CBN MDC4050IR User Manual

Full hd megapixel ip camera

Advertisement

Quick Links

M
D
C
4
0
5
0
I
R
U
s
e
r
'
s
G
M
D
C
4
0
5
0
I
R
U
s
e
r
'
s
G
MDC4050IR
Full HD Megapixel IP Camera
u
i
d
e
u
i
d
e
Rev.1.0 (Oct. 2013)
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MDC4050IR and is the answer not in the manual?

Questions and answers

Summary of Contents for CBN MDC4050IR

  • Page 1 ’ ’ MDC4050IR Full HD Megapixel IP Camera Rev.1.0 (Oct. 2013)
  • Page 2 ’ ’ Directions Be careful not to cause any physical damage by dropping or throwing MDC4050IR. Especially keep the device out of reach from children. Do not disassemble MDC4050IR. No After Service is assumed when disassembled. Use only the power adapter provided with MDC4050IR.
  • Page 3 ’ ’ Revision History Date Revision Details 2013-12-01 First manual revision creation. Rev.1.0 (Oct. 2013)
  • Page 4: Table Of Contents

    ’ Contents 1. Introduction ..................5 1.1. Overview ....................5 1.2. Specification ................... 6 1.3. Applications of MDC4050IR ................ 8 2. Product Description ................9 2.1. Contents ....................9 2.2. Product Preview ..................9 2.3. Physical description ................10 2.4. Functional Description ................12 3.
  • Page 5: Introduction

    It enables real time transmission of synchronized video of up to 2M pixels and audio data. Remote clients can connect to MDC4050IR for the real time video/audio data through various client solutions running on PC, mobile phones. Real time 2-way communication is available through bidirectional audio communication feature.
  • Page 6: Specification

    ’ ’ 1.2. Specification Camera Module Image sensor Progressive scan 1/2.9 inch CMOS 2.0M pixels Full resolution 1,920 x 1,080 pixels (Full HD) Min. illumination Color : 0.12 Lux (F 1.4) / IR LED on : 0Lux S/N Ratio 50dB or more White Balance Sync System Internal...
  • Page 7 ’ ’ External Terminals 10/100BaseT LAN (auto MDIX) Analog output 1 channel D1 CVBS output of the encoding video Alarm input / output Alarm I/O (1 Sensor input & 1 Relay output) Factory Reset Supported other MIC, Line in / Line out / 12VDCin Installation Standard PoE (IEEE802.3af) Supported...
  • Page 8: Applications Of Mdc4050Ir

    ’ ’ 1.3. Applications of MDC4050IR  Security surveillance (buildings, stores, manufacturing facilities, parking lots, banks, government facilities, military, etc.)  Remote monitoring (hospitals, kindergartens, traffic, public areas, etc.)  eleconference (Bi-directional audio conference). Remote Learning, Internet broadcasting  Weather and environmental observation...
  • Page 9: Product Description

    2. Product Description 2.1. Contents The product package contains followings : Contents Description Remarks MDC4050IR IP camera MDC4050IR main unit Tools and Mounting Screws Software & User’s Guide Quick Reference Guide Quick installation guide Default built in standard PoE module 12VDC Adaptor Power Adaptor (IEEE802.3af)
  • Page 10: Physical Description

    ’ ’ 2.3. Physical description 2.3.1. External View 2.3.2. Switch and Controls This shows Camera module inside the dome cover. Network Connector Analog Video Output (Yellow) Power Terminal (Red) Rev.1.0 (Oct. 2013)
  • Page 11 ’ ’ Micro SD card slot Status LED Factory Default Switch Input/Output Connector - Relay out - Relay out - Sensor Input(-) - Sensor Input (+) - Line Output - GND - MIC / Line Input Rev.1.0 (Oct. 2013)
  • Page 12: Functional Description

    ’ 2.4. Functional Description  Power : Power input for supplying 12V DC, 1A power. Caution : If MDC4050IR is powered by PoE, do not plug in DC Jack with active DC power into DC power connector.  Network connector 100Mbps Ethernet connector (RJ-45) with PoE standard (802.3af).
  • Page 13 ’ ’  Relay Output Relay output is provided for connecting alarm devices or for remote on/off control of devices such as light. Relay is normal open and it will be closed upon alarm annunciation or remote on. The relay is capable of switching 30V AC/DC, 2A.
  • Page 14: On Site Installation

    ’ ’ 3. On Site Installation 3.1. 1. Open the dome cover 2. Make a hole for cables. 3. Connect cables * After supplying power (DC or PoE), check the LED indicator 4. Fix the camera on wall or ceiling using screw provided. 5.
  • Page 15: Getting Started

    Brief information for first time operation of MDC4050IR is provided in this chapter. 4.1. PC Requirement Audio/Video streaming data received from MDC4050IR can be displayed or stored in a PC running client programs. Minimum requirement of the PC is described below:...
  • Page 16: Quick Installation Guide

    1) Prepare a PC to run programs for the installation and video connection (PC is needed to assign IP address to MDC4050IR) 2) In the case of using PoE, connect the PC and MDC4050IR to the network using one of the following ways.
  • Page 17 ’ ’ Click on the field in ③ for sorting and rearranging the list. Select network mode that best suits from the drop down list in ⑤. You can choose either Static or ADSL and Auto (DHCP), respectively. If ADSL and Auto are selected, the fields in ⑥ is deactivated.
  • Page 18 3. Remote video connection to MDC4050IR 1) Connection through Web Viewer Web Viewer offers simplest way of video connection to MDC4050IR. For video connection, enter the IP address of MDC4050IR in the URL window of Internet Explorer as: Can be omitted the [e.g.] Port 80...
  • Page 19 ’ ’ 2) Connection through NVR-Pro NVR-Pro is a multi-channel CMS program for to IP camera or Video server. Install NVR-Pro on remote PC to connect to these products. It is needed to assign connection information to NVR-Pro program before connection. Details for the NVR-Pro can be found in [NVR-Pro User’s Guide]. Admin Page Button Figure 4-3.
  • Page 20: Trouble Shooting

    ’ ’ 5. Trouble Shooting 5.1. No power is applied  In case of Standard PoE (Power over Ethernet) Power supply through standard PoE is possible only when the following conditions are met. 1. Standard PoE is supported on the product. 2.
  • Page 21: Cannot Connect To The Video

    ’ ’ 5.2. Cannot connect to the Video Check the status of the network connection through PING test. Try the following on your PC : Start > Run > Cmd > Ping IP address (Ex : Ping 172.16.42.51) If “Reply from ~”...
  • Page 22: Windows Vista Or Windows 7

    ’ ’ 5.3. Windows Vista or Windows 7 Windows Vista and Windows 7 users need to configure UAC (User Access Control) and Privilege Level for proper recording and still video capture in NVR-pro and Web Viewer. <Windows Vista> 1. UAC (User Access Control) configuration 1) Double-click “User Accounts”...
  • Page 23 ’ ’ <Windows 7> 1. UAC (User Access Control) configuration 1) Double-click “User Accounts” in control panel 2) Double-click “Change User Account Control setting” 3) Set to “Never notify” Rev.1.0 (Oct. 2013)
  • Page 24 ’ ’ 2. Privilege Level Control 1) Select “NVR” icon on the desktop 2) Click right mouse button and select “properties” 3) Check “Privilege Level” in “Compatibility” tab Rev.1.0 (Oct. 2013)
  • Page 25: Technical Assistance

    ’ ’ 5.4. Technical Assistance If you need any technical assistance, please contact your dealer. For immediate service please provide the following information. 1. Model name 2. MAC address and Registration number 3. Purchase date 4. Description of the problem 5.
