Ainol NOVO 7 Crystal Owner's Manual

Quad core 7" display
Hide thumbs
Table of Contents

Advertisement

Quick Links

Enjoy Life Enjoy AINOL
Firstly thanks a lot for using Ainol digital products--NOVO 7 Crystal Quad core Tablet PC, sincerely hope you can enjoy it. This
manual will introduce the feature of this product that allows you to fully understand how to use it. For your ease to operate the
device as soon as possible, please read the instructions before using the machine so that you can properly use it!
1、It is based on Android 4.1 operating system that supports wireless Internet
2、It use 7.0-inch HD screen 1024*600 resolution
3、Camera: Front 0.3 Mega Pixel
4、It supports five points capacitive touch screen and button operation.
5、The CPU is: ATM7029 ARM cortex A9 Family Quad core.
6. 1.0 GB DDR3 RAM and 1.0 GB ROM.
7、The picture used in the manual may be different from UI in the device, please subject to the device!
Preface
1
-
- www.ainol.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NOVO 7 Crystal and is the answer not in the manual?

Questions and answers

Related Manuals for Ainol NOVO 7 Crystal

Summary of Contents for Ainol NOVO 7 Crystal

  • Page 1 Preface Firstly thanks a lot for using Ainol digital products--NOVO 7 Crystal Quad core Tablet PC, sincerely hope you can enjoy it. This manual will introduce the feature of this product that allows you to fully understand how to use it. For your ease to operate the device as soon as possible, please read the instructions before using the machine so that you can properly use it! 1、It is based on Android 4.1 operating system that supports wireless Internet...
  • Page 2 Enjoy Life Enjoy AINOL Content P r e f a c e ..........0 1 S e t t i n g .
  • Page 3 Enjoy Life Enjoy AINOL Accessories: If there is any change, we will advise Quad core Novo7 Crystal - www.ainol.com...

  • Page 4: Main Function

    Enjoy Life Enjoy AINOL I.Main function ● 7.0 inch HD Display 1024*600 resolution； ● Support Android 4.1 operating system; ● Support APK application and installation ● Support 1080P full HD format video play; ● Support G-Sensor for screen rotation function;...
  • Page 5 Enjoy Life Enjoy AINOL ● Support firmware upgrade; ● Support multi-task, can read eBook while listening to music II、Note This manual contains important safety measures and information to use the product correctly. In order to avoid using improperly, please read the manual carefully before using it.
  • Page 6 Enjoy Life Enjoy AINOL  When the device is formatting, uploading or downloading documents do not disconnect it suddenly. Otherwise it will probably lead to player failure. We are not responsible for any document losses incurred by damage and repair the machine or other reasons.

  • Page 7: Basic Operation

    Enjoy Life Enjoy AINOL  The product performance and functionality may be different with different version of software. We’ll not give further notice. The company reserves the right to improve the product. III、Basic Operation ● Power On/ OFF Power On: In the turn-off status, press the power button for 3 seconds, the unit will enter the main interface after the boot.
  • Page 8 Enjoy Life Enjoy AINOL Main Screen Button operation: : Enter the main screen : Check the history record : Return to main Interface from any Interface : Return to last layer Main Interface operation: Clicking at any point in the center of the main interface can set he wallpaper.
  • Page 9 Enjoy Life Enjoy AINOL Main Function menu operation: Click this function button, full-featured pop-up menu, such as below: This window shows all the features of the machine icon, click on any icon to access the relevant function interface, click on the main interface key to return to the main interface.

  • Page 10: Hd Media Player

    Enjoy Life Enjoy AINOL IV、Emails Click “emails” to enter user account interface and then log in to send and receive emails. (Require to register a google account) V、HD Media Player On the main screen click on "HD media player" option, you can access the video files list interface, the point of a video can be selected into the video player interface.
  • Page 11 Enjoy Life Enjoy AINOL Ⅵ、Calculator In the main menu interface, click the "calculator" option, you can enter the calculator display screen, click on the numbers and operators, can be "add, subtract, multiply, divide," Browser Under the main menu, click “Browser" to enter into the internet interface. The default home page of this device is “Google”.
  • Page 12 Enjoy Life Enjoy AINOL check webpag bookmark, history record and Saved webpage enter the interface of browser setting pop up the keyboard for searching content add the current webpage as bookmark Click icon to hide the keyboard after puting in the website, click to enter the webpage.
  • Page 13 Enjoy Life Enjoy AINOL VIII、Setting In the main menu click the “setting “option can enter the system menu setting interface 1. Wireless and network Wi-Fi: turn on/off WI-FI Click “scan” to scan all the WIFI networks available within the range Click”...
  • Page 14 Enjoy Life Enjoy AINOL then click “ connect”to set this network as current online network. to pop up “advanced settings interface” for advanced setting Click Flow status: check the flow status More: set air mode,VPN and mobile network 2. Device:...
  • Page 15 Enjoy Life Enjoy AINOL Save document and reset: The user can save personal document and restore the machine to factory state. 4、System The date and time: User can set to automatically gain the data and time from the network, and can also manually set the date / time zone / time / format.
  • Page 16 Enjoy Life Enjoy AINOL X、Search Under the main menu click the “search” into the following interface Under the searching interface, Click to pop up setting Interface, then set searching network and apps. - www.ainol.com...

