed on your computer, you must completely remove it first! Please insert the Utility CD into your CD-ROM drive, and then follow the instruction below to install Bluetooth software: Note: DO NOT plug the USB Dongle/Adapter into the USB port before software installation. - Page 10 BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual 4. As prompted, plug the BT007Ex/BT009Ex while the installation ask you to plug the USB adapter. When software installation is complete, restart your computer. 5. Af ter the computer is restarted, you can see the “Bluetooth” icon added at the ndows toolbar.
-
Page 11: Toshiba Bluetooth Utility Contents
BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual 3. Toshiba Bluetooth Utility Contents Toshiba Bluetooth Utility is an Windows-b ed software from Toshiba that allo your Bluetooth® enabled desktop or noteboo k computer to wirelessly connect to other Bluetooth enabled devices. Toshiba... - Page 12 BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual Operation Systems Profiles Descriptions Roles Windows Windows XP/2000 98SE/ME Dev A. Serial Port Dev B. Dial Up LAN access (Bluetooth v1.1) Mouse, keyboard Host and others HCRP Printing Client Client Object push...
-
Page 13: Introduction Of The Bluetooth Utility Contents
BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual 3.2 Introduction of the Bluetooth Utility Co ntents The B luetooth Utilit y is a software tool use d to configur e a variet y of settin gs once a connection has been established between the PC and the Bl uetooth de ice. - Page 14 BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual 3.2.2 Bluetooth Manager This program, which appears as a Taskbar icon, monitors and controls the operating status of Bluetooth devices. It can be used to start the Bluetooth Setup Utility, add a new connection, disconnect from a remote device, and perform other tasks.
-
Page 15: Remote Camera
BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual 3.2.4 Remote Camera Connecting to a Bluetooth - compatible digital camera allows the device to be operated from the PC side, and captured images to be sent to the PC. 3.2.5 Bluetooth Local CO... - Page 16 BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual 3.2.7 On-Line User guide When you have troubles in usin g Toshiba Bluetooth stack, you can easily get on-line help by click: [help => help].
-
Page 17: Toshiba Bluetooth Stack Console
BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual 4. Toshiba Bluetooth Stack Console 4.1 Toshiba Bluetooth setting shiba Bluetooth setting starts can open with the Main Window. Use the Main Window to perform your primary con nection operations or others setting. The Mai Window displays the local device as w ell as the remote devices detected. -
Page 18: Express Mode Setup
BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual several services (profiles) are supported in the device, the service that has n set to the highest priority shall be selected and registered. press Mode is normally recommended for device set-up. •... - Page 19 BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual 2. The [B luetooth Settings] window below will appear when other devices have alread y been registered. 3. Please click the [New Connection] button to open the [Add New Connection Wizard] window. If no devices have been regis tered yet, please proceed directly to "Detecting Bluetooth Devices."...
- Page 20 BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual 3. Searching for Bluetooth devices will start. 4. When the mouse has been detected, the name and address of the device will appear in the [Add New Connection Wizard (Select Device)] window.
- Page 21 BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual Note: If no device is found, please confirm that the device has been made connectable via Bluetooth, and click on the [Update] button. A further device search will be performed. 4.2.3 Detecting services 1.
- Page 22 BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual Note: If several services (profiles) are supported by the device, the service that has been set to the highest priority shall be automatically selected and set up in Express Mode. Please use Custom Mode if you wish to select desired services manually.
- Page 23 BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual Note: If you wish to chan ge the icon, please click on the [Chan ge Icon] button and select your pr eferred icon from the list that appears.
- Page 24 BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual 4.2.4 Registering settings information 1. Click on the [F inish] button. 2. The [Bluetooth Settings] window will appear. T he icons of the registered devices will appear, and the devic es will be ready to use.
-
Page 25: Custom Mode Setup
BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual 4.3 Custom Mode Setup 4.3.1 Starting Bluetooth Settings 1. Click [Start]→[All Programs]→[Bluetooth]→[Bluetooth Settings]. (Under Windows 2000, click [Start]→[Programs]→[Bluetooth]→[Bluetooth Settings].) Note: T he same result can be achieved by right-clickin g on the Bluetooth icon in the... - Page 26 BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual Please click the [New Connection] button to open t he [Add New Connection Wizard] window. If no devices have been registered yet, please proceed directly to "Detecting Bluetooth Devices." .3.2 Detecting Bluetooth devices .
- Page 27 BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual 3. Searching for Bluetooth devices will start. When the mouse has been detecte d, the name and address of the device will appear in the [Add New Connection Wizard (Select Device)] window.
- Page 28 BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual 4.3.3 Detecting services 1. Select the mouse device name from [Device List] and click on the [Next] button. 2. Bluetooth device detection will commence.
- Page 29 BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual Note: When a service has been detected, a window prompting you to enter the Bluetooth passkey (PIN code) may appear. Please enter the passkey and click on the [OK] button. Please refer to yo...
- Page 30 BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual 3. Select the desired service and click on the [Next] button. Note: When a devic e supports several services: If the device su pports several services, you c an use Custom Mode to...
- Page 31 BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual Note: When the settings information has been registered, a window prompting you to enter the Bluetooth passkey (PIN code) may appear. Please enter the passkey and click on the [OK] button. Please refer to your device instruction manual for information on which passkey to use.
- Page 32 BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual Note: If you wish to change the icon, please click on the [Change Icon] button and select your preferred icon from the list that appears. 4.3.4 Registering settings information 1. Click on the [F inish] button.
- Page 33 BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual 2. The [Bluetooth Settings] window will appear. The icons of the registered devices will appear, and the devices will be ready to use.
- Page 34 BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual 5. Bluetooth Service Usage 5.1 Connecting to internet...
- Page 35 BLUETAKE BT007Ex/BT009Ex Bluetooth USB Adapter – User Manual Federal Communications Commission (FCC) Statement RADIO FREQUENCY INTERFERENCE BTATEMENT This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation.
