  • Page 1 10.1” P-CAP Access Control W10IB3S-PCH2AC & W10IB3S-PCH1AC User Manual Version 1.0...

  • Page 2: Copyright Notice

    Copyright Notice No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer. Trademark Acknowledgement Brand and product names are trademarks or registered trademarks of their respective owners.

  • Page 3: Customer Service

    For example, the serial number 1W14Axxxxxxxx means October of year 2014. Customer Service We provide a service guide for any problem by the following steps: First, visit the website of our distributor to find the update information about the product. Second, contact with your distributor, sales representative, or our customer service center for technical support if you need additional assistance.

  • Page 4: Safety Precautions

    Safety Precautions  Please read these safety instructions carefully.  Please keep this user's manual for later reference.  Please disconnect this equipment from any AC outlet before cleaning. Do not use liquid or spray detergents for cleaning. Use a damp cloth. ...

  • Page 5: Important Information

     Do not leave this equipment in an uncontrolled environment where the storage temperature is below -20° C (-4°F) or above 60° C (140° F). It may damage the equipment.  CAUTION – Use the recommended mounting apparatus to avoid risk of injury. ...

  • Page 6: Declaration Of Conformity (Doc)

    case the user will be required to correct the interference at him own expense. Declaration of Conformity (DoC) [English] The object of the declaration described above [A] is in conformity with the requirement of the following EU legislations [B] and harmonized standards [C]. Product also complies with the Council directions [D].

  • Page 7: Table Of Contents

    Contents Copyright Notice ..............................5 Trademark Acknowledgement ..........................5 Disclaimer ................................5 Warranty ................................5 Customer Service ..............................6 Safety Information ..............................6 Safety Precautions ..............................7 Important Information ............................8 Declaration of Conformity (DoC) .......................... 9 Introduction ................................ 13 Features ................................
  • Page 8 Installation of Audio Driver ..........................46 USB 3.0 Driver Installation ..........................47 Mounting Installation ............................51 PCAP Series Mounting Guide.......................... 51 VESA Mount ..............................51 Flush Mount / Panel Mount: ........................51 Winmate VESA Bracket Mount (Optional): ....................52 SPECIFICATIONS ..............................53...
  • Page 9 Hardware Specifications ..........................53 W10IB3S-PCH2AC ............................53 W10IB3S-PCH1AC ............................54 Restoring Operating System ..........................55 Using Recovery Wizard to Restore Panel PC......................55...

  • Page 10: Introduction

    Introduction Interactive and smart display system of an intelligence building is in a fast growing phase. Winmate Multi Touch Flat Panel PC and Display are suitable for home automation and room management systems. By connecting to centralized database, it can provide real time update for booking status and available schedule, or perform as a synchronous display in meetings.

  • Page 11: Product Overview

    Product Overview Drawing Input / Output Instruction The input / output instruction are as follows: W10IB3S-PCH2AC...
  • Page 12 W10IB3S-PCH1AC...

  • Page 13: Mechanical Dimensions

    Mechanical Dimensions W10IB3S-PCH2AC...
  • Page 14 W10IB3S-PCH1...

  • Page 15: Getting Started

    GETTING STARTED Jumpers Jumper list The following table lists the function of each of the board's jumpers. Label Function Note Inverter Voltage Select 3x1 header , pitch 2.0mm Inverter Enable Select 3x1 header , pitch 2.0mm DC Mode Control 3x1 header , pitch 2.0mm From SoC Brightness PWM Voltage Select 3x1 header , pitch 2.0mm Brightness Control Select...
  • Page 16 JP1 : Inverter Voltage Select JP2 : Inverter Enable Select JP4 : DC Mode Control JP5 : From SoC Brightness PWM Voltage Select...
  • Page 17 JP6 : Brightness Control Select JP7 : Brightness Control to VRD JP8/JP9 : COM Port Select...

  • Page 18: Connectors And Pin Assignments

    JP10 : VRD Brightness Function Connectors and Pin assignments The table below lists the function of each of the board’s connectors. Label Function DC Jack 12V Power Input COM1 RS232/422/485 USB 1/2 USB 3.0/USB2.0 Ports HDMI 1 HDMI Connector ® LAN1 / 2 Intel LAN Ports...

  • Page 19: Com1: Rs232/422/485

    SATA II SATA 2.0 Port SATA Power SATA Power CPU Fan CPU Fan Front Panel System Function (Power / Reset) 3.3V 3.3V Output 5V Output 12V Output GPIO General Purpose I/O 12V DC Input 12V DC Power Input Wafer USB 3/4 USB 2.0 Wafer USB 5/6 USB 2.0 Wafer...

  • Page 20: Usb 1/2: Usb 3.0 (Lower)/Usb2.0 (Upper)Ports

    USB 1/2: USB 3.0 (Lower)/USB2.0 (Upper)Ports Pin Number Signal Name Pin Number Signal Name +5VUSB3.0 +5VUSB2.0 U2DN0 U2DN1 U2DP0 U2DP1 USB_GND USB_GND U3RXDN1 U3RXDP1 USB_GND U3TXDN1 U3TXDP1 HDMI: HDMI Connector Pin No. SYMBOL Pin No. SYMBOL HDMIB_TMDS0+ HDMIB_TMDS0- HDMIB_TMDS1+ HDMIB_TMDS1- HDMIB_TMDS2+ HDMIB_TMDS2- HDMIB_CLK+...

