- Page 1 TM116W715L User’s Guide surface...
- Page 2 This guide has been designed to help familiarize you with the features and functions of the Kickstand 11 Draw, and get you ‘up-and-running’ as soon as possible. Once you’re online, visit www.nuvision.com to register your tablet, and access more information to...
-
Page 3: Check Package Contents
Check Package Contents Tablet AC/DC Adapter Keyboard / Cover Digital Pen & (1) AAAA Battery... - Page 4 Tablet Overview...
- Page 5 Kickstand Pull Holds Speaker Micro TF Memory Card Slot USB 2.0 3.5mm Headphone Jack Front Camera Lens Volume (+/-) Power Button A/C Adapter Connection Micro USB Micro HDMI Port USB 3.0 Windows Button BACK with KICKSTAND Keyboard Dock Connection Rear Camera Lens Kickstand (Use Pull Holds to adjust stand height.)
-
Page 6: Keyboard Overview
Keyboard Overview Function Key Track Pad Fingerprint ID Scanner Open Active Menu Magnet (Attaches to front of Tablet when Keyboard is connected.) Keyboard Dock Connection... -
Page 7: Pen Overview
Pen Overview Pen Back Pen Head AAAA Battery (Inserts Positive end towards the Tip) Eraser Button Use Pen Replacement Tool to Alt Button (Mouse Right-Click) remove/replace Tip Clip... - Page 8 To Connect to the Internet, you will need: (Home WiFi Router) WIFI INFO NAME (SSID): XXXXXX PASSWORD: XXXXXX...
- Page 9 • A Home WiFi Router OR a publicly-available WiFi signal (ie., In a library, coffee shop or school.) • The Network Name (SSID) and Network Security Key (ie., Password) for the Internet Connection.
-
Page 10: Charge The Tablet
Charge the Tablet... - Page 11 Connect the AC/DC power adapter to a wall outlet, then to the tablet’s DC port as shown. A blue light above the DC port will indicate that the tablet is charging. It is recommended to fully charge the battery before first use. Typical battery charge time is between 4-6 hours.
- Page 12 Connecting the Tablet and Keyboard Your tablet features a specially-designed magnetic hinge that attaches and secures the tablet and keyboard together, enabling quick and easy docking. 1. Dock Port Connect the 5-pin magnetic dock port to support the keyboard. 2. Hinge Tabs Align and insert tabs into their respective slots in the tablet.
- Page 13 Undocking the Tablet Firmly grasp the tablet and secure the keyboard at the same time, then gently pull up on the tablet.
- Page 14 Turn-on the Tablet and follow the prompts. Seconds...
- Page 15 Use the Setup Wizard During the setup process, Hi there. you will be able to: • Create a Microsoft account • Personalize the unit • Establish a Password. Select a WiFi Network and type-in the Password Select ‘skip this section’ at the bottom of the list. You’ll be able to connect later (See page 18)
- Page 16 Familiarize yourself with Windows. (Shown here in Tablet Mode, with live tiles.) 10 11 13 14...
- Page 17 Select Pinned tiles or All apps menu Account Settings: Change account settings or Sign out. Windows Settings : View and adjust settings for the System, Internet, Security, etc. Power: Sleep, Shut down or restart the system. Windows: Return to Home screen. (Desktop Mode) View Apps menu and pinned tiles. Go to Previous screen Activate Cortana Task View: View active windows.
-
Page 18: Connecting To The Internet
Connecting to the Internet MyHomeRouter Secured MySmartphone Secured Private Secured CoffeeShop WiFi Secured LibraryInternet Secured Tap on the WiFi icon, and a menu will appear with all available WiFi signals. Look for and select the Network Name in your WiFi listing, on your tablet. - Page 19 MyHomeRouter MyHomeRouter Secured Secured Connect Automatically Enter the Network Security Key •••••••• Connect You can also connect by pushing the button on the router. MySmartphone Secured Private MySmartphone Secured Secured CoffeeShop WiFi Private Secured Secured LibraryInternet CoffeeShop WiFi Secured Secured LibraryInternet Secured Select Connect.
- Page 20 Connecting to the Internet Once you have a WiFi connection, you can go to the internet using the Microsoft Edge Browser. Tip: If you don’t see the Edge icon on your desktop, tap on the Windows logo > All apps Icon and scroll down the list until you see “Edge”.
- Page 21 Visit Nuvision online! www.NuVision.com & shopNuVision.com NuVision.com is your online resource for: • Product Registration • Frequently-Asked Questions (F.A.Qs) • Information and tips on how to best use your tablet. • Customer Service Chat & email.
- Page 22 Apps Menu...
- Page 23 Tap on the ‘All apps’ icon in the Windows menu to open a list of all your tablet’s available apps. To make an app available as a tile on the Start screen (“Pin to start”), press and hold the app ‘tile’ for 2 seconds, then release and select “Pin to start”...
-
Page 24: Customer Service
Customer Service Chat @ www.NuVision.com www.nuvision.com/support Phone: (800) 890-1288 Hours: 8:30am to 5:30pm PST M-F Email: cs@nuvision.com Register your tablet today at www.nuvision.com... -
Page 25: Important Safety Instructions
10. Static discharge is normal and can occur in an electronic device. Although not life threatening, it may corrupt files or damage memory and its content. Do not use accessories that are not from Nuvision. 11. Dismantling the tablet will void the manufacturer’s warranty. If you are experiencing problems, review this quick start guide or visit the FAQ online at www.nuvision.com. -
Page 26: Compliance Information
Compliance Information FCC NOTICE The following statement applies to all products that have received FCC approval. Applicable products wear the FCC logo, and /or an FCC ID in the format FCC ID:2ADQN-TM116W on the product label. This mobile device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: This mobile device may not cause harmful interference, and this mobile device must accept any interference received, including interference that may cause undesired operation. -
Page 27: Limited Warranty
TO OBTAIN WARRANTY SERVICE Should it be necessary to contact Customer Support, call (800) 890-1288 or email at cs@nuvision.com. You will be instructed on how your claim will be processed. Have pertinent information available including proof of purchase and an understanding of the issue.
