Configuration Manual
SHENZHEN C‐DATA TECHNOLOGY CO., LTD.
Company Address: Flat 6, Bldg 4,South 2 of Honghualing Industrial Zone,Liuxian Road, Xili Town,
Shenzhen, Guangdong, China(518055)
Tel: +86‐755‐26014509/4710/4711
Fax:+86‐755‐26014506
Website: www.cdatatec.com
Company Address: Flat 6, Bldg 4,South 2 of Honghualing Industrial Zone,Liuxian Road, Xili Town, Shenzhen, Guangdong, China(518055)
Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506
Website: www.cdatatec.com
FD1216S EPON OLT
CLI User Manual
versions：V1.0
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for C-Data FD1216S
Summary of Contents for C-Data FD1216S
- Page 1 FD1216S EPON OLT CLI User Manual versions：V1.0 SHENZHEN C‐DATA TECHNOLOGY CO., LTD. Company Address: Flat 6, Bldg 4,South 2 of Honghualing Industrial Zone,Liuxian Road, Xili Town, Shenzhen, Guangdong, China(518055) Tel: +86‐755‐26014509/4710/4711 Fax:+86‐755‐26014506 Website: www.cdatatec.com ...
- Page 2 I may not be able to notify all users timely, you can contact with the product sellers or my company to relevant personnel or visit our website www.cdatatec.com for information. Document description This manual applies to west dieter FD1216S EPON OLT products, this manual is only as part of the equipment of user manual and document content including instructions for equipment command line management, users should read the information before using EPON OLT equipment. Company Address: Flat 6, Bldg 4,South 2 of Honghualing Industrial Zone,Liuxian Road, Xili Town, Shenzhen, Guangdong, China(518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website: www.cdatatec.com...
-
Page 3: Table Of Contents
CATALOGUE ©STATEMENT .......................... 1 1.1 Summary of the command line view .................. ... - Page 4 5.2 load configuration ........................ 2 1 5.3 show current‐config ......................... 2 2 5.4 save ............................ 2 2 5.5 erase saved‐config ........................ 2 2 5.6 show saved‐config ........................ 2 3 .......................... 2 3 USERS MANAGEMENT 6.1 user add ............................ 2 4 7.1 shutdown .......................... 2 4 7.2 no shutdown ...
- Page 5 .......................... 4 3 ‐ IGMP SNOOPING 【 】 .......................... 4 3 Command igmp‐snooping enable ........................ 4 3 9.2 igmp‐snooping fast‐leave ...................... 4 3 9.3 igmp‐snooping host‐aging‐time .................... 4 4 9.4 igmp‐snooping router‐aging‐time .................... 4 4 9.5 igmp‐snooping querier ...................... 4 4 9.6 igmp‐snooping querier interval .................... ...
- Page 6 .......................... 6 8 DHCP‐ SNOOP 13.1 dhcp‐snooping enable ...................... 6 8 13.2 dhcp‐snooping disable ...................... 6 8 13.3 show dhcp‐snooping configuration .................. 6 9 13.4 dhcp‐snooping vlan ........................ 6 9 13.5 dhcp‐snooping trust port ...................... 7 0 13.6 dhcp‐snooping chaddr‐check .................... 7 0 13.7 dhcp‐snooping limit‐rate ...................... 7 1 13.8 dhcp‐snooping option82 ...
- Page 7 17.7 commit ........................... 9 1 ........................... 9 1 18.ONT MANAGEMENT 18.1 ont add ........................... 9 1 18.2 ont confirm .......................... 9 2 18.3 ont cancel .......................... 9 2 18.4 ont delete .......................... 9 3 18.5 ont description ........................ 9 3 18.6 ont autofind .......................... 9 4 18.7 ont active .......................... 9 4 18.8 ont deactive ...
- Page 8 The book contract The command line agreement Format Meaning Bold Key words of command line(The part of keeping same,and according to the part of input) must make bold Italic Command line arguments(the part according to real dates to replace in the commands) The selected parts in `[]` (X∣Y∣...)
- Page 9 Term contract OLT：On behalf of FD1216S system, including the part connected to the switch, top allied equipment mouth and exchange of the main processing module PON：On behalf ofpon protocol processing module and the pon port connected to the onu.
- Page 10 1.The command line interface view ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ The switch view and view instructions：This command line environment is divided into multiple views ,including: View model，The following called view or user mode,enter it After inputting password, The model can perform the most simple commands.the view are as follows: OLT > ...
-
Page 11: Summary Of The Command Line View
1.1 Summary of the command line view Serial interface (The bits per second: PuTTY 9600 (telnet) Data bits: 8 Parity :none The login: Stop bits: 1 user:root password:admin View: OLT> enable Enableview OLT# config Global configuration model OLT(config)# GE interface GPONinterfac Ge interface view ... -
Page 12: Enable
enable 【command】enable 【View】 view model 【Parameter】none 【Description】entering enable model from view model. 【Example】 OLT > enable OLT # 1.3 config 【command】 config 【View】 enable model 【Parameter】none 【Description】entering configmodel from enable model. 【Example】 OLT # config OLT (config)# 1.4 interface 【command】 interface ge interface xge interface EPON interface vlanif vlanid interface mgmt 【view】 config model 【Parameter】 Vlanid:VLAN ID. <U><1~4094> 【Description】entering interfacemodel from config model.(including XGE、ge、EPON、vlanif、 mgnt)。 【example】 OLT(config)# interface ge OLT(interface‐ge)# ... -
Page 13: Dba-Profile
OLT(interface‐EPON)# OLT(config)# interface vlanif 100 OLT(interface‐vlanif‐100)# ... -
Page 14: Acl
【example】 OLT(config)# ont‐srvprofile profile‐id 1 OLT(ont‐srvprofile‐1)# ... -
Page 15: Load
2.1 load 【command】 load packetfile ftp server‐ip‐address user‐name user‐password filename 【view】 enableview、configview 【Parameter】 ： server‐ip‐address The IP address of FTP server user‐name：ftpuser ： user‐password ftp password of user ： filename To download the application file name 【Description】 This command is used to upgrade the OLT software version and the kernel version, the command need root user login. 【example】 Upgrade application of OLT,the name of application is FD1216S_FW_V1.0.2_150914_1603.img, the IPaddress of ftp server is 192.168.1.16,ftpuser is amdin,password is admin.restarting the OLT after OLT showed upgrade OK. OLT(config)# load packetfile ftp 192.168.1.16 admin admin FD1216S_FW_V1.0.2_150 914_1603.img Broadcast message from root: ... -
Page 16: Show Progress
This command is used to check the hardware of olt,software and the info of inter version. 【example】 Checking the info of version OLT(config)# show version ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ ... -
Page 17: Management Of Equipment
3.management of equipment 3.1 reboot 【command】 reboot 【view】 enableview、configview 【Parameter】 【Description】 This command is used to reboot OLT, rootuser only has this limitation. 【example】 Reboot the OLT OLT# reboot ... -
Page 18: Show Interface Mgmt
