REMOTE KEYPAD with NFC Tag (KPT-32N, KPT-32N-F1)
Identifying the Parts
1. Siren
2. Orange LED: Home Arm Key
3
Red LED: Away Arm Key
.
4. Panic Alarm (if enabled)
- Press both 1 and 3 to trigger panic alarm
5. Fire Alarm (if enabled)
- Press both 4 and 6 to trigger fire alarm
6. Medical Alarm (if enabled)
<NOTE>
A short beep will sound along with key pressing to indicate that the button pressed is valid.
A long beep will sound along with key pressing to indicate successful command.
4 continuous beeps will sound indicating mistake and the user should repeat the process again.
Backlight will be ON for any key pressed or command sent from the Keypad.
LED Indicator
Red LED (Away Arm Key)
Red LED on: the system is in Test Mode.
Red LED: Red flashes, and Backlight on in the Away Arm Mode.
Red LED flash with 4 beeps: failure due to the following reasons:
No response from the control panel.
Request for Home mode during Arm mode.
Request for Force arm.
Orange LED (Home Arm Key)
Orange LED: Orange flashes and backlight on in the Home Mode.
Orange LED flashes for 5 seconds: low battery in Normal Operation Mode, and Tamper open.
LED flash with 4 beeps: failure due to the following reasons:
No response from the control panel.
Request for Home mode during Arm mode.
Request for Force arm.
- Press both 7 and 9 to trigger Medical alarm
7.
Key
- Enter Keypad PIN Code +
8. Keypad Sensor (for tag)
9. NFC Tag
10. # Key
11. Mounting Holes
12. Tamper Switch
1
April 01st, 2016
Key to enter Test Mode.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KPT-32N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Climax Technology KPT-32N

Summary of Contents for Climax Technology KPT-32N

  • Page 1 REMOTE KEYPAD with NFC Tag (KPT-32N, KPT-32N-F1) April 01st, 2016 Identifying the Parts 1. Siren - Press both 7 and 9 to trigger Medical alarm 2. Orange LED: Home Arm Key Red LED: Away Arm Key - Enter Keypad PIN Code + Key to enter Test Mode.

  • Page 2: Power Saving Feature

    <NOTE> When Arm/Home, Red/Orange LED will turn off after successful completion of a valid keystroke sequence, or when the pause in between Control panel User code/PIN code keystrokes exceeds 2 seconds along with 4 beeps. If Arm/Home button is pressed but no Control Panel User Code/PIN code is entered, in 5 seconds the keypad will enter sleep mode.

  • Page 3: Tamper Protection

    Press ＊ key and then 7 key to transmit learn code to Control Panel. Refer to Control Panel manual to complete Step 3. the learning process. If learning is successful, the Keypad will emit 3 beeps upon receiving acknowledgement signal from Control Panel. If the Keypad does not sound 3 beeps, please restart learning procedure from Step 1.

  • Page 4: Change Of Battery

    Mounting Remote Keypad To mount the remote keypad: Remove the front cover. Using the 2 mounting holes of the back cover as a template, mark off the positions in the most appropriate place. III. Insert the wall plugs if fixing into plaster or brick surface. IV.
  • Page 5 When incorrect Keypad PIN code is entered to enter Test mode, The Keypad will emit 4 beeps. If incorrect Keypad PIN codes are entered for 4 times, the Keypad will disable key input function for 1 minute and indicate error by flashing all LEDs for 6 times and emitting 6 beeps.
