Summary of Contents for Excera EM8100 U2
-
Page 2: Table Of Contents
Contents Important Information Bluetooth Alert Icon Disabled Frequencies Digital Conventional Functions and Operations Checking Items in the Package Call Getting Started Private Call Installation Group Call Installation Diagram All Call Product Overview Scan Radio Controls Scan Start Condition Palm Microphone Scan List Scan Tx Mode LED Indicator... - Page 3 Contents Preset Msg Contact Status Msg Private Call Contact Group Call Contact Color Code New Contact Call Log Message Zone Analog Conventional Functions and Operations Inbox Outbox DMO and RMO CTCSS/CDCSS Type Drafts New Msg CTCSS Preset Msg CDCSS Status Msg CDCSS Invert Call Log Squelch Level...
- Page 4 Contents Contents Channel Information Hunt Subgroup Short Hunt Comprehensive Hunt Authentication Remote Remove Radio Service Team Hunt Background Hunt Remote Change Radio Service Emergency Team Hunt List Emergency Call Fixed TSCC List Emergency Alarm TSCC Hunt MPT Trunking Functions and Operations Channel Information Registering Subgroup...
-
Page 5: Important Information
Important Information Before using this product, please read this user manual carefully. ■ Alert Icon Caution: Indicates situations that could cause human injury or damage to your products. Note: Indicates tips that can help you make better use of your products. Caution: This radio is restricted to occupational use only to satisfy FCC RF energy exposure requirements. -
Page 6: Checking Items In The Package
Checking Items in the Package Please unpack carefully and check that all items listed below are received. If any item is missing or damaged, please contact your dealer. Radio Palm Microphone Fuse Microphone Hanger and Screws Mounting Bracket Kit Power Cord User Manual... -
Page 7: Getting Started
Getting Started ■ Installation Installation Diagram Part Name Bracket Locking Knob Screws Radio RF Antenna Power Inlet GPS Antenna Power Supply Microphone Jack Fuse 1. Slide the radio into the mounting bracket and secure it using the locking knobs. 2. Connect the palm microphone to the radio. 3. -
Page 8: Product Overview
Getting Started ■ Product Overview Radio Controls Part Name Part Name Part Name ① ⑦ ⑭ Microphone Jack P2 Key Locking Knob ② ⑧ ⑮ TK (Top Key) P1 Key RF Antenna Connector Volume Control ⑨ ⑯ Setting Key Power Inlet ③... -
Page 9: Palm Microphone
Getting Started Palm Microphone Part Name Part Name ③ ① Microphone Hanger PTT Key ④ ② Microphone Fixing Button Microphone... -
Page 10: Led Indicator
Getting Started ■ LED Indicator Icon Icon Name LED Indicator Radio Status Medium Power LED flashes green slowly. None Low Power LED flashes green rapidly. Upgrading or powering on Roam LED glows green. Receiving LED flashes red rapidly. None Glonass Missed Call LED glows red. -
Page 11: Menu Navigation
Menu Navigation ■ ■ Mode Date and Time Your radio can operate in either of these modes: You can set date and time for your radio. Conventional (digital and analog), DMR Trunking, and MPT To access this item, press the Setting key in the home Trunking. -
Page 12: Display
Menu Navigation ■ ■ Noise Reduction Display This option can reduce background noise during This option allows you to set display parameters, including Backlight Off Time, Display Off Mode, and Brightness. communication so as to enhance voice clarity. To access this item, press the Setting key in the home You can set this function via the CPS or the radio menu. -
Page 13: Bluetooth
Menu Navigation ■ Bluetooth ● When your radio is successfully connected to a Bluetooth headset and a Wireless PTT , the Bluetooth headset and This feature allows you to use your radio with a Bluetooth Wireless PTT connected icon appears on the status -enabled device (such as Bluetooth headset and Wireless bar. -
Page 14: Gps
Menu Navigation ■ With this option, you can allow your radio to receive its GPS information from the GPS chipset and upload the information to the system after receiving GPS upload request. To enable or disable this feature, press the Setting key in the home screen and then select "Accessories ->... -
Page 15: Digital Conventional Functions And Operations
Digital Conventional Functions and Operations Late Entry Call ■ After a private call is established, it allows other radios to join To ensure that your speech is clear, keep the microphone this private call on this channel. 2.5 to 5 cm from your mouth. Late Entry may occur in any of the following situations: Private Call ●... -
Page 16: All Call
Digital Conventional Functions and Operations ● ■ radio is powered on. Scan ● The Channel Selector knob is rotated to the channel in Scan Start Condition operation. ● You can start scan only when more than one channel radio exits from another group call. ●... -
Page 17: Priority Channel 1
Digital Conventional Functions and Operations Priority Channel 1 Scan Delay This option allows you to select a channel in the scan list as This option enables you to set the time that the radio will Priority Channel 1. If only Priority Channel 1 is set, 50% of a resume scanning after the end of a valid channel activity. -
Page 18: Emergency
Digital Conventional Functions and Operations Emergency Emergency Alarm ■ Emergency is used to summon help in emergency situations. If the Emergency Alarm option is selected, your radio only Your radio supports two types of emergency modes: sends emergency alarm requests upon emergency activation. Emergency Call and Emergency Alarm. -
Page 19: Message
Digital Conventional Functions and Operations ■ Message When the Outbox is full, the oldest message will be overwritten by the latest one automatically. To access this item, press the Menu key in the home screen and then select "Message". Drafts The Drafts can save up to 100 draft messages. -
Page 20: Color Code
Digital Conventional Functions and Operations ■ Color Code ● To delete all call entries in the Missed/Incoming/Outgoing Call list, select "Call Log -> Missed/Incoming/Outgoing Color code is used to identify a system. Users who wish to Call -> Selected Call -> Delete All". communicate with each other are assigned with the same color code. -