3.3 show interface mgmt 【command】 show interface mgmt 【view】 configview 【Parameter】 【description】 This command is used to check the ip address of the out of hand management,maximum unit of the transmition and MAC address of equipment. 【example】 Checking the ip address of the out of hand management. OLT(config)# show interface mgmt Description : mgmt interface ... -
Page 19: Show Device Info
Device model : FD1216S ... -
Page 20: Dhcp-Client Renew
【description】 This command is used to the 3 layer interface , open or close the function of DHCP client. 【example】 Open the DHCP client function of vlanif1 interface. OLT(config‐interface‐vlanif‐1)# dhcp‐client enable 3.7 dhcp‐client renew 【command】 dhcp‐client renew 【view】vlanif view 【parameter】 【description】 This command is used to the 3 layer interface，open the interface of renew swith.this command will be used when we need actively to make IP address of interface and then request messages that include renewal or repeated requirement will be send. 【example】 Open the renew swith of vlanif1 interface. OLT(config‐interface‐vlanif‐1)# dhcp‐client renew 3.8 dhcp‐client release 【command】 dhcp‐client release 【view】vlanif view 【parameter】 【description】 This command is used to the 3 layer interface and free the IP of that.this command will be executed when we need to delete the ip address applied dynamically and then touched release ... -
Page 21: Show Dhcp-Client
【view】vlanif view 【parameter】 【description】 This command is used to configure the info of option60 when DHCP‐Client send the requst of message .this command is used to configure the info of option60 in order to coordinate with uplink that configured 3 layer relay of DHCP acording to the option60.no command is used to configure the info of option60,and recover the default. ... -
Page 22: Show Dhcp-Client Option60
3.11 show dhcp‐client option60 【command】 show dhcp‐client option60 [interface vlanif vlanif] 【view】config view 【parameter】 interface vlanif vlanif: index of 3 layer interface. 【description】 This command is used to query the info of option60 configured in the vlan 3 layer interface. 【example】 OLT(config)# show dhcp‐client option60 interface vlanif 1 ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ VLANIF OPTION60 ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ 1 CDATA‐VLANIF ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ ‐‐‐ 192.168.2.225 ping statistics ‐‐‐ ... -
Page 23: Show Temperature
FAN[4] status: Normal (7207RPM) ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ ... -
Page 24: Time
【description】 This command is used to display device software version and hardware version. 【example】 displayiing device software version and hardware version. OLT(config)# show version Hardware version : V1.1 ... -
Page 25: Ntp-Service Unicast-Service
【view】 enable view、config view 【parameter】 【description】 This command is used to display start‐up time and work time of equipment 【example】 Displaying start‐up time and work time of equipment OLT(config)# show uptime System up time ... -
Page 26: Timezone
【command】 show ntp‐service session 【view】 config view 【parameter】 【description】 View the OLT NTP session information. clock source：The clock server IP address. 【example】 View the OLT NTP session information OLT(config)# show ntp‐service session clock source: 202.120.2.101 clock stratum: 3 clock status: configured, sane reference clock ID: 79.213.241.147 reach: 1 current poll: 32 now: 0 offset: +511298392.149292ms delay: 0.135728 disper: 3.939436 4.11 timezone 【command】 timezone（gmt+ timezone| gmt‐ timezone） 【view】 config view 【parameter】 gmt+：The eastern time zone ... -
Page 27: Dns Server
【command】 show timezone 【view】 config view 【parameter】 【description】 This command is used to the time zone of query system。 【example】 Query the time zone of system OLT(config)# show timezone The current time zone: GMT+08:00 4.13 dns server 【command】 dns server ip address 【view】 config view 【parameter】 ： ip address The IP address of the domain name of server. 【description】 This command is used to set the system domain name server IP address。 【example】 Set up the domain name of server for 10.10.10.1 OLT(config)# dns server 10.10.10.1 4.14 no dns server 【command】 no dns server [ip address ] 【view】 config view 【parameter】 ip address:The IP address of the domain name of server. 【description】 ... -
Page 28: Backup
5.1 backup 【command】 backup configuration ftp server‐ip‐address user‐name user‐password filename 【view】 enable view、config view 【parameter】 ： server‐ip‐address The IP address of the ftp server. user‐name：ftp user ： user‐password ftp password of user ： filename The backup configuration of file name, the name of the set and do not need to file format 【description】 This command is used to backup configuration of olt 【example】 backup configuration of equipmens named config ， The IP address of the ftp server is 192.168.1.16，ftp user is amdin，and password is admin。 ... -
Page 29: Show Current-Config
The loading is successful ... -
Page 30: Show Saved-Config
【command】 erase saved‐config 【view】 enable view、config view 【parameter】 【description】 This command is used to erase the configuration file and execute the command. OLT will restore factory Settings after restart the OLT. 【example】 to erase the configuration file OLT# erase saved‐config ... -
Page 31: User Add
6.1 user add 【command】 user add name group 【view】 config view 【parameter】 ： name user name of new user group：New users belonging to a group is root、admin、guest 【description】 This command is used to add new user, new users belonging to a group is root、admin、guest RootUser has all permissions of equipment. Admin User has configured to check permissions and do not have to restart, upgrade the permissions. GuestUsers have to check the configuration and backup function. 【example】 Creating a guest user named C‐DATA and password is C‐DATA OLT(config)# user add C‐DATA guest Enter new password for user C‐DATA: ... -
Page 32: Show Port State
【Parameter】 port‐list：the list of port to be set up. 【Description】 Turn the port on. 【Example】 Turn the port ge1 on. OLT(interface‐ge)# no shutdown 1 7.3 show port state 【Command】 show port state all show port state port‐id 【View】View ge ; view EPON ;View xge ; View link‐aggregation 【Parameter】 port‐id：To‐be‐checked serial number of port. 【Description】 Check the detailed information of port or check the port‐list of OLT. 【Example】 Check the detailed information of port ge1: OLT(interface‐ge)# show port state 1 ... -
Page 33: Show Port Ddm-Info
OLT(interface‐ge)# show port state all ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ ... -
Page 34: Show Port Vlan
7.5 show port vlan 【Command】 show port vlan port‐id 【View】View ge ; view EPON ;View xge ; View link‐aggregation. 【Parameter】 ： port‐id To‐be‐checked PON port number. 【Description】 The command is use to query configuration information of port VLAN. 【Example】 query configuration information of port VLAN: OLT(interface‐ge)# show port vlan 1 ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ ... -
Page 35: Speed