  • Page 17: Audio Record

    Enjoy Life Enjoy AINOL XI、Audio Record Under the state of main menu, select “Record” option, enter into the Record interface . Click button to start record; Click button to stop record and save it; click to display current recording file.

  • Page 18: App Installer

    Enjoy Life Enjoy AINOL return to previous laye XIII、App Installer This device supports APK installation, uninstallation. Click any APK in the File Management to access installation Interface. Click “installation” to start installing this APK. Uninstallation: enter “applications interface “in the “setting “menu to uninstall the APK XIV、Camera...
  • Page 19 Enjoy Life Enjoy AINOL Click it to change to video Click it to change to photo-taking Enter to the camera interface, click the icon , can be photographed and saved automatically. Top right of screen, click the small icon to view the photos taken. On the right corner of the interface， click to show or hide the camera settings menu.

  • Page 20: Music Player

    Enjoy Life Enjoy AINOL icon in the upper right corner, the recorded video can be played; in the video shown on the right corner of the interface click to show or hide the video settings menu. Click to restore the default settings (as shown).
  • Page 21 Enjoy Life Enjoy AINOL In the music player interface, click the icon or press the Menu button, you can set the pop-music menu, click on "music library, party shuffle, playlist, delete" to enter the setting interface. XVI、OTG Cable: User methods and notice OTG Cable can transmit the data between devices without the HOST.

  • Page 22: Hdmi Output

    Enjoy Life Enjoy AINOL Power on the unit with the external device, choose “USB External device” to enter the interface of the U Disk files list after identifying the U Disk successfully. To disconnect the OTG external device, first disconnect the power supply on the external device, and then disconnect the OTG external device.

  • Page 23: Mobile Storage Function

    The device for high-speed USB2.0 interface, the standard removable disk function, support for Windows98 (need to install the driver), Windows2000/XP/Vista (do not need to install the driver) system, use the USB cable (please try to use the first wife Ainol data line) connected with the PC after (wait a few minutes), the player is displayed as on-line mode;...
  • Page 24 Enjoy Life Enjoy AINOL Copy files / folders Download files from your computer to the player, just simply want to download the file / folder onto your player can move the disk can be the same; you can put players inside the file transfer to your computer Delete a file / folder Select File / folder on the keyboard, press the "Delete (delete)"...
  • Page 25 Enjoy Life Enjoy AINOL power socket with power adapter. When using power adapter to charge the unit, the screen will display charging status. After the charge is finished, the screen will show battery is full. It takes 5 hours to fully charge this unit. (For the first two times, it takes 8 hours to fully activate the battery) XXI、FAQ...
  • Page 26 Enjoy Life Enjoy AINOL the other music. If the file has been damaged, it will lead to very serious tone of the noise or jump. Garbled screen Please check whether it has set the correct language option, the language chosen can set in the (set) =＞(language selection)

  • Page 27: Product Specification

    Enjoy Life Enjoy AINOL XXII、Product Specification Model Number Novo7 Crystal II DDR3 1G Power Input DC 5V 2A Screen Size 7.0 inch HD colors 16millions Operation 5 points capacitive touch screen with button Screen res. 1024*600 USB Connection High speed USB 2.0...
  • Page 28 Enjoy Life Enjoy AINOL WIFI 802.11b/g/n Audio format Support MP3,WAV,(APE,FLAC,AAC,OGG need install the third software) Video format Support MOV,MKV,AVI,TS,TP,M2TS,VOB,DAT,MPEG,MP4,PMP,3GP,FLV,WMV,ASF etc. Photo format JPG、BMP、PNG、GIF Ebook format TXT、LRC、(PDF,EPUB,FB2 need install the third software) Camera Front 0.3 Mega Pixel Temperature Working temperature: -10~45 degree Battery 3.7V, 3700mAh...
