EVERSPRING ST113 User Manual

Solar-powered wireless pool alarm
Hide thumbs Also See for ST113:

Advertisement

Quick Links

SOLAR-POWERED POOL ALARM SYSTEM FOR SAFETY AID
TO READ ATTENTIVELY AND TO PRESERVE FOR FUTURE CONSULTATION
WARNING
This system is simply a safety aid which announces a danger (or risk of danger) when an
equivalent of 8kgs (18 pounds) object falls into a unsupervised swimming pool. The fast
intervention in less than 3 min of a responsible adult is obligatory when the signal of alarm
happens. Ensure the construction of the pool wall is solid enough, thus it can stand the drilling
of the screws and wall plugs without cracking the pool wall. After installation, ensure the pool
alarm itself cannot be shaken, otherwise it will affect the performance of pool alarm detection. In
the event of any injury or death to any person arising out of misuse, abuse, negligence, accident
or alteration, Everspring Tech USA, Inc., will not be liable for any consequence caused.
This system does not replace the good direction nor with the several liability. The purpose of it is
not to either replace the vigilance of the parents and/or the responsible adults, which remains the
essential factor for the protection of the children with less than five years;
The user who turns OFF the system must be conscious that the human monitoring must take
The greatest vigilance of the responsible parent /adult is necessary between the end of the bathe
Never leave children unattended in or around the swimming pool or spa. Children under five years of
age are at the greatest risk for injury or death in pool-related accidents.
In the event of possibility of stroke with against current: "Cancel the stroke with against current at
the end of the bathe to allow the reactivation of the product".
Some of cleaning robots as a plunger robots type are incompatible with the systems of detection
It is imperative to react when the signal of alarm happens;
and the reactivation of the product;
over;
of immersion
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ST113 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for EVERSPRING ST113

  • Page 1 Everspring Tech USA, Inc., will not be liable for any consequence caused. This system does not replace the good direction nor with the several liability. The purpose of it is not to either replace the vigilance of the parents and/or the responsible adults, which remains the essential factor for the protection of the children with less than five years;...
  • Page 2: Product Layout

    PRODUCT LAYOUT Solar-powered Wireless Pool Alarm (ST113) Battery Cover Solar Panel Start Button Base Sensing Compartment Detachable Tube Wireless Keypad (SA802) Setting/Low Battery LED Keypad Function Key Function Key Description Sequence System Off System On Auto Disarm the alarm sound...
  • Page 3: Package Content

    Siren & Strobe (SE802) Strobe Light Red & Green LED ( when both LEDs are on, the LED will be converted into orange color) Tamper Switch Learning Key DC Jack Two-Phase Sound Jumper Link Anti-jamming Jumper Link Tamper Jumper Link Mounting Bracket The kit includes one piece each of Solar-powered Wireless Pool Alarm, Siren &...
  • Page 4 Solar-powered Item wireless pool alarm system(ST113) Base Initiation key LR20 Alkaline Battery Solar Panel with Ni-MH AA 6V Rechargeable battery Detachable tube (φ4.7x30mm) Screw Plastic wall plug Siren & Strobe (SE802) (φ3 x 18mm) Screw Plastic wall plug 1.5V LR14 14A Size C Wireless Keypad (SA802) (φ3 x 18mm) Screw...
  • Page 5 4.5cm Under Water level 24.5cm Sensing Compartment Tube Base 1. Locate the appropriate (plain and not very grassy) place to fix the unit on the top rail of the swimming pool. For the above ground pool, the unit must be installed at a height of 1.5m (59 inch) above the ground. 2.
  • Page 6: Loading The Battery

    4. Use the base as a template to mark the position of four fixing holes. Drill four 30mm fixing hole and fit the plastic wall plugs to the holes. 5. Aim the base to the place where four plastic wall plugs are situated. Fasten the base using the fixing screws supplied.
  • Page 7: Wireless Keypad

    Replace the battery cover and fixing screws. Refit the rubber stoppers. Note: Reverse battery cover cannot fit to the compartment. Power Cord DC Jack WIRELESS KEYPAD The Wireless Keypad is used to control the Pool Alarm by using a four digit Administrator password. The Keypad is powered by 3 x AA 1.5V alkaline battery.
  • Page 8 2. Using the mounting bracket as a template, mark the positions of the two fixing holes on the wall. 3. Fix the mounting bracket to the wall using the screws and wall plugs provided. Do not over-tighten the fixing screws as this may distort or damage the mounting bracket. 4.
  • Page 9: Changing The Administrator Password