【Command】 duplex port‐listduplex 【View】view ge ; View xge ; 【Parameter】 port‐list：To‐be‐checked port list. duplex：duplex mode of Ethernet，Value：half、full。 【Description】 This command is used to configure the Ethernet port duplex mode. After successful configuration, the Ethernet port will be set at full duplex or half duplex mode. 【jExample】 OLT(interface‐ge)# duplex 1 full 7.8 speed 【Command】 speed port‐listspeed 【View】View ge. 【Parameter】 ： port‐list To‐be‐checked port list. speed：the speed of Ethernet port ;Value：10,100,1000 【Description】 This command is used to set the Ethernet port speed, port works at set rate. 【Example】 Ge1 port speed is set as 100Mbit/s. OLT(interface‐ge)# speed 1 100 7.9 flow‐control 【Command】 flow‐control port‐list no flow‐control port‐list 【View】 ge views EPON views ;xge views; link‐aggregation views. 【Parameter】 ： port‐list To‐be‐checked port list. 【Description】 Opening ... -
Page 36: Mirror
7.10 mirror 【Command】 mirror src‐port src‐port dst‐port (ge|xge) port‐id direction no mirror src‐port src‐port direction 【View】 ge views EPON views ;xge views; link‐aggregation views. 【Parameter】 src‐port： the port number of src‐ port. ： port‐id Mirroring destination port. ： direction Mirror source port messages: ingress：Mirror source port receives packets. Duplicate it completely and output to the port mirroring destination. egress：Mirror source ports to send messages. Duplicate it completely and output to the port mirroring destination. all： Mirror source port transceiver two‐way message.Duplicate the message and output it to the port mirroring destination. 【Description】 This command is used to configure the Ethernet port mirroring function. When traffic on a port in the system needs to be duplicated to the other ports to output,for traffic observation, network troubleshooting, data analysis, using this command. When Ethernet port mirroring feature is set successfully, the mirror source port Specifies the message will be copied to the mirror in the direction of destination port. ... -
Page 37: Mtu
OLT(interface‐ge)# show mirror ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ ... -
Page 38: Show Port Statistics
7.14 show port statistics 【Command】 show port statistics port‐id 【View】ge views EPON views ;xge views; 【Parameter】 ： port‐id To‐be‐ checked the port number. 【Description】 This command is used to query the port statistics.According to these information,Users can determine the current device in order to detect timely and troubleshoot. Total (bytes) is the port total bytes sent/received, Uncast (pkts) is the port number of unicast packets received/sent, Bcast (pkts) is the port number of broadcast packets received/sent, Mcast (pkts) is the port number ... -
Page 39: Show Location
all：Query information of all MAC addresses in the MAC address table. black‐hole：Query the MAC address in the MAC address table which in a black hole. dynamic：Query the dynamic MAC address in the MAC address table. port port‐id：Query the MAC dress learning from a port. static：Query the static MAC address in the MAC address table. timer：Check MAC address aging time. ： vlan vlan‐id Queries the specified VLAN ID corresponds to the MAC address. 【Description】 This command is used to query the MAC address table information in the system. When you add or delete the MAC address, you can use this command to check the current MAC address table in the dynamic and the static MAC address information. 【Example 1】 Query table MAC address which all belong to the upstream port ge1of the OLT . OLT(config)# show mac‐address port ge 1 ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ ... -
Page 40: Mac-Address Limit Port
【Example 】 Querying source port information corresponding to 3C:97:0E:FD:0C:69address . OLT(config)# show location 3C:97:0E:FD:0C:69 ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ ... -
Page 41: Mac-Address Timer
Adding a static MAC address to OLT ge1 port,the corresponding VLAN is 100. OLT(config)# mac‐address static port ge 1 vlan 100 e0:67:b3:00:12:9c 7.19 mac‐address timer 【Command】 mac‐address timer aging‐time mac‐address timer no‐aging 【View】View config 【Parameter】 ： aging‐time MAC address aging time. no‐aging： sets the MAC address as not aging.using this parameter when you do not need to open the MAC address aging 【Description】 This command is used to set theaging time of dynamic entries in MAC dynamic address table . After MAC address aging time setting successfully,it takes effect immediately,and the system regularly check the dynamic MAC address, if in aging periods (1 – twice times the aging time), the system does not send or receive any message that carries the source MAC address, the corresponding ... -
Page 42: Mac-Address Black-Hole
【Example 】 The OLT ge1 of enable of MAC address learning function. OLT(config)# mac‐address learning port ge 1 enable 7.21 mac‐address black‐hole 【Command】 mac‐address black‐hole vlan‐idmac‐address no mac‐address black‐hole vlan‐idmac‐address 【View】View config 【Parameter】 ： vlan‐id the MAC address of the black holecorresponds toVLAN ID . 【Description】 Specify the MAC address table of the black hole. If a packet's source MAC address or destination MAC address MAC address MAC address table entries is equal to a black hole, the switch discards the message. 【Example】 Add MAC address table entries of a black hole. MAC address for the black hole: E0:67:B3:A5:39:A2, the corresponding VLAN is 50. OLT(config)# mac‐address black‐hole 50 e0:67:b3:a5:39:a2 7.22 mac‐address flush 【Command】 mac‐address flush all mac‐address flush black‐hole ... -
Page 43: Traffic-Suppress
Clears all OLT ge1 dynamic MAC address OLT(config)# mac‐address flush port ge 1 dynamic 7.23 traffic‐suppress 【Command】 traffic‐suppress port‐idbroadcast(kbps|pps)value traffic‐suppress port‐id multicast (kbps|pps) value traffic‐suppress port‐id unicast (kbps|pps) value no traffic‐suppress port‐id （unicast | multicast | broadcast） (kbps|pps) value 【View】view ge ,view EPON,view xge, view link‐aggregation . 【Parameter】 port‐id：To‐be‐checked port list. broadcast：By setting the allowing broadcast current to port, to realize the purpose of inhibiting port broadcasting storms. multicast：By setting the allowing unknown multicast traffic on the ports, to achieve the purpose of inhibiting port unknown multicast storm. unicast：By setting the port allows unknown unicast traffic, to achieve the purpose of inhibiting port unknown unicast storm. ： kbps value Suppression of flow values，Range of values：(1~1000000) ： pps value Value. (U)(1~1488100) 【Description】 Broadcasting of the traffic‐suppress command is used to configure the port, unknown multi‐cast and unknown uni‐cast traffic, suppression level to prevent such messages take up too many network ... -
Page 44: User Group
user delete name 【View】View config 【Parameter】 ： name To‐be‐deleted name of user. 【Description】 This command is used to delete the already created user, attention : the root user cannot be deleted. 【Example】 Delete a created user whose name is C‐DATA. OLT(config)# user delete C‐DATA 6.3 user group 【Command】 user group name group 【View】View config 【Parameter】 ： name To‐be‐changed name of group. ： group THE new name of group. 【Description】 ... -
