Celsus Sound Companion One Manual page 12

6. Volume Control – is divided into 100 steps.
Press once to change the volume by one step.
Press and hold changes volume rapidly. Vol+：
Step 1 to 30, press once to increase by 1.5dB;
steps 31 to 100 by 0.5dB. Vol-：Press once to
decrease by 0.5dB from vol 100 to 31 and 1.5dB
from vol 30 to 0.
7. I/O:
a. Power Input – Charging input. Using DC
5V/1250mA, charging the 6000mAh Lithium
Ion battery takes about 8 hours.
b. USB Audio Input – USB audio from
Android, iOS, MAC or PC is decoded for
high-resolution music.
c. Headphone Output – Able to drive 16 to 300
Ohm earphones.
d. Line Output
e. Toslink SPDIF
8. Client Connection procedures:
a. Connect to Companion One using AP mode
and SSID "Companion One". The default IP
address is 192.168.10.1
b. Access
http://192.168.10.1 from a browser.
c. Choose the home WiFi network SSID and
configure the password for Companion One
to connect to your home WiFi network when it
is in the client mode. You will hear the voice
www.celsus-sound.com
the web
& www.celsussound.com
Celsus Sound
interface at
13
