DA DA1280 Manual

Cordless telephone plug
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DA1280
DECT and CAT-iq
Page
3
Start-Up with DECT GAP Basisstation
4
connect analog terminal
5
operation : telephone, Telefax
6
operation : Hints
7
switch into ex-works-setup
8
change ex-works-setup parameters: Method 1
9
Configuration Codes
10
change ex-works-setup parameters: Method 2
11
connectors, LED ,...
12
Questions and Answers (FAQ)
13
Security Advices
14
Warranty
15
Recycling
16
CE Conformity
cordless telephone PLUG
Software Upgrade
Manual
-1-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DA1280 and is the answer not in the manual?

Questions and answers

Summary of Contents for DA DA1280

  • Page 1 DA1280 cordless telephone PLUG DECT and CAT-iq Manual Page Start-Up with DECT GAP Basisstation connect analog terminal operation : telephone, Telefax operation : Hints switch into ex-works-setup change ex-works-setup parameters: Method 1 Configuration Codes change ex-works-setup parameters: Method 2 connectors, LED ,…...
  • Page 2 Call, Fax or Data to your WAN destination. All you have to do is to make your DA1280 “acquainted” with your access point. This is called Registration and is the same procedure you know from DECT Handsets. This manual will help you.
  • Page 3 8-10 in case PIN of your DECT Base is not „0000“ Hints for PABX and Multicell Systems: DA1280 has a unique DECT-ID called IPEI. This IPEI you can see on the product label on your DA1280. It has is a 10-digit Hexadecimal form (HEX). Some DECT Systems (e.g. PABX) request this PIN in decimal form (DEC) The conversion HEX (e.g.
  • Page 4 Connect your analogue terminal with RJ11 cable to DA1280. In Germany in most cases a standard TAE adapter is necessary. You can immediately use your analogue terminal with DA1280 ex-works-setup. See pages 8-10 if you need to adjust the ex works configuration.

  • Page 5: Operation

    Hook-off analogue terminal. LED3 shows active and dialing tone will be announced. Analogue terminal dials calling number. After 4 seconds wait, DA1280 will setup the call with this resulting number sequence. DA1280 is in transparent connection (ex-works-setup). Outgoing Call (auto dialing) DA1280 can hold a special telephone number for auto-dialing after hook-off.
  • Page 6 Operation Hints In case Internal Calls are enabled, you can call internal DECT handsets with following sequence: **{Handset INT number}# possible {Handset INT number} are 1,2,3,5,6,7,8,9 Please notice that „Internal Call enabled“ and „transparent Mode on“ cannot be activated simultaneously. If „transparent Mode ON“...
  • Page 7 300ms Auto dialling restore ex-works-setup Press side key for 5 seconds to activate the RESET of DA1280. RESET function will restore the ex-works setup. All previous DECT registration will be deleted and all Settings will be reset to ex-works parameters.
  • Page 8 Method 1: connect a corded analogue phone to DA1280 and use its keypad for entering Configuration Codes. Follow the instructions below Activate Configuration Mode 1. disconnect DA1280 from wall plug (power OFF) 2. hook-off the phone which is connected to DA1280 3.
  • Page 9 Configurations Codes **800*1# End of configuration **801*{PIN}# Registration to Base station with {PIN} **802*1# Fax/Modem Mode ON e **802*0# Fax/Modem Mode OFF **803*1# Internal calls enabled **803*0# Internal calls disabled **804*1# End Symbol ON **804*0# End-Symbol OFF **805*1# transparent Mode ON **805*0# transparent Mode OFF **806*{0..2}#...
  • Page 10 Method 2: Connect DA1280 via USB with your PC. A special DA1280 APP (download from Internet) will offer you a comfortable MMI for all settings of DA1280. Adapt your setup to your requirements which will be automatically stored on DA1280 when closing the APP regularly 1.

  • Page 11: Software Upgrade

    (on/off) side key(Reset, special for multicall HS) USB connector (SW Upgrade) Software Upgrade Software Upgrades for DA1280 can be downloaded via USB connector and USB cable to PC. Please search your Supplier’s website to get information about such Software Upgrades.
  • Page 12 FAQ: Questions and Answers Please consult also the website of your dealer and/or manufacturer to get updated information and FAQs about DA1280. problem root cause remedy no line, no signalling, The analoge terminal is not properly Crosscheck cable and connectors...

  • Page 13: Security Advices

    Security Advices Make sure your DA1280 is not exposed to heat and interference from electrical devices e.g. motors and transformers. DA1280 shall be not be placed close to metallic walls. Place DA1280 in wall sockets only with LEDs on top.

  • Page 14: Warranty

    Warranty Your dealer warrants for 2 years for material and manufacturing quality of the product. Appointed date is the date of Buyer‘s receipt. The Buyer has the right for repair or replacement. Returned and replaced products will pass its property to the Seller. In case of defects Buyer has to immediately inform the Seller about such defects.
  • Page 15 Recycling Please contact your Dealer regarding Recycling of your product. In no case get disposed of your product via household garbage. Manual for DA1280 DECT analogue PLUG English Version 2.0 Edition 01 January 2017 Editor DOSCH&AMAND Products GmbH München -15-...

  • Page 16: Technical Support

    CE Conformity This product fulfills the requirements of EU rules 2004/108/EG (Richtlinie des Europäischen Parlaments und des Rates zur Angleichung der Rechtsvorschriften der Mitgliedstaaten über die elektromagnetische Verträglichkeit und zur Aufhebung der Richtlinie 89/336/EWG), and 2006/95/EG (Richtlinie des Europäischen Parlaments und des Rates zur Angleichung der Rechtsvorschriften der Mitgliedstaaten betreffend elektrische Betriebsmittel zur Verwendung innerhalb bestimmter Spannungsgrenzen).