Page 45: Show User
6.5 show user 【Command】 show user 【View】View config 【Parameter】 【Description】 This command is used to query the device for all users you've created. 【Example】 To query the device for all users who have created OLT(config)# show user ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ ... -
Page 46: Vlan Mode
【Command】 show vlan all show vlan vlan‐id 【View】View config 【Parameter】all：Checking all existing VLAN information vlan‐id：VLAN ID，Used to identify a unique VLAN. 【Description】 This command is used to query for all existing VLAN, or queries a specified VLAN, thus observing the VLAN which contains ports and ports tag processing mode 【Example】 Checking the information of VLAN 100. OLT(config)# show vlan 100 ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ ... -
Page 47: Vlan Trunk
【Parameter】 port‐list：To‐be‐set port list . vlan‐id：VLAN ID，it is used to identify a unique VLAN. 【Description】 Add access VLAN to port, if the VLAN is already exists and the port VLAN mode is access. 【Example】 Adding access vlan 100 to ge1 port. OLT(interface‐ge)# vlan access 1 100 8.5 vlan trunk 【Command】 vlan trunk port‐list allowed vlan‐list no vlan trunk port‐list allowed vlan‐list 【View】viewge ;view EPON;view xge; view link‐aggregation. 【Parameter】 port‐list：To‐be‐set port list . vlan‐list：VLAN list. 【Description】 Add access VLAN to port, if the VLAN is already exists and the port VLAN mode is trunk 【Example】 ge1 port adds trunk vlan 100，200,300 OLT(interface‐ge)# vlan trunk 1 allowed 100,200,300 ge1 ... -
Page 48: Vlan Native-Vlan
OLT(interface‐ge)# vlan hybrid 1 tagged 100 ge1 : hybrid add tag vlan: Fail: 0, Success: 1 ... -
Page 49: Interface Vlanif
‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ Untagged‐Vlan: ... -
Page 50: Multicast Module
Querying all information of vlanif interface. OLT(config)# show interface vlanif all ... -
Page 51: Igmp-Snooping Host-Aging-Time
messageafter a timeout, this command is used to switchchannels faster. 【example】 Open the function of igmp‐snooping fast‐leaving of olt OLT(config)# igmp‐snooping fast‐leave on 9.3 igmp‐snooping host‐aging‐time 【Command】 igmp‐snooping host‐aging‐time time 【View】 config view 【Parameter】 ： time members of the aging time of the port 【Description】 if member of the port didn't receive the group by group in the aging time of the IGMP membership report message, switch would delete the port from the group by group published a port in the list . 【Example】 Configure ... -
Page 52: Igmp-Snooping Querier Interval
igmp‐snooping querier disable 【View】 config view 【Parameter】 enable：enable the querier of igmp snooping disable：disable the querier of igmp snooping 【Description】 In running the IGMP multicast networks, there will be a three layer multicast device ACTS as the IGMP query, being responsible for sending IGMP query message, three layer multicast equipment can turn to establish and maintain in the network layer multicast published items But two layer equipment can’t surpport IGMP in a three layer multicast network equipment, So we can not realize the IGMP query related functions.In order to solve this problem, we can make the IGMP Snooping query on the layer 2 device, the layer 2 device can turn to establish and maintain the data link layer multicast published items 【Example】 OLT(config)# igmp‐snooping querier enable 9.6 igmp‐snooping querier interval 【Command】 igmp‐snooping querier interval time 【View】 config view 【Parameter】 ... -
Page 53: Igmp-Snooping Querier Source
information quickly.,so the router can quickly grasp the existence of the multicast group members. 【Example】 Configure the maximum response time as 10 seconds OLT(config)# igmp‐snooping querier max‐response‐time 10 9.8 igmp‐snooping querier source‐ip 【Command】 igmp‐snooping querier source‐ip source_ip 【View】 config view 【Parameter】 ： source_ip source ip address of igmp message. 【Description】 the device will not set it on the second floor for dynamic router port that the source IP address is 0.0.0.0 ,thus affecting the establishment of the published data link layer multicast turn item, eventually the normal multicast data cannot be forwarded. ... -
Page 54: Show Igmp-Snooping Group
Max response time(s) : 10 ... -
Page 55: Show Multicast-Vlan
【Description】 Multicast‐VLAN command is used to create a multicast VLAN, and enters VLAN of multicast mode. Multicast VLAN is a application of VLAN, users can configure the multicast‐related parameters under the VLAN for multicast mode. 【Example】 Creating a multicast VLAN 100 and enter the corresponding multicast VLAN mode. OLT(config)# multicast‐vlan 100 ... -
Page 56: Rstp
multicast‐unknown policy (discard | transparent) 【View】view config 【Parameter】 discard：System discards received unknown multicast traffic. transparent：The system diffuse received unknown multicast traffic. 【Description】 This command is used to configure reduction strategy of unknown multicast traffic. If the multicadt traffic carrying unknown multicast vlan , which is calles pass‐through. No special‐purpose unknown multicast would occupy bandwidth, usually configured to drop. 【Example】 Configuring unknown multicast suppression policies are passthrough mode. OLT(config)# multicast‐unknown policy transparent 10.RSTP ... -
Page 57: Spanning-Tree Timer Forward-Delay
Command is used to set the device in the designated priority in spanning‐tree . Priority of the device size determines whether the device can be selected as the root bridge of the spanning tree, when the priority of the device needs to be configured, and realize that some device can generate the root bridge.using this command. After setting the device priority, the device will be become the gist of whether select the device to generate root bridge. 【Example】 Setting the priority of spanning‐tree of OLT as 4096. OLT(config)# spanning‐tree priority 4096 ... -
Page 58: Spanning-Tree Timer Max-Age
The Hello time time parameter of device was set , equipment based on set time intervals, send Hello message to the switch around. 【Example】 Setting the hello time of OLT as 1s. OLT(config)# spanning‐tree timer hello 1 10.5 spanning‐tree timer max‐age 【Command】 spanning‐tree timer max‐age time 【View】view config 【Parameter】 time：time parameter of max age，The maximum age of a message threshold. 【Description】 Command is used to set the device's Max Age (maximum age of a message) time parameter. When you need to determine whether the configuration message obsolete, using this command. After you set the Max Age time parameters of the device, the device discard configuration messages which exceed the setting value. Range: 6‐40 second, the default value is 20 seconds. ... -
Page 59: Spanning-Tree Cost
