Related Manuals for BREWISTA Cold Pro Nitro
Summary of Contents for BREWISTA Cold Pro Nitro
-
Page 1: Cover/Customer Service Information
Customer Service (North America): 1-888-538-8683 Local (Wyoming, USA): 307-222-6086 Email: help@mybrewista.com READ THIS MANUAL PRIOR TO FIRST USE AND SAVE FOR FUTURE REFERENCE 1-year Limited Warranty... -
Page 2: Important Safeguards
Operate dispenser within a temperature range of 42° - 95° F (6 - 35° C). • • To protect against risk of electrical shock, do not put body of the Cold Pro Nitro™ Machine in water or other liquid. •... -
Page 3: Additional Safeguards
ADDITIONAL SAFEGUARDS DO NOT OPERATE APPLIANCE IF THE LINE CORD SHOWS ANY DAMAGE OR IF APPLIANCE WORKS INTERMITTENTLY OR STOPS WORKING ENTIRELY. EXTENSION CORDS A short power-supply cord is to be provided to reduce the risk resulting from becoming entangled in or tripping over a longer cord. Longer detachable power- supply cords or extension cords are available and may be used if care is exercised in their use. -
Page 4: Table Of Contents
IMPORTANT SAFEGUARDS ADDITIONAL SAFEGUARDS Cold Pro Nitro™ Components Intended Usage Operation Instructions • Assemble your Cold Pro Nitro™ • Connect the Intake Line • Connect your Cold Brew Container • Dispensing your Nitro Cold Brew • Adjustable Settings ◦ Temperature ◦... -
Page 5: Cold Pro Nitro™ Components
Cold Pro Nitro™ Components Tap handle 11. Intake line (2.0 m) with coupler to Tap valve body connect to dispenser Jet-nozzle tap-outlet spout 12. Carry handle Machine casing 13. Air intake vent Temperature control 14. Gas control cap Drip tray 15. -
Page 6: Intended Usage
Intended Usage The Brewista® Cold Pro Nitro™ Dispenser is a ready-to-use dispenser to tap nitrogenized and cooled beverages in particular cold-brew coffee. Such systems are mainly used for professional customers in hotels, restaurants and bars. The nitrogen effect is created through filtered compressed air which contains 78% nitrogen. -
Page 7: Connect Your Cold Brew Container
Connect your Cold Brew Container • Note: Brewista recommends checking functionality of your system by using water. This will also help flush out any cleaning solution residue from the system as well. • Connect the intake line tubing (11) to your cold brew container. If your intake line is connected to a keg, be sure the system can draw air or is fed with inert gas when tapping starts and coffee is dispensed. -
Page 8: Flowrate
Pre-cool the coffee in the refrigerator before connecting container to the dispenser. • Use the Cold Pro Nitro™ dispenser in combination with a refrigerator, under counter refrigeration, or a cooling box. In this scenario, the coffee remains cool and does not warm up after connecting to the dispenser. -
Page 9: Product Shelf Life
Cleaning Instructions Brewista recommends Cafetto Cold Pro Cleaner for cleaning your Cold Pro Nitro™ System To clean your Cold Pro Nitro™ System: Flush dispenser with water and then with air (emptying the lines) before unscrewing and dismantling parts. -
Page 10: Maintenance
Changing the Air Filter • The air filter used with the Cold Pro Nitro™ System is a micro air-filter that filters particles up to 0.1 μm (microns) with an efficiency of 99.9998%. According to DIN EN 1822 this represents a U 15 filter class. -
Page 11: Troubleshooting
Troubleshooting your Cold Pro Nitro™ System Problem Cause Solution Not enough or too The gas needle valve is not set up Follow instructions in the much foam properly. “Changing the Gas Level” section on page 7. The needle valve has a default setup of 1 mm with a tolerance of +/- 0.25... - Page 12 Problem Cause Solution Flowrate is too The perforated disc (9 or 10), The 2 hole disc (10) provides a high or too low. which is mounted in the jet-noz- flowrate of 0.6 L/min. zle outlet-spout (3), determines The 5 hole disc (9) provides a the dispenser’s flowrate.
- Page 13 Problem Cause Solution The dispenser If the dispenser was used In such a situation, the dispenser does not dispense without a filter adapter (19)in the and the pump must be flushed coffee (Continued) intake line (11), coffee particles with tap water. can get into the pump and Screw off the tap jet-nozzle damage or block valve parts.
-
Page 14: 1-Year Limited Warranty Information
LIMITED WARRANTY 1-Year Limited Warranty from the date of original purchase. 1. This warranty extends only to the original consumer, purchaser, or gift recipient. Keep the original sales receipt, as proof of purchase is required to make a warranty claim. The product must be purchased at an authorized retailer for the warranty to be valid. -
Page 15: Warnings And Technical Data
WARNING: Never leave the unit unattended while appliance is running, especially if there are children nearby. WARNING: Do not immerse the unit in water or any other liquid. This may cause electric shock or damage the appliance. TECHNICAL DATA For countries with voltage For countries with voltage ranging from 110-127V ranging from 220-240V... - Page 16 1133 W. 27th Street, Cheyenne, WY 82001, USA | www.mybrewista.com Toll Free in North America: 888-538-8683 | Local: 307-222-6086...
