Module 2 (Amplitude)

Module 2 lets you design your own amplitude-based modulation effect.
1. Topology
Select the type of effect you want. The units
used for parameter values, or the actual
parameters themselves, may differ for each
control depending on the type of effect you
select, as explained below.
2. Time Sync Display Panel
When the BPM switch is on, the Time Sync
panel will display the value of the Rate knob as
a time division corresponding to the global
BPM set in BIAS Pedal software. When the
BPM switch is off, the Time Sync panel
displays the value of the Rate knob in Hz
(Hertz, or cycles per second).
3. BPM Sync Switch
Sets the Rate knob to adjust Hz or the time
division corresponding to the global BPM.
4. Intensity
Adjusts the dry/wet mix. When the Intensity
knob is set to its maximum value (all the way to
the right), the signal is 100% wet and you are
only hearing the processed (effect) signal.
37
5. Tone
Controls a "tilt" filter (bipolar shelving filter).
Turning the Tone control clockwise from its
noon position attenuates low frequencies while
simultaneously boosting highs. Turning the
Tone control anti-clockwise has the opposite
effect, boosting low frequencies while simulta-
neously cutting highs.
6. Rate
[Tremolo, Pan, Auto Swell]
Adjusts the oscillation speed of the LFO.
[RingMod]
Adjusts the oscillation speed that modulates the carrier frequency.
7. Depth
[Tremolo, Pan]
Adjusts the oscillation depth of the LFO.
[RingMod]
Adjusts the oscillation depth that modulates the carrier frequency.
[Auto Swell]
Adjusts the threshold/sensitivity to produce a slow attack.
8. Wobble
[Tremolo, Pan]
Adjusts the secondary LFO. Turning on Wobble results in some randomness in the Depth setting .
[RingMod]
Sets the carrier frequency; this has a very prominent effect on the RingMod sound.
[Auto Swell]
Sets the depth of the secondary LFO, adding tremolo to the slow-attack sound.