Setting ge1 as edge port. OLT(interface‐ge)# spanning‐tree edged‐port 1 enable 10.7 spanning‐tree cost 【Command】 spanning‐tree cost port‐id cost 【View】view ge ;view EPON;view xge; view link‐aggregation. 【Parameter】 port‐id：To‐be‐set port list. ： cost The port path cost. The cost is a ports quantity,which reflect that the cost of port related with network ，lower the value is,better the connection of port.range:1‐200000000。 【Description】 spanning‐tree cost command is used to set spanning‐tree cost of port presently,after setting the cost,May cause the change of topology, spanning tree recalculate. 【Example】 Setting the spanning‐tree cost of port of ge1 as 500. OLT(interface‐ge)# spanning‐tree cost 1 500 10.8 spanning‐tree mcheck 【Command】 spanning‐tree mcheck port‐id switch 【View】view ge ;view EPON;view xge; view link‐aggregation. 【Parameter】 port‐id：To‐be‐set port list. ： switch mcheck switch。value：enable、disable。 【Description】 STO mcheck command is used to execute mCheck operation at the global or port. On devices of running the RSTP , if a port is connected to the device, the port is automatically migrated to the STP‐compatible mode 【Example】 Opening the mcheck of ge1. ... -
Page 60: Spanning-Tree Priority
【View】view ge ;view EPON;view xge; view link‐aggregation. 【Parameter】 port‐id：To‐be‐set port list. ： mode point‐to‐point mode of spanning‐tree.，value：true,false,auto 【Description】 Spanning‐tree point‐to‐point command is used to set the currentEthernet port which is link of point‐to‐point. . When need to control the switch time of Ethernet status, you need to configure whether the link is a point‐to‐point link, using this command. Setting the current link ... -
Page 61: Acl
11.ACL 11.1 time‐range 【Command】 time-rangetime-name { start-timetoend-timedays | fromtime1date1 [ totime2date2 ] } no time-rangetime-name 【View】confiig view 【Parameter】 ： 。 time-name the name of time period, Configure ACL rules refer to this name ： start-time The start time of relative time period。identify a time range with the end-time，days define date,Three parameters to determine a relative time period。... -
Page 62: Display Time-Range
11.2 display time-range 【Command】 display time-range { all | time-name} 【View】config view 【Parameter】 all：Query information all the time。 ： time-name the name of time period。 When you need to query information about the specified time period, you can use this parameter。 【Description】 ... -
Page 63: Rule (Adv Acl)
reference for packet filtering rules. Or you can used with QoS policyfor a particular message service quality assurance. no rule : This command is used to delete or modify the ACL rules. 【Example】 In the worktime period, specified port 1 can only receive message from IP address for 10.10.10.2. OLT(config)# time‐range worktime 8:00 to 18:00 working‐day ... -
Page 64: Rule (Link Acl)
[destination(ip-address sour-wildcard | any)] [src-port port-list | dest-portport-list] | [precedence procedence-value ] | [dscp dscp-value] |[time-rangetime-range-name]] The command format based on the rules of IPv4 of delete or modify as follows: no rule rule-id( source | destination | precedence | dscp | src-port | dest-port | time-range | precedence | all) 【View】adv ... -
Page 65: Show Acl
【Command】 rulerule-id(permit | deny)( [cos cos-value ] | [destinationmac-addrmac-wildcard] | [ sourcemac-addrmac-wildcard] | [ inner-cosinner-cos-value] | [ vlan vlan-id] | [inner-vlan inner-vlan-id] | [ typeEthernet-type] |[time-rangetime-range-name]) no rule rule-id 【View】basic acl view 【Parameter】 rule-id：ACL Rule-ID。ACL ID is the bigger the priority； permit： Don't allow to match the flow through the message； deny： The original IP address section in the ACl rules； source: the original IP address of a ACL matching message； ；... -
Page 66: Qos
acl‐id: Specific ACL all:Show all of the ACL 【Desctribtion】 【Example】 Quering all of the ACL information about devices OLT(config)# show acl all Basic ACL 2000, 1 rules hold rule 1 permit source 10.10.10.2 0.0.0.0 time-range working-day 12. QOS 12.1 packet‐filter 【Commond】 packet‐filter (inbound| outbound ) acl‐id [ rule‐idrule‐id ]port （ge | EPON | xge）port‐list nopacket‐filter (inbound| outbound ) acl‐id [ rule‐idrule‐id ]port （ge | EPON | xge）port‐list 【View】 Config view 【Parameter】 Inbound: The traffic on inbound packets of the interface Outbound： ... -
Page 67: Traffic-Limit
【Commond】 traffic‐dscp (inbound| outbound ) acl‐id [ rule‐idrule‐id ]port （ge | EPON | xge）port‐list remark‐dscpremark‐dscp‐value notraffic‐dscp (inbound| outbound ) acl‐id [ rule‐idrule‐id ]port （ge | EPON | xge）port‐list 【View】 Config view 【parameter】 Inbound: the trafficon inbound packets of the interface Outbound： the trafficon outbound packets of the interface ： rule‐id the rule ID of ACL acl‐id: ACL’s name ： port‐list ports list ： remark‐dscp‐value To remark the DSCP value ... -
Page 68: Traffic-Mirror
： remark‐dscp‐value To remark the DSCP value rate‐value: The rate of the interface 【Describtion】 traffic‐limit: Command is used to specify the discharge port configuration ACL, and make it into effect. When you need to use the ACL rules for port rate limit, use this command. no traffic‐limit: This ciommand is used to cancel the ACL traffic restrictions specified port. -
Page 69: Traffic-Outervlan
OLT(config)# traffic-mirror inbound 2000 port ge 1 to ge 2 traffic‐outervlan 12.5 【Command】 traffic‐outervlaninbound acl‐id [ rule‐idrule‐id ]port（ge | EPON | xge）port‐list vlan vlanID no traffic‐outervlaninbound acl‐id [ rule‐idrule‐id ]port （ge | EPON | xge）port‐list 【View】 Config view 【Parameter】 Inbound: the traffic on inbound packets of the interface Outbound： the traffic on outbound packets of the interface rule‐id： the rule ID of ACL acl‐id: ACL’s name port‐list： ports list vlanID: ... -
Page 70: Traffic-Redirect
Inbound: the traffic on inbound packets of the interface Outbound： the traffic on outbound packets of the interface rule‐id： ID the rule ID of ACL acl‐id: ACL’s name port‐list： ports list vlanID: Add the outer label pri‐value:The value of the priority 【Description】 traffic‐priority: Command is used to configure vlan priority for the specified port, and make it into effect. When you need to use the ACL rules to change VLAN priority, you can use this command. -
Page 71: Traffic-Statistic
In the worktime period, the message that its ip address is 10.10.10.2 are redirect to port 2, OLT(config)# time‐range worktime 8:00 to 18:00 working‐day OLT(config)# acl 2000 OLT(acl‐basic‐2000)# rule 2 permit source 10.10.10.2 0.0.0.0 time‐range working‐day OLT(acl‐basic‐2000)# exit OLT(config)# traffic-redirectinbound 2000 port ge 1 to ge 2 traffic‐statistic 12.8 【Command】 ... -
Page 72: Show Qos-Info
Config view 【Parameter】 Inbound: the traffic on inbound packets of the interface Outbound：the traffic on outbound packets of the interface rule‐id： the rule ID of ACL acl‐id: ACL’s name port‐list： ports list 【Description】 traffic‐statisticclear-counters: This command is used to remove the configuration which istraffic statistics of the specified port ,and make it take effect. 【Example】 In the worktime period,removing the flow statistics of message that is from port 1 ,and the ip address of the message is 10.10.10.2. ... -
