- Page 1 ’ ’ MGC6050F Full HD Megapixel IP Camera Rev.1.0 (Dec.2013)
- Page 2 ’ ’ Directions Be careful not to cause any physical damage by dropping or throwing MGC6050F. Especially keep the device out of reach from children. Do not disassemble MGC6050F. No After Service is assumed when disassembled. Use only the power adapter provided with MGC6050F.
- Page 3 ’ ’ Caution Any changes or modifications in construction of this device which are not explicitly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Revision History Date Revision Details 2013-12-01 First manual revision creation. Rev.1.0 (Dec.2013)
-
Page 4: Table Of Contents
Contents ..................... 4 1. Introduction ..................5 1.1. Overview ....................5 1.2. Specification ................... 6 1.3. Applications of MGC6050F ................. 8 2. Product Description ................9 2.1. Contents ....................9 2.2. Product Preview ..................9 2.3. Physical description ................10 2.4. -
Page 5: Introduction
It enables real time transmission of synchronized video of up to 2 Megapixel or 3 Megapixel and audio data. Remote clients can connect to MGC6050F for the real time video/audio data through various client solutions running on PC, mobile phones. Real time 2-way communication is available through bidirectional audio communication feature. -
Page 6: Specification
’ ’ 1.2. Specification Category Sub-Category Details Compression H.264/MJPEG Video Resolution **Refer to the datasheet. 32 Kbps G.726 Audio (Bi-directional) Down 128 Kbps PCM Interface RJ-45, 10/100 Mbps, PoE (802.3af) Network Access network Static, DHCP, PPP/PPPoE Application RTP, RTSP, SMTP, FTP, HTTP, SDP, NTP, DNS RS-485 For providing RS-485 device Sensor In... - Page 7 ’ ’ IP filtering for restricting administrative Security access for audio and bi-audio Sync to PC Synchronize to PC Manual Manual time setting Time management Internet Time Server Synchronize to Time Server Day Light Saving Active-X SDK support HTTP Rev.1.0 (Dec.2013)
-
Page 8: Applications Of Mgc6050F
’ ’ 1.3. Applications of MGC6050F Security surveillance (buildings, stores, manufacturing facilities, parking lots, banks, government facilities, military, etc.) Remote monitoring (hospitals, kindergartens, traffic, public areas, etc.) Teleconference (Bi-directional audio conference). Remote Learning, Internet broadcasting Weather and environmental observation... -
Page 9: Product Description
’ 2. Product Description 2.1. Contents The product package contains followings: Contents Description Remarks MGC6050F IP camera (MGC6050F ) main unit Default built in standard PoE module 12VDC Adaptor Power Adaptor (IEEE802.3af) (Optional item) Mounting bracket and Standard mount bracket,... -
Page 10: Physical Description
’ ’ 2.3. Physical description 2.3.1. External View Figure 2-1. External view of MGC6050F 2.3.2. Rear panel Figure 2-2. Rear panel of MGC6050F Rev.1.0 (Dec.2013) -
Page 11: Functional Description
’ 2.4. Functional Description DC 12V: Power input for supplying 12V DC power. Caution: If MGC6050F is powered by PoE, do not plug in DC Jack with active DC power into DC power connector. MIC/LINE IN Connect external audio source or microphone. - Page 12 Ground of RS-232C ALARM IN/OUT and Composite Video Output Terminal block for the I/O Connection Figure 2-3 of MGC6050F Used for connecting P/T device, sensor, and composite video output. Pin assignments are as follows. Description Misc. RS-485 Plus (+)
- Page 13 ’ ’ SNS IN Examples of sensing devices are infrared sensors, motion sensors, heat/smoke sensors, magnetic sensor, etc. Connect the two wires of the sensors to “SNS In”. The sensor type (NC/NO) can be set in Administrative mode. Multiple sensor devices can be connected in parallel. Photo Coupler NO/NCType Open CollectorType...
- Page 14 A switch provided for returning the IP camera to factory default state. Press the switch for a few seconds while power is applied. Factory Default Switch Figure 2-6 Factory Default switch of MGC6050F Restoring the factory default will erase all settings. SD card slot Please insert SD memory card when you want to use SD memory card.
-
Page 15: On Site Installation
’ ’ 3. On Site Installation 3.1. Please follow through the following procedures for the installation on the wall or ceiling. 1. Fix the mounting bracket and bracket holder on the wall or the ceiling using screws. Insert the bolt on the bracket into the bracket hole and rotate the bolt clockwise to install the IP camera on the bracket... -
Page 16: Getting Started
Brief information for first time operation of MGC6050F is provided in this chapter. 4.1. PC Requirement Audio/Video streaming data received from MGC6050F can be displayed or stored in a PC running client programs. Minimum requirement of the PC is described below:... -
Page 17: Quick Installation Guide
1) Prepare a PC to run programs for the installation and video connection (PC is needed to assign IP address to MGC6050F) 2) In case of using PoE, connect the PC and MGC6050F to the network using one of the following ways. If your LAN Switch does not support standard PoE, connect... - Page 18 ’ ’ Click on the field in ③ for sorting and rearranging the list. Select network mode that best suits your case from the drop down list in ⑤. You can choose either Static or ADSL and Auto (DHCP), respectively. If ADSL and Auto are selected, the fields in ⑥...
- Page 19 3. Remote video connection to MGC6050F 1) Connection through Web Viewer Web Viewer offers simplest way of video connection to MGC6050F. For video connection, enter the IP address of MGC6050F in the URL window of Internet Explorer as: Can be omitted the [e.g.] Port 80...
- Page 20 ’ ’ 2) Connection through NVR-Pro NVR-Pro is a multi-channel CMS program for to IP camera or Video server. Install NVR-Pro on remote PC to connect to these products. It is needed to assign connection information to NVR-Pro program before connection. Details for the NVR-Pro can be found in [NVR-Pro User’s Guide]. Admin Page Button Figure 4-3.
-
Page 21: Trouble Shooting
’ ’ 5. Trouble Shooting 5.1. No power is applied In case of Standard PoE (Power over Ethernet) Power supply through standard PoE is possible only when the following conditions are met. 1. Standard PoE is supported on the product. 2. -
Page 22: Cannot Connect To The Video
’ ’ 5.2. Cannot connect to the Video Check the status of the network connection through PING test. Try the following on your PC: Start > Run > Cmd > Ping IP address (Ex : Ping 172.16.42.51) If “Reply from ~”... -
Page 23: Windows Vista Or Windows 7
’ ’ 5.3. Windows Vista or Windows 7 Windows Vista and Windows 7 users need to configure UAC (User Access Control) and Privilege Level for proper recording and still video capture in NVR-pro and Web Viewer. <Windows Vista> 1. UAC (User Access Control) configuration 1) Double-click “User Accounts”... - Page 24 ’ ’ <Windows 7> 1. UAC (User Access Control) configuration 1) Double-click “User Accounts” in control panel 2) Double-click “Change User Account Control setting” 3) Set to “Never notify” Rev.1.0 (Dec.2013)
- Page 25 ’ ’ 2. Privilege Level Control 1) Select “NVR” icon on the desktop 2) Click right mouse button and select “properties” 3) Check “Privilege Level” in “Compatibility” tab Rev.1.0 (Dec.2013)
-
Page 26: Technical Assistance
’ ’ 5.4. Technical Assistance If you need any technical assistance, please contact your dealer. For immediate service please provide the following information. 1. Model name 2. MAC address and Registration number 3. Purchase date 4. Description of the problem 5.