  • Page 21: 1394B (Optional)

    1394b (optional) Pin No. SYMBOL Pin No. SYMBOL 1394b_TPB0+ 1394b_TPA0+ 1394b_TPB0- 1394b_TPA0- +V12S SPK: 2W External Speaker Pin No. SYMBOL Pin No. SYMBOL LOUT+ LOUT- Pin No. SYMBOL Pin No. SYMBOL ROUT+ ROUT- Audio: Line_in / Line_out / Mic_in Pin No. SYMBOL Pin No.

  • Page 22: Vga: Vga Internal Wafer

    VGA: VGA Internal Wafer Pin No. SYMBOL Pin No. SYMBOL DAC_SDAT0 VGA_5V DAC_SCL0 R_FILTER 3VHSYNC0 G_FILTER 3VVSYNC0 B_FILTER LVDS: LVDS Port Pin No. SYMBOL Pin No. SYMBOL LCDVDD TXOUT_L0- LCDVDD TXOUT_L0+ LCDVDD TXOUT_L1- TXOUT_L1+ TXOUT_L2- TXOUT_L2+ TXCLK_L- TXCLK_L+ TXOUT_L3- TXOUT_L3+ TXOUT_U0- TXOUT_U0+ TXOUT_U1-...

  • Page 23: Sata Ii: Sata 2.0 Port

    SATA II: SATA 2.0 Port Pin No. SYMBOL Pin No. SYMBOL SATA_TXP SATA_TXN SATA_RXN SATA_RXP SATA Power Pin No. SYMBOL Pin No. SYMBOL +12V +12V CPU Fan Pin No. SYMBOL Pin No. SYMBOL +12V SENSE...

  • Page 24: Gpio: General Purpose I/O

    GPIO: General Purpose I/O Pin No. SYMBOL Pin No. SYMBOL +V5A DOUT3 DOUT1 DOUT2 DOUT0 DINT3 DINT2 DINT1 DINT0 GPIO53_IN0 GPIO56_OUT0 GPIO54_IN1 GPIO57_OUT1 USB 3/4 (USB 5/6): USB 2.0 Wafer Pin No. SYMBOL Pin No. SYMBOL DATA0- DATA1- DATA0+ DATA1+...

  • Page 25: Com2 (Com3 / Com4): Rs232

    COM2 (COM3 / COM4): RS232 Signal Name Signal Name FK_NDCD[2:4] FK_NDSR[2:4] FK_NSIN[2:4] FK_NRTS[2:4] FK_NSOUT[2:4] FK_NCTS[2:4] FK_NDTR[2:4] FK_NRI[2:4] Using the AC power adapter. Perform the following to connect the Panel PC to AC to DC Adapter: 1. Plug the power cord into the power adapter. 2.

  • Page 26: Ac Adapter Components

    AC adapter components AC to DC 12V power Adapter Power Cord Terminal Block to DC Jack cable Tips for using the AC power adapter ˙Plug the power cord into an AC outlet that is easily accessible at all times. ˙Always plug the AC adapter into a grounded outlet. If you do not use a grounded outlet, you may notice an electrical tingling sensation when the palms of your hands touch the W10IB3S Caution...

  • Page 27: How To Turn On The Device

    product case and/or packaging. • Do not use the adapter if the cord becomes damaged. • Do not attempt to service the unit. There are no serviceable parts inside. Replace the unit if it is damaged or exposed to excess moisture. How to turn on the device Connecting to Power Supply The Panel PC operates on external DC power.

  • Page 28: Software Utilities

    Software Utilities 1. Double click the Hot Tab icon on the windows desktop. 2. The Hot Tab main menu will be shown on the desktop as following image. “Utilities”-Tapping this button will automatically change its orientation from landscape to portrait mode or different degree such as 0∘, 90∘, 180∘, 270∘.

  • Page 29: Led Light Bar

    “Touch lock” Using touch lock button to lock / unlock the touch function. LED Light Bar SDK Porting Guide For the SDK porting guide of LED Light Bar, please click the download path as below to visit our website to download it. http://www.winmate.com.tw/DownCenter/DownLoadCenter.asp?DownType=300301...

  • Page 30: Projected Capacitive Touch

    Projected Capacitive Touch The projected capacitive touch is mainly made up with three components: sensor layer, cover glass, and controller. Within the sensor layer is a matrix of rows and columns of conductive material. When voltage applies through this matrix, a measurable electrostatic field is then created. The cover glass is optically bonded on top of the sensor layer, burying the electrodes within the stack of the lamination.

  • Page 31: Driver Installation

    Driver Installation Installation of Chipset Driver Step.1. Insert the CD that comes with the motherboard. Open the file document “Chipset Driver”. Step.2. Click on “infinst_auto.exe“ to install drive...
  • Page 32 Step.3. Click on “Yes “ to” agree License Step.4. Click on “Next“ to install driver.
  • Page 33 Step.5. Click on “Next“ to install driver. Step.6. Click on “Yes, I want to restart this computer now“ to go on.

