K13440
Base top
1 pcs
K13445
Base top
1 pcs
L06460 Mano
Door
1 pcs
Bumper
Dowel
7x1,5 mm
8x30 mm
1 pcs
8 pcs
Allen key
4 mm
1 pcs
17-07-2013 1
/
DCS64,***,***
K13424
Side
1 pcs
K13973
Cover
1 pcs
Mounting plate
2 pcs
BP00029
Magnet
45,5x14,5x13
1 pcs
Screw flh
Screw rh
3x12 5
3x16 mm
1 pcs
2 pcs
MC659
K13425
Side
1 pcs
K13444
Shelf
2 pcs
Hinge
107 degrees
2 pcs
Plate for magnet
Screw flh
35x12x1
3,5x45 mm
1 pcs
10 pcs
K13442
Back panel
1 pcs
K13360
Suspension list
1 pcs
Screw confirmat
10x50
2 pcs
1 /
9
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Kvik MC659
Summary of Contents for Kvik MC659
- Page 1 MC659 DCS64,***,*** K13440 Base top K13442 K13424 K13425 Back panel Side Side 1 pcs 1 pcs 1 pcs 1 pcs K13360 K13445 K13973 K13444 Suspension list Base top Cover Shelf 1 pcs 1 pcs 2 pcs 1 pcs L06460 Mano...
- Page 2 MC659 FIG. K13425 Side Magnet Screw ph 45,5x14,5x13 3x16 mm 1 pcs 2 pcs Dowel 8x30 mm 2 pcs FIG. K13424 Side Dowel 8x30 mm 2 pcs 17-07-2013 1...
- Page 3 MC659 FIG. K13440 K13425 Base top Side Screw flh 3,5x45 mm 4 pcs K13360 Suspension list K13445 Base top K13424 Side OBS!!! FIG. Dowel 8x30 mm 4 pcs K13444 Shelf K13444 Shelf K13442 Back panel 17-07-2013 1...
- Page 4 MC659 FIG. Screw flh 3,5x45 mm 6 pcs FIG. Screw flh 3x12 5 Plate for magnet 35x12x1 17-07-2013 1...
- Page 5 MC659 FIG. Push, and the screw will make a mark on the backside, to use to mount the plate for magnet FIG. Screw flh 3x12 5 Use mark Plate for magnet 35x12x1 17-07-2013 1...
- Page 6 MC659 FIG. Click FIG. Click Hinge 107 degrees 2 pcs Mounting plate 2 pcs Bumper 7x1,5 Bumper 7x1,5 L06460 Mano Door L06460 Mano Door 17-07-2013 1...
- Page 7 MC659 FIG. Left L06460 Mano Door FIG. Left K13973 Cover 17-07-2013 1...
- Page 8 MC659 FIG. Right L06460 Mano Door Right K13973 Cover 17-07-2013 1...
- Page 9 MC659 Allen key 4 mm Screw confirmat 10x50 2 pcs Adjustment 17-07-2013 1...
