- Page 1 WWW.PROFITAP.COM PROFISHARK 100M User manual Ethernet Protocol Analyzer TAP...
- Page 2 Page 2 LAN-WAN Test Equipment Thank you for purchasing the PROFISHARK 100M. Package content Inside the package are provided : - 1* PROFISHARK 100M main unit - 1* 2Gb USB key containing drivers and softwares - 1* RJ45 cable - 1* USB2.0 cable...
-
Page 3: Table Of Contents
Page 3 Table of contents 1. General Information…..………………………….………….. 2. PROFISHARK 100M Visual Description…………………. 3. Installation…………………………………………………….. 3.1 Hardware & Driver installation 3.2 Analyzer Installation 4. Optional Software Description…………………………….. 4.1 EasyStat 4.1.a Installation 4.1.b Description 4.1.c Usage 4.2 NanoSec Converter 4.2.a Installation 4.2.b How to use it? -
Page 4: General Information
Page 4 LAN-WAN Test Equipment 1. General Information The PROFISHARK is a straightforward solution. In-Line, it sees and monitors all 7 protocol layers. It captures and aggregates Full-Duplex traffic at Wire- Speed (200Mb). It requires only one USB 2.0 (480Mb) port. It is a cost- effective, ultra compact, easy to use solution. - Page 5 There are several ways to indicate this kind of errors with PROFISHARK: via LEDs on the frontpanel, via the EasyStat or with the used Analyzer. Finally, ProfiTAP is declined under different versions depending on option chosen. In fact we provide to our consumers the ability to lead their analysis as they wish.
-
Page 6: Profishark 100M Visual Description
Page 6 LAN-WAN Test Equipment 2. PROFISHARK 100M Visual Description Port A (RJ45) connected to the network Port B (RJ45) connected to the network Two green LEDs to indicate whether a CRC error occurs Two green LEDs to indicate the activity on the network Green LED to give information about power supply status (e.g. -
Page 7: Installation
Page 7 3. Installation... -
Page 8: Hardware & Driver Installation
Page 8 LAN-WAN Test Equipment 3.1 Hardware & driver installation a. Insert the USB key for accessing/copying the contents to an installa- tion folder. Note : It is recommended to copy the contents to your hard disk first, if there is no more other USB2.0 port available. - Page 9 Linux kernel 2.6.14 ~ 2.6.22 Please check the latest driver released for your Operating System in the User Section at www.profitap.com. You need to be a registered User to access this area. Registering is free and will let you participate on ongoing product im- provements.
-
Page 10: Analyzer Installation
In addition, perform step a. to enable PROFISHARK to be the selected resource for Analysis. Verify the listing on our website regarding supported Analyzers at the User Section of www.profitap.com Make sure to use the latest available version if any problem occurs with PROFISHARK. -
Page 11: Optional Software Description
Page 11 4. Optional Software Description On the front panel of PROFISHARK you will find the exact edition / version of the purchased unit. This chapter is about the corresponding optional software. -
Page 12: Easystat
We recommend to have latest Java Runtime version running with your ProfiTAP - checking the website of Java from time to time.. b. Description EasyStat is a standalone application designed for PROFISHARK. There is no need to deactivate your Analyzer while performing any action with that soft- ware. -
Page 13: Usage
Page 13 chart or graph prior to a deeper investigation performed by an Analyzer. In addition to the display of CRC errors via LEDs on the front of PROFISHARK device, it displays detailed informations about RX and TX lines of the monitored link with the EasyStat. - Page 14 Page 14 LAN-WAN Test Equipment The picture on the prior page shows the set of counters and informations available for the monitored transmitted (TX) and received (RX) lines : PROFISHARK counts the following events : CRC error, size bracket of fra- mes, undersized and oversized frames, collisions and jabbers.
- Page 15 Page 15 Meters This view use meters and gauges in order to display the average bandwidth utilization and CRC error occurances. The values are percentage of the total of seen packets on the monitored TX and RX lines. This tab offers setting up thresholds for bandwidth traffic and CRC error and to write an event into a log if the values exceeds this thresholds.
-
Page 16: Nanosec Converter
Page 16 LAN-WAN Test Equipment 4.2 NanoSec Converter (model C1AP-100) For Packet Capture with/via PROFISHARK, the TAP can be set to add a 5 nanosecond resolution time information to each packet. (see chapter: User SetUp) Note: As of today, to take advantage of this nanosecond timestamp it is mandatory to perform the initial packet capture in combination of PROFISHARK and Wireshark. - Page 17 Page 17 Window of NanoSec Converter During conversion, follow the instruction as displayed in the application window. Note : The native capture file(s) will not be changed. After conversion, open the ns.***.pcap file(s) with Wireshark. You will find the precise timing information at its proper position.
-
Page 18: Profitap User Setup
Copy the files ‘User SetUp.jar’ and ‘jnetpcap.dll’ to the same directory on your hard disk. If you’re running a Windows based OS, you can copy ‘jnetpcap.dll’ to c:\windows\system32 instead. You may create a shortcut on your desktop to have the ProfiTAP User SetUp available in one click. Notes : The software is a Java based application as well. -
Page 19: Usage
Page 19 2. Usage Run the program: a green button in the upper left corner of the User SetUp window indicates that PROFISHARK is properly installed and connected. As shown above there are four configurable options/settings available : - CRC error filter... - Page 20 You may consider CRC32 bytes to be useless, This option allows the TAP to truncate this information from your frames. Please keep in mind that since ProfiTAP natively keeps packets containing CRC errors, all of the erro- neous packets will be treated like fair ones.
- Page 21 Check factory option : a click on that button will indicates through the CRC LEDs of PROFISHARK which option(s) is(are) implemented. Right LED lightning indicates whether filter setup (corresponding software : ProfiTAP User SetUp) is available or not. Left LED lightning indicates whether timestamp (corresponding software : NanoSec Converter) is available or not.
-
Page 22: Additional Informations
Page 22 LAN-WAN Test Equipment 5. Additional informations 5.1 System requirements To achieve maximum performance and to avoid potential packet loss or malfunctions , the mininum required configuration should be : - USB2.0 Port - Dual Core Processor - 1GB Memory. 5.2 Technical and electrical features Power consumption : 5V - 300mA Operating Temperature : 0 - +50°C... -
Page 23: Warranty And Liability
Page 23 Disclaimer The information in this document is subject to change without notice. The manufacturer makes no representations or warranties with respect to the con- tents hereof and specifically disclaims any implied warranties of merchantability or fitness for any particular purpose. The manufacturer reserves the right to revise this publication and to make changes in the content hereof without obligation of the manufacturer to notify any person of such revision or changes. - Page 24 Rev 1.3 ©2014, Comcraft CUSTOMER SUPPORT INFORMATION For technical information support: Phone : +33 388 101830 Fax : +33 388 101835 Mail order : COMCRAFT 17A, rue des Frères Lumière 67201 Eckbolsheim - France Website: www.profitap.com E-mail: info@profitap.com...