Page 73: Qos Queue-Scheduler
qos queue‐scheduler 12.11 【Command】 queue0-weight queue1-weight queue2-weight qos queue-scheduler wrr queue3-weight qos queue-schedulerstrict-priority 【View】 Config view 【Parameter】 strict-priority: Strict Priority Scheduling， Applying this model, the system in strict accordance with the priority queue for scheduling. Only high priority queue is empty, you can schedule message in the lower priority queues. -
Page 74: Show Queue-Scheduler
Systems support PQ, WRR, WRR + PQ scheduling model. When a queue is empty,system can switch immediately to the next queue scheduling,it make full use of bandwidth resource. When existing WRR queue scheduling, the sum of weights must be 100 WRR + PQ scheduling mode is a mixture of WRR and PQ two scheduling model. -
Page 75: Dhcp-Snoop
‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ Priority Queue ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ ... -
Page 76: Show Dhcp-Snooping Configuration
Close dhcp-snooping function After DHCP snooping closing, Other functions closing, example,trust/untrusted port function, MAC address detection function, DHCP message rate limit in untrusted port, port recover function, option82 function, ARP dynamic monitoring function and ARP rapid response function. 【Example】 Close dhcp-snooping function OLT(config)# dhcp-snooping disable ... -
Page 77: Dhcp-Snooping Chaddr-Check
【Example】 Add monitoring vlan100,200,300 OLT(config)# dhcp-snooping vlan 100,200-300 dhcp-snooping trust port 13.5 【Command】 dhcp-snooping trust port (ge | xge | EPON| lag) port-list no dhcp-snooping trust port (ge | xge| EPON | lag )port-list 【View】 Config View 【Parameter】 port-list:Add the specified port list 【Description】 ... -
Page 78: Dhcp-Snooping Limit-Rate
Close the untrusted port MAC address detection OLT(config)# dhcp-snooping chaddr-check disable dhcp-snooping limit-rate 13.7 【Command】 dhcp-snooping limit-rate rateport （ge | gon｜xge | lag）port-list 【View】 Config view 【Parameter】 Rate:Limit the rate of the DHCP request packet 【Description】 Set the rate of receiving DHCP request packet in the untrust GE port, exceeding the rate, the untrust port discarding the message. -
Page 79: Dhcp-Snooping Option82 Remoteid-String
dhcp-snooping option82 circuitId-stringstringport （EPON | ge | lag | xge）port-id no dhcp-snooping option82 circuitId-stringstring 【View】 Config view 【Parameter】 ： Custom circuit id sub-option information string ： Setting agent circuit id port-id 【Description】 dhcp-snooping option82 circuitId-string: Setting custom circuit id sub-option information no dhcp-snooping option82 circuitId-stringstring: To restore the default sub-option information of agent circuit id... -
Page 80: Dhcp-Snooping Binding
【Command】 dhcp-snooping option82 policy (keep|drop|replace) 【View】 Config view 【Parameter】 keep: The same forwarding DHCP message with Option82 option drop: Discarded directly DHCP message with option82 replace: Replace the Option82 options of the original DHCP message, and then forward 【Description】 dhcp-snooping option82 policy: It is used to config forward policy based on the request packet Opton82 【Example】 ... -
Page 81: Dhcp-Snooping Bind-Table Write-Delay
【View】 Config view 【Parameter】 Vlan-id: Clear bind table by vlan all: Clear all entries static:Clear all static entries dynamic：Clear all dynamic entries ip-address：Clear all entries with the specified IP address 【Description】 Clear bind-table entries 【Example】 OLT(config)# dhcp-snooping bind-table clear all dhcp-snooping bind-table write-delay 13.14 ... -
Page 82: Dhcp-Snooping Bind-Table Write-To-Flash
13.16 dhcp-snooping bind-table write-to-flash 【Command】 dhcp-snooping bind-table write-to-flash 【View】 Config view 【Parameter】 nothing 【Description】 Write manually bind table into flash 【Example】 Write the bind table of dhcp into flash OLT(config)# dhcp-snooping bind-table wrtite-to-flash dhcp-snooping bind-table save-to-tftp 13.17 【Command】 dhcp-snooping bind-table save-to-tftpip 【View】 ... -
Page 83: Dhcp-Snooping Arp-Reply-Fast
ip-address：Show all entries with the specified IP address 【Description】 Show DHCP snooping bind table 【Example】 Show the information of DHCP snooping bind table OLT(config)# show dhcp-snooping bind-table all ----------------------------------------------------------------------------- database entries count: 5 database entries delete time: 300(s) ----------------------------------------------------------------------------- MacAddress IpAddress Vlan Port Lease(s) Type Status... -
Page 84: Link-Aggregation
【Description】 Support a total of eight aggregation groups about FD1216S equipment, Member add,this commandisthat add members in group aggregation port; member delete ,this command is that delete member port under the corresponding aggregation group. -
Page 85: Link-Aggregation Group Group-Idunicast Balance
14.2 link-aggregation group group-idunicast balance 【Command】 link-aggregation group group-idunicast balance (dest-ip |dest-mac |source-dest-ip | source-dest-mac | source-ip | source-mac ) 【View】 Lag view 【Parameter】 group-id: the value of link-aggregation group 【Description】 Set the sharing mode of known unicast in aggregation group 【Example】 ... -
Page 86: Show Link-Aggregation Group Summary
value: Set the port priority of aggregation, when the main port is in the election, its priority is higher, the aggregation port of the higher priority 【Description】 Set the port priority of aggregation 【Example】 Setting the priority of interface 1 is 6000 OLT(config-interface-aggregation)# link-aggregation port-priority ge 1 6000 14.5 show link‐aggregation group summary ... -
Page 87: The Configuration Of Dba-Profile
member xge2 statistics: ----------------------------------------------------------------------------- Direction Total Uncast Bcast Mcast (bytes) (pkts) (pkts) (pkts) (pkts) ---------------------------------------------------------------------------- ----------------------------------------------------------------------------- link-aggregation group 1 statistics: ----------------------------------------------------------------------------- Direction Total Uncast Bcast Mcast (bytes) (pkts) (pkts) (pkts) (pkts) ---------------------------------------------------------------------------- ----------------------------------------------------------------------------- The configuration of DBA-profile 15.1 dba‐profile 【Command】 dba‐profile (profile‐id profile‐id | profile‐name profile‐name) ... - Page 88 【Command】 type1 fix fix type2assure assure type3assure assure max max type4max max type5fix fix assure assure max max 【View】 dba‐profile view 【Parameter】 type1 Configuration type isthe DBA template of the fixed bandwidth. Fixed bandwidth is reserved completely for specific ONU or specific business of ONU, even without the ascending business flow in the ONU, this part of the bandwidth is also cannot be used for other ONU.
