RESOL D e lt a S o l
Pool
®
Mounting
Connection
Operation
Troubleshooting
en-US/CA
Manual
Thank you for buying this RESOL product.
Please read this manual carefully to get the best performance from this unit.
www.resol.com
Please keep this manual carefully.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DeltaSol Pool and is the answer not in the manual?

Questions and answers

Summary of Contents for Resol DeltaSol Pool

  • Page 1 RESOL D e lt a S o l Pool ® Mounting Connection Operation Troubleshooting en-US/CA Manual Thank you for buying this RESOL product. Please read this manual carefully to get the best performance from this unit. www.resol.com Please keep this manual carefully.
  • Page 2: Table Of Contents

    Pool D e lt a S o l ® Table of contents General ................ 2 Buttons for adjustment ........8 Overview of functions and technical data ....3 Control lamp ............8 Menu structure ............. 9 1. Installation ............4 User code ...............
  • Page 3: Overview Of Functions And Technical Data

    • 13 sensor inputs • 7 relay outputs • function control • RESOL VBus ® Scope of delivery: 1 x D e lt a S o l Pool ® 1 x accessory bag 2 x screws and wall plugs...
  • Page 4: Installation

    Pool D e lt a S o l ® Installation WARNING! Electric shock! 1.1 Mounting Opening the housing will expose live parts! push-push locking mechanism Î Switch off power supply and dis- push to open connect the device from power push to close supply before opening the housing! The unit must only be located in dry interior locations.
  • Page 5: Actuators

    4 (1) A (220 ... 240) V~ cover! OK / Set Sammelklemme benutzen 1.2.3 Data communication / bus e Ground Collective Terminal Block The controller is equipped with the RESOL VBus ® for data transfer with and energy supply to external modules. The floating relay electromech.
  • Page 6: Sensors

    Use PE Collective Block Vor Öffnen Gerät spannungslos schalten! R1-R6 2 (1) A (220 ... 240) V~ Isolate mains before removing 4 (1) A (220 ... 240) V~ clamp-cover! Pool D e lt a S o l ® OK / Set Masse-Sammelklemme benutzen Use the Ground Collective Terminal Block 1.2.4 Sensors...
  • Page 7: Basic System

    Pool D e lt a S o l ® 2. Basic system Sensor allocation CS10 release T-return T-absorber T-pool T-flow T-outd. irradiation flow rate filter system (WMZ) switch-extra filter runtime Abbreviations sensors sensor description T-absorber absorber temperature T-pool swimming pool temperature T-flow flow temperature T-outd.
  • Page 8: Operation And Function

    Pool D e lt a S o l ® Operation and function 3.1 Buttons for adjustment The controller is operated via the 3 push buttons below the display. The forward-button (1) is used for scrolling forward through the menu or to increase the adjustment values. The backward-button (2) is similarly used for scrolling backwards control lamp and reducing values.
  • Page 9: Menu Structure

    Pool D e lt a S o l ® 3.3 Menu structure Adjustment and control of the controller are carried out Main menu via the menu. When the controller is commissioned, the Status display level is in the status menu. In the first line of each submenu you will find the option “back”, by means of which it is possible to get to the former menu level.
  • Page 10: Menu Overview

    Pool D e lt a S o l ® 3.5 Menu overview Main menu Status Balance values back Manual operation WMZ1 Adj. values WMZ module User code Options Expert Adjust. values back Poolmax. DT on DT off Min.on Min.off Filtre min. Expert back Adj.
  • Page 11: Commissioning

    Pool D e lt a S o l ® 4. Commissioning Adjust date and time in the Status menu. control lamp forwards (+) (-) backwards SET / OK selection / adjustment mode 5. Functions and options Maximum pool temperature Adjust the maximum pool temperature, in °C. Adj.
  • Page 12 Pool D e lt a S o l ® Minimum filter runtime Adjust the minimum runtime of the filter pump, in hours. Adj. values/Circ. min. The pump will be switched on every day for this period of adjustment range: 0 ... 16 h time.
  • Page 13 Pool D e lt a S o l ® If you select the “Expert” submenu, you can further choose WMZ/WMZ1/Expert between: - Sensor flow/return: here you can re-allocate the sensors, WMZ/WMZ1/Expert/Sen. flow if you do not use the sensors which have already been pre- adjust to “3”...
  • Page 14 Pool D e lt a S o l ® Backup heating optimisation The function starts when the pool is being loaded. Solar loa- ding means that pool loading is only carried out for energy Expert/Options/AH sol. opt. supply and not for cooling purposes etc. and adjust: Backup heating is suppressed when the temperature diffe- Expert/Adj.
  • Page 15 Pool D e lt a S o l ® Pool cooling function If the maximum pool temperature is exceeded by the adjusted value (DT-Cool), heat is diverted, provided that Expert/Options/Pool cool. the absorber is by at least DTCool on colder than the and adjust: pool.
  • Page 16: Messages

    Pool D e lt a S o l ® Reset: The reset option can be selected. When the reset option is selected (“Yes”), the controller settings are set back to the Expert/Options/Reset factory settings. selection: “Yes” or “No”. Language: Language choice: German, English, French, Castellano, Italiano. Expert/Language/English 6.
  • Page 17 Pool D e lt a S o l ® Messages The following states can be displayed: display description normal operation of the system, no malfunction Everything OK controller is switched off Controller off controller has been switched off by the operator >...
  • Page 18: Balance Values

    Pool D e lt a S o l ® 7. Balance values Balance values The values shown on the left can be balanced. Balance/Pool max Balance/Colmax Balance/Flow max Balance/B-rel1 Operating hours of the individual relays. Balance/B-rel2 Balance/B-rel3 Balance/B-rel4 Balance/B-rel5 Balance/B-rel6 Balance/B-rel7 Balance/Oper.
  • Page 19 Pool D e lt a S o l ® In the case of a malfunction, a message is shown on the display of the controller. fuse T4A spare fuse T4A control lamp Control lamp off Operating control lamp flashes red. The symbol are shown.
  • Page 20: Accessory

    Another use outside the copyright re- best of our knowledge. As faults can never be excluded, quires the approval of RESOL - Elektronische Regelungen please note: Your own calculations and plans, under con- GmbH. This especially applies for copies, translations, sideration of the current standards and directions should micro films and the storage into electronic systems.