  • Page 34: Installation Of Graphic Driver

    Installation of Graphic Driver IB32 Motherboard is equipped with Intel SoC Integrated Device. The Intel Graphic Drivers should be installed first, and it will enable “Video Controller (VGA compatible). Follow the instructions below to complete the installation. You will quickly complete the installation. Step.1.
  • Page 35 Step.3. Click on “Next “ to install Driver. Step.4. Click on “Yes “ to agree License.
  • Page 36 Step.5. Click on “Next “ to install Driver. Step.6. Click on “Next “ to install Driver.
  • Page 37 Step.7. Click on “Yes, I want to restart this computer “ now“ to go on.

  • Page 38: Panel Resolution Setting

    Panel Resolution Setting Step.1. Right-click the desktop, and then click Properties. Step.2. In the Display Properties dialog box, click the Settings tab. Step.3. Click on “Monitor”.
  • Page 39 Step.4. Click on “Hide modes that this monitor cannot display” to remove this option. Step.5. Click on “Setting”, then could choose 32bit color qualify...

  • Page 40: Installation Of Ethernet Driver

    Installation of Ethernet Driver The Users must make sure which operating system you are using in the IB32 Motherboard before installing the Ethernet drivers. Follow the steps below to complete the installation of the Intel WG82574L Gigabit Ethernet controller LAN drivers. You will quickly complete the installation.
  • Page 41 Step.3. Click on “Update Driver” to execute the setup. Step.4. Click on “Browse my computer for driver software “ to install driver.
  • Page 42 Step.5. Choose the path to install driver. Step.6. Click on “Close “ and go on.

  • Page 43: Audio Driver Introduction

    Audio Driver Introduction The ALC886 series are high-performance 7.1+2 Channel High Definition Audio Codecs providing ten DAC channels that simultaneously support 7.1 sound play back, plus 2 channels of independent stereo sound output (multiple streaming) through the front panel stereo outputs. The series integrates two stereo ADCs that can support a stereo microphone, and feature Acoustic Echo Cancellation (AEC), Beam Forming (BF), and Noise Suppression (NS) technology.

  • Page 44: Usb 3.0 Driver Installation

    Step.3. Click on “Yes, I want to restart my computer now” to finish installation USB 3.0 Driver Installation IH32 Motherboard is designed with Intel mobile Core i5 dual core CPU with the Intel® USB 3.0 extensible Host Controller. You need to install the Intel® USB 3.0 extensible Host Controller driver to enable the function.
  • Page 45 Step.3. Click “Next” to continue. Step.4. Read License Agreement and click “Yes” to proceed.
  • Page 46 Step.5. Review Readme File Information and click “Next” to proceed. Step.6.When the “Setup Progress” is complete click “Next” to proceed.
  • Page 47 Step.7. When the “Setup Progress” is complete click “Next” to proceed. Step.8. Lastly, the “Setup Complete” screen appears so click “Finish” to restart your computer.

  • Page 48: Mounting Installation

    Mounting Installation PCAP Series Mounting Guide P-CAP Series is suitable for most of the industrial/commercial application, by any kind of mounting approach. The main mounting Approaches, such as chassis, is very easy for user to install as the pictures guided. VESA Mount •...

  • Page 49: Winmate Vesa Bracket Mount (Optional)

    Winmate VESA Bracket Mount (Optional): 1. Screw Winmate VESA Bracket to the fixture (ex. Wall) with M4 flat head screws. 2. Place the 10.1” panel PC on VESA bracket. Please notice that both hooks on bracket should lock the notches on panel PC back cover.

  • Page 50: Specifications

    SPECIFICATIONS Hardware Specifications W10IB3S-PCH2AC System : ® Processor ® Intel Celeron Bay Trail-M N2930 1.83GHz ® System Chipset Intel ATOM SoC Integrated System Memory 4GB DDR3L 1066/1333 SO-DIMM Storage 64GB mSATA SSD Dual Intel® WG82574L GbE LAN Display Spec Size/Type 10.1"...

  • Page 51: W10Ib3S-Pch1Ac

    W10IB3S-PCH1AC System : ® ® Processor Intel Celeron Bay Trail-M N2930 1.83GHz ® System Chipset Intel ATOM SoC Integrated System Memory 4GB DDR3L 1066/1333 SODIMM Storage 64GB mSATA SSD Dual Intel® WG82574L GbE LAN Display Spec Size/Type 10.1" TFT (Wide screen) Resolutions 1024x600 Brightness...

  • Page 52: Restoring Operating System

    Restoring Operating System Using Recovery Wizard to Restore Panel PC Our system has a dedicate recovery partition stored on the hard drive of the PC to enable quick one-key recovery process. This partition occupies about 11GB of the storage space, and comes built-in to each Panel PC.
  • Page 53 Wait till the recovery process to complete. During the recovery process, a command prompt will show up to indicate the percent of recovery process. After recovery process is completed, the computer will restart automatically...