-
Page 89: Show Dba-Profile
【Example】 The dba template 10is type5, fixed bandwidth is 5 mbit/s, guarantee the bandwidth is 10 mbit/s, maximum bandwidth is30 mbit/s OLT(dba‐profile‐10)# type5 fix 5120 assure 10240 max 30720 15.3 show dba‐profile 【Command】 show dba‐profile (all | profile‐id profile‐id | profile‐name profile‐name) 【View】 config view 【Parameter】 all：Query all of the dba‐template information in system ： profile‐id profile‐id Query the dba‐template information of specified ID ： profile‐name profile‐name ... -
Page 90: Commit
15.4 commit 【Command】 commit 【View】 dba‐profile view 【Parameter】 【Description】 This command is used to submit the current dba‐template configuration, only submit successfully, all of the dba template parameters configuration will only take effect. 【Example】 Submit the current dba template configuration OLT(dba‐profile‐10)# commit 16.ONT configuration of the line template 16.1 ont‐lineprofile 【Command】 ont‐lineprofile (profile‐id profile‐id | profile‐name profile‐name) no ont‐lineprofile (profile‐id profile‐id | profile‐name profile‐name) 【View】 config view 【Parameter】 ： profile‐id Line template number of EPON ONT, it is used to identify uniquely a line template ： profile‐name Line template name of EPON ONT, The default template name is “ line ‐ profile_x”, "x" is the actual template number. ... -
Page 91: Fec
【Command】 Llidllid‐list ([(dba‐profile‐id profile‐id | dba‐profile‐nameprofile‐name)] | [ encrypt ( off |triple‐churning) ] | [ont‐car Profile‐id ]) no llid llid‐list ([dba‐profile] | [ont‐car]) 【View】 config view 【Parameter】 ： profile‐id Line template number of EPON ONT, it is used to identify uniquely a line template ： profile‐name Line template name of EPON ONT, The default template name is “ line ‐ profile_x”, "x" is the actual template number. ... -
Page 92: Show Ont-Lineprofile
OLT(config‐ont‐lineprofile‐10)# 16.4 show ont‐lineprofile ... -
Page 93: Ont Business Template Configuration
FEC switch : Enable ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ LLID Encrypt type DBA Profile‐ID Traffic‐CAR‐ID ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ 17.ONT business template configuration 17.1 ont‐srvprofile 【Command】 ont‐srvprofile (profile‐id profile‐id | profile‐name profile‐name) no ont‐srvprofile (profile‐id profile‐id | profile‐name profile‐name) 【View】 config view 【Parameter】 ： profile‐id The serial number of EPON ONT business template .If you do not specify a template ID, ... -
Page 94: Port Vlan
【Parameter】 eth eth： The number of Ethernet ports on the ONT pots pots： The number of voice ports on the ONT. 【Description】 This command is used to set the port capacity of business template on the ONT, namely that is port number of each type port . port capacity of ONT must be consistent with actual ability. The port number is 0 by default 【Example】 The port number of ETH is 4,and the port number of POTS is 1 in ont‐srvprofile‐10 OLT(ont‐srvprofile‐10)# ont‐port eth 4 pots 1 17.3 port vlan 【Command】 port vlan eth port‐list translationvlan‐iduser‐vlanvlan‐id port vlan eth port‐list transparent port vlan eth port‐list vlan‐id no port vlan eth port‐list vlan‐id 【View】 ... -
Page 95: Show Ont-Srvprofile
【Command】 port eth ont‐portid ( [ds‐policing (traffic-table-index| unconcern)] | [group‐num‐maxnum] |[ multicast‐tagstrip ( tag | untag )] | [up‐policing (traffic-table-index| unconcern)] | [max‐mac‐count ( num |unlimited]) no 【View】 srvprofile view 【Parameter】 ont-portid：the port ID of ont traffic-table-index： up-policing Traffic profile for downstream The table of upward flow on the ETH port ds-policing... -
Page 96: Show Ont-Srvprofile Current
profile‐name profile‐name： Show Service profile name detailed information of specific 【Description】 Show information of epon ONT service profiles 【Example】 Show information of epon ONT service profile 1 OLT(config)# show ont‐srvprofile profile‐id 1 ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ Profile‐ID : 1 Profile‐name : srvprofile_1 Binding times : 66 ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ Port‐type Port‐number ... - Page 97 【Command】 show ont‐srvprofile current 【View】 srvprofile view 【Parameter】 【Description】 Show the current information of service profile 【Example】 Show the current information of service profile 1 OLT(config‐ont‐srvprofile‐1)# show ont‐srvprofile current ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ Profile‐ID : 1 Profile‐name : srvprofile_1 Binding times : 66 ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ Port‐type Port‐number ...