Page 21: Analog Conventional Functions And Operations
Analog Conventional Functions and Operations ■ ■ DMO and RMO CTCSS/CDCSS Type This option allows you to configure the current channel with Your radio supports both DMO and RMO modes. a specific Rx CTCSS/CDCSS type. When the radio receives ● DMO: You can set the Rx frequency of your radio to be the signal, it will distinguish whether the received signal is consistent with the Tx frequency using the CPS. -
Page 22: Cdcss Invert
Analog Conventional Functions and Operations CDCSS ■ Squelch Level The radio checks for CDCSS match when receiving a signal This option can reduce background noise by adjusting the on the current channel. squelch level when the radio is receiving signals. You may Follow the procedure below to set CTCSS/CDCSS Type to set the squelch level to Tight, Normal, or Open using the CDCSS. -
Page 23: Dmr Trunking Functions And Operations
DMR Trunking Functions and Operations Note: A license is required for accessing the DMR ● The radio registers with another base station. trunking system. Contact your dealer for details. ■ Call ■ Registering To ensure that your speech is clear, keep the microphone The radio will register with a proper base station automatically 2.5 to 5 cm from your mouth. - Page 24 DMR Trunking Functions and Operations ● Making a Call through Contact or Call Log Receiving a Private Call Procedure: When a private call is received, the alert tone is given and 1. Press the Menu key to enter the main menu. the incoming call icon is displayed on the LCD display.
-
Page 25: Group Call
DMR Trunking Functions and Operations ● The calling party ends the ongoing call. Conversation Limit ● Signal of base station is missing. When a private call is established, both the calling party and the called party will display the call duration in real time. Group Call Making a Group Call You can make a group call through any of the following... - Page 26 DMR Trunking Functions and Operations ● ● Making a Call through Redial or Backdial List The Group Call Selector knob is rotated to the group in operation. Procedure: ● The radio exits from another group call. 1. In the home screen, press the key to access ●...
- Page 27 DMR Trunking Functions and Operations Conversation Limit Ending a Call When a group call is established, both the calling party and The voice communication will be terminated when one of the the called party will display the call duration in real time. following situations occurs: ●...
-
Page 28: Emergency Call
DMR Trunking Functions and Operations Emergency Call Priority Call In the normal voice calls, priority call has the highest priority. Emergency Call can be either emergency private or group You may follow the procedure below to make a priority call. call. -
Page 29: Contact
DMR Trunking Functions and Operations ■ Contact Group Call Contact You can save up to 256 entries of group call contact To access this item, press the Menu key in the home screen information in the list. To access this list, select “Contact -> and then select “Contact”. -
Page 30: Message
DMR Trunking Functions and Operations ■ Message When the Outbox is full, the oldest message will be overwritten by the latest one automatically. To access this item, press the Menu key in the home screen and then select “Message”. Drafts The Drafts can save up to 100 draft messages. -
Page 31: Call Log
DMR Trunking Functions and Operations ■ Call Log Either of the two lists can save up to 10 entries. When the list is full, the oldest entry will be overwritten by the latest one To access this item, press the Menu key in the home screen automatically. -
Page 32: Backdial List
DMR Trunking Functions and Operations Backdial List ■ Hunt All incoming calls are saved in the Backdial List. In the DMR system, the terminal is required to register with a base station for normal work. Before registering, the terminal will hunt through the control channels for available base stations. -
Page 33: Team Hunt
DMR Trunking Functions and Operations is achieved after comprehensive hunt, the hunt will go on with channel on which the radio currently registers is lost, it the Fixed TSCC List. The hunt process will cycle until the will hunt through the channels available in the saved radio successfully registers with a base station. -
Page 34: Subgroup
DMR Trunking Functions and Operations ■ ■ Remote Remove Radio Service Subgroup A subgroup is a group of group call contacts. Your radio The authorized dispatcher is able to permanently disable a radio remotely. The disabled radio cannot perform any supports up to 2048 group call contacts and 32 subgroups, operation (including requesting or receiving calls or SMSs) with a maximum of 64 group call contacts per subgroup. -
Page 35: Emergency
DMR Trunking Functions and Operations ■ Emergency Emergency Call Emergency Alarm If the Emergency Alarm option is selected, your radio only If the Emergency Call option is selected, your radio only sends emergency alarm requests upon emergency activation. transmits emergency call upon emergency activation. You may follow the procedure below to initiate an emergency You may follow the procedure below to initiate an emergency alarm. -
Page 36: Mpt Trunking Functions And Operations
MPT Trunking Functions and Operations ■ Note: A license is required for accessing the MPT Call trunking system. Contact your dealer for details. To ensure that your speech is clear, keep the microphone ■ Registering 2.5 to 5 cm from your mouth. The radio will register with a proper base station automatically Private Call according to CPS configuration after power-on. - Page 37 MPT Trunking Functions and Operations ● Making a Call through Redial or Backdial List Voice Communication Procedure: After a private call is established, either the calling party or 1. In the home screen, press the key to access the called party can make a voice call only if the PTT key is the Redial or Backdial List.