    Note: The Keypad is supplied with a default Administrator password of: 1234. For security reasons, it is recommended that this password is changed to another four digit number which only you and other users of the system know. Note: The Keypad has back light illumination facility. The back light of digit number 0~9 won’t be off until 5-second illumination duration expires each time when you press any key.
  • Page 10 is within the effective range of Pool Alarm. INSTALLING AND CONFIGURING THE SIREN & STROBE (1) Undo and remove the fixing screws from the mounting bracket. (2) Place 4 x 1.5V alkaline LR14 batteries to the battery compartment. Ensure that correct polarity of the batteries is inserted.
  • Page 11: Operating Instructions

    seconds. When this occurs, the batteries should be replaced as soon as possible. (8) In order to detect any attempts to illegally jam the radio channel used by your alarm system, a special jamming detection function is incorporated into the unit. There are two types of jamming detection.
  • Page 12: Initial Power-Up

    Typical examples of installation are shown below: Be sure that the Pool Alarm is not installed next to any pool features (jets, water features, etc.) that may cause disturbance. Be sure that the Pool Alarm can be accessed easily. INITIAL POWER-UP When powering up initially, the Pool Alarm will enter the armed mode straight away.
  • Page 13 Start Button Auto Auto Initiation Key 2. The Pool Alarm will instantly be monitoring your pool for an intrusion. 3. Using the Wireless Keypad: Press Administrator password 4. In case of unwanted intrusions into a swimming pool, the Pool Alarm will generate a full alarm condition, while the auxiliary Siren &...
  • Page 14: Auto Mode

    Press dministrator password AUTO MODE 1. Press and hold the start button by turning the initiation key from OFF AUTO OFF. 3 bleeps can be heard as a confirmation after releasing the start button. The Pool Alarm will enter the auto mode. Prior to entry into the pool, user may either turn off the unit or set the unit to auto mode.
  • Page 15 4. Using the Wireless Keypad Press Administrator password After the Alarm sound is disarmed, the Pool Alarm will enter armed mode straight away. LEARNING THE ID CODE In order to prevent any unauthorized attempt to operate or disarm your system, you must configure your system to accept radio signals only from your own system devices.
  • Page 16 DC Jack Learning Key CLEANING OUT THE PRESET ID CODE Pool Alarm Press and hold the learning key on the Pool Alarm for more than 6 seconds will clean out the preset ID code. 1 bleep can be heard as an acknowledgement. Siren &...
  • Page 17 interval and bleep 0.1 second at 30 second interval Low battery indication (under armed Bleep 0.5 second and illuminating LED 0.5 second at mode) 30 second interval Keep pressing start button Orange illuminating LED Learning the ID code period Orange slow flashing LED Alarm activation Red illuminating LED QUICK GUIDELINE FOR LED INDICATION AND BLEEP SOUND ON THE...
  • Page 18 back light 0~9 extinguish back light 0~9 flashing 3 times Auto mode back light 0~9 extinguish back light 0~9 flashing 3 times Disarming the alarm sound Pressing any key or back light 0~9 will be on function key Learning the ID code back light 0~9 extinguish and 4 back light 0~9 flashing 3 times mode...
  • Page 19: Replacing The Batteries

    - store the pesticides of water out of the range of the children; - certain systems of stroke with against current do not allow the automatic reactivation of the system of detection of immersion; - certain robots of cleaning of plunger the robots type are incompatible with the systems of detection of immersion;...
  • Page 20: Periodic Testing

    If your pool is located in an area where freezing normally occurs and you do not intend to maintain your pool in a heated state throughout the winter season, you should remove the unit before freezing occurs. Store the unit indoors and re-install when the water has thawed. Be sure to remove the batteries from the unit when placing it in storage for a prolonged period.
  • Page 21 Abnormal activation Tube is not saturated by 1. Reallocate the mounting position enough water level of the unit 2. Add an extra tube 3. Add much water to the pool thus enhancing water level LED indicator not working on Did not fit the batteries or Check if the batteries are fitted or the Siren &...
  • Page 22: Specifications

    SPECIFICATIONS Model No. ST113 Solar-powered Wireless Pool Alarm Item Siren Twin piezo siren Siren Output 110 dB / 1 meter Effective Pool Alarm 4m x 8m (157.5 inch x 315 inch), subject to Min. 6 kgs (13 pounds) object Dimension...
  • Page 23: Warranty

    This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
  • Page 24 Damage due to a natural disaster, floods or vandalism. CONTACT US Please feel free to write or call us with your comments or questions at the address below. Everspring Tech USA, INC 3200 Wilshire Blvd. South Tower, STE# 1730 Los Angeles, CA. 90010 Tel: (626) 698-1898, Fax: (626) 956-0600 Email: steve_chang@everspring.com...
  • Page 25 Customer Title (Mr/Ms) First Name Middle Initial Last Name Address Zip Code City Country Email Telephone (area code) Fax (area code) - - Retailer Name Date of purchase City Country Model No...