-
Page 98: Commit
ETH 4 Translation 1 1 1 ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ 17.7 commit 【Command】 commit 【View】 srvprofile view 【Parameter】 【Description】 This command is used to submit the current configuration of business template , it is not until this command submit that parameter configuration will take effect to all the business templates, line template and the alarm strategy template. -
Page 99: Ont Confirm
template 10, the binding business template10. OLT(interface‐epon)# ont add 1 2 mac‐auth 22:22:22:22:22:22 ont‐lineprofile‐id 10 ont‐ srvprofile‐id 10 18.2 ont confirm 【Command】 ont confirm port‐idmac‐authmac ont‐lineprofile‐id ont‐lineprofile‐id ont‐srvprofile‐id ont‐srvprofile‐id ont confirm port‐id allmac‐auth ont‐lineprofile‐id ont‐lineprofile‐id ont‐srvprofile‐id ont‐srvprofile‐id 【View】 epon view 【Parameter】 ： port‐id The EPON port number of the confirmed ONT. all：... -
Page 100: Ont Delete
Cancel all of ont found automatically under PON1 port OLT(interface‐EPON)# ont cancel 1 all 18.4 ont delete 【Command】 ont delete port‐id(all | ont‐id) 【View】 epon view 【Parameter】 port‐id: The port number of EPON needed to delete all：Delete all configure business of ONT under EPON port ont‐id：The number of ONT needed to delete 【Description】 This command is used to delete the ONT. Deleted ONT will be deleted the configuration information of the ont, and online ONT will be forced to offline. 【Example】 ... -
Page 101: Ont Autofind
18.6 ont autofind 【Command】 ont autofind port‐idswitch 【View】 epon view 【Parameter】 port‐id： The PON port number that need to open the function of ONT automatically find ： switch enable，disable the switch of ONT automatically find ,value : 【Description】 This command is used to open or close automatic found ONT under the PON port of EPON OLT 【Example】 ... -
Page 102: Ont Modify
【View】 epon view 【Parameter】 port‐id： The PON port number of the ONT needed to deactivate all： Used to volume deactive ONT ： ont‐id Used to deactive specified ONT on the PON port 【Description】 This command is used to deactivate the ONT. ONT can work normally only in the activated state. Don't ... -
Page 103: Ont Ipconfig
This command is used to restart ONU 【Example】 Restart ONU 1 on the PON2 OLT(interface‐EPON)# ont reboot 2 1 18.11ont ipconfig 【Command】 ont ipconfig port‐idont‐id ip‐address ip mask mask gateway gatewaymanage‐vlanmanage‐vlanService‐VLAN ID. 【View】 epon view 【Parameter】 port‐id： The PON port number of ONT that need to restrat ： ont‐id The number of the ont that need to restart Ip: the ip address of the ont Mask: ip address mask Gateway： the gateway address of device Manage‐vlan: manage‐vlan Service‐vlanid service‐vlanid 【Description】 This command is used to config the ip address gateway of ont ... -
Page 104: Ont Port Native-Vlan
use this command ,when you need to set up-policing. traffic-table-index： ds-policing The traffic-table-index of down-policing on the ETH port .you can use this command ,when you need to set down-policing. Unconcern： Unconcern the flow control of the ETH port 【Description】 This command is used to control the port state ,flow control ,traffic rate‐limiting of the ont. ... - Page 105 status ,the configuration and t‐conut about ont) Port： The PON port number of ONT on the OLT ONT ID： The specified serial number of ONU. MAC： The MAC address of the ONU Control flag： active： ONT is activated , ONT can work normally only in the activated state. deactive： ONT is unactiveted Run state： It is running‐remark , including “online” and “offline”,normal online is “online”. Config state： After ONT online normally, It is remark whether ont issued and restore configuration .there are three states: “initial”, “failed”and “Success” initial： ...
-
Page 106: Show Ont Autofind
POTS 0 ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ Multicast fast leave switch : Disable Ring check switch : Disable ... -
Page 107: Show Ont Config-Capability
and the discover automatically time. 【Example】 Query all of ONTs that are found automatically under the PON 1 OLT(config‐interface‐epon)# show ont autofind 13 all ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ Index MAC Autofind‐Time ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ 1 E0:67:B3:AA:BB:0C 2000‐01‐01 00:01:37 ... -
Page 108: Show Ont Version
【Parameter】 port‐id：The PON port number of ONT that need to query capability. ： ont‐id The number of ONT that need to query capability 【Description】 This command is used to query the user configuration capabilities of ONT. Check whether ability match by comparing the user configuration capabilities with real ability 【Example】 Query the user configuration capabilities of the ONT 1 on the PON13 of ont 1 on the PON13 OLT(config‐interface‐epon)# show ont config‐capability 13 1 ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ ... -
Page 109: Loghost Add
【Command】 show ont version port‐idont‐id 【View】 epon view 【Parameter】 port‐id： The PON port number of the ont that need to query ： ont‐id The nymber of ont that need to query 【Description】 This command is used to query the relevant information of ONT version, you can query the software and hardware versions of ONT, manufacturers and so on. 【Example】 ... -
Page 110: Loghost Delete
of equipment can record on host by syslog mechanism. 【Example】 Add syslog server named log,and its ip address is 192.168.1.223. OLT(config)# loghost add 192.168.1.223 log Successfully add syslog host! ... -
Page 111: Loghost Deactivate
Successfully activate syslog host! 19.4 loghost deactivate ... -
Page 112: Show Syslog Priority Severity
【Command】 syslog priority severity 【View】 config view 【Parameter】 severity：level the fifth：critical the forth：error the third：arning the second：notice the first：debug 【Description】 This command is used to set the level of olt log,OLT will only output logging information whose level is equal to or greater than the current system log level . If the log level is set to the highest levels, the OLT will only output log information of the critical level,if the log level is set to notice, OLT can output logging information of critical, error, warning, notice level. notice isrecommended 【Example】 Setting the severity of syslog priority is notice OLT(config)# syslog priority notice 19.7 show syslog priority severity 【Command】 show syslog priority severity 【View】 config view 【Parameter】 【Description】 This command is used to query the log level of current configration 【Example】 Query the log level of current configration OLT(config)# show syslog priority severity Syslog priority severity: notice ... -
Page 113: Terminal Debugging
： filename the file name of saved log 【Description】 This command is used to manually save log to the FTP server 【Example】 Save log to ftp server,the ip address of ftp server is 192.168.1.223,username is admin,password is admin. OLT(config)# backup log ftp 192.168.1.223 admin admin logback Start backup log files The backup is successful ... -
Page 114: Erase Log
19.11 erase log 【Command】 erase log 【View】 config view 【Parameter】 【Description】 Erase olg information of the olt 【Example】 view device information OLT(config)# erase log 19.12 show alarmhistory 【Command】 show alarmhistory 【View】 enable view、config view 【Parameter】 【Description】 This command is used to query the alarm history information 【Example】 OLT# show alarm history 2000/01/01 06:04:24 PON 1 ONU 1 offline! 2000/01/01 06:05:00 PON 1 ONU 1 online! 19.13 show alarmpriority 【Command】 show alarmpriority 【View】 config view 【Parameter】 【Description】 This command is used to query the alarm priority 【Example】 ... -
Page 115: Alarm Priority
【Example】 OLT(config)# alarm priority critical Conclusion Thanks to the use of the C-Data Technology Co. Ltd. Products! Contact： Company Address：Flat 6, #4, South 2 of Honghualing Industrial Zone,Xili, Nanshan, Shenzhen China(518055) Telephone：0755-26014509/26014710/26014711 Fax：0755-26014506 Website：www.cdatatec.com Company Address: Flat 6, Bldg 4,South 2 of Honghualing Industrial Zone,Liuxian Road, Xili Town, Shenzhen, Guangdong, China(518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website: www.cdatatec.com...