-
Page 38: Group Call
MPT Trunking Functions and Operations ● Ending a Call Making a Call ia Manual Dial Procedure: The voice communication will be terminated when one of the 1. In the home screen, input a group call number using following situations occurs: the keypad. - Page 39 MPT Trunking Functions and Operations Late Entry Join a Group Call via Manual Dial After a group call is established, it allows other group You can initiate a group call by inputting the group ID that is members to join this call. not covered in Group Call Contact using the keypad.
-
Page 40: All Call
MPT Trunking Functions and Operations programmed by your dealer. The group call will be All Call terminated automatically when the preset time expires. All Call in System is available in the MPT system. ● At the Called Party The called party displays the actual communication time. All Call in System The timer starts counting once the called party joins the 1981 is the All Call in System number. -
Page 41: Broadcast Call
MPT Trunking Functions and Operations ■ Broadcast Call Call Log Broadcast call can only be broadcast group call. In a To access this item, press the Menu key in the home screen broadcast call, the calling party can only transmit voice and then select “Call Log”. -
Page 42: Redial Or Backdial List
MPT Trunking Functions and Operations ■ Redial or Backdial List ● To delete all call entries in the list, select "Redial List -> Selected Call -> Delete All". To access the Redial or Backdial List, press the in the home screen. Either of the two lists can save up to 10 Backdial List entries. -
Page 43: Hunt
MPT Trunking Functions and Operations ■ Hunt with the Fixed TSCC List. The hunt process will cycle until the radio successfully registers with a base station. In the MPT system, the terminal is required to register with a base station for normal work. Before registering, the terminal will hunt through the control channels for available base Team Hunt stations. -
Page 44: Team Hunt List
MPT Trunking Functions and Operations Team Hunt List TSCC Hunt With this option, you can enable your radio to register with a This option is used to determine whether a selected channel base station by inputting the ID of an available control team to be searched repeatedly during radio registration. -
Page 45: Subgroup
MPT Trunking Functions and Operations ■ ■ Subgroup Emergency A subgroup is a group of group call contacts. Your radio Your radio supports one emergency mode: Emergency Call. supports up to 2048 group call contacts and 32 subgroups, You may follow the procedure below to initiate an emergency with a maximum of 64 group call contacts per subgroup. -
Page 46: Optional Accessories
Optional Accessories The following items are the main optional accessories for the product. Consult your local dealer for more other accessories. GPS Antenna Wireless PTT Bluetooth Headset Programming Cable Sucker Antenna EAS157501 EPTTB01 EEWB03E EPC02 Vehicle Remote Control Motorcycle Remote Control Keypad Microphone Power Supply Head Mount Kit... -
Page 47: Troubleshooting
Troubleshooting Phenomena Solution Analysis The battery may be improperly installed. Remove the battey and attach it again. The radio cannot be The battery may run out. Recharge or replace the battery. powered on. The battery may suffer from poor contact Clean the battery contacts. -
Page 48: Limited Warranty
What This Warranty Covers and for How Long Shenzhen Excera Technology Co., Ltd. warrants the Excera manufactured products listed below against defects in material and workmanship under normal use and service for a period of time from the date of purchase as scheduled below:... -
Page 49: Warranty Card
Warranty Card Purchase Information Customer Name: Customer Phone: Customer Address: Purchase Date: Radio Information Model Number: Serial Number: Note: This warranty card applies to after-sale and maintenance services for the product and accessories described above. ● ● You must provide this warranty card and purchase invoice in order to get warranty services. ●... -
Page 50: Fcc Statement
FCC Statement been approved by FCC to operate with the antenna types listed below with This radio transmitter has gain(3.5dBi) and required antenna impedance for each antenna type the maximum permissible indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated(3.5dBi) for that type, are strictly prohibited for use with this device.
