Summary of Contents for RCT Power Power Battery 5.7
- Page 1 MANUAL Power Battery 5.7 / 7.6 / 9.6 / 11.5...
- Page 2 RCT Power GmbH represents a violation of the applicable copyright laws and will be prosecuted. We reserve the right to make technical changes that improve the equipment or increase the safety standard, even without a separate announcement.
-
Page 3: Table Of Contents
Table of Contents ABOUT THIS DOCUMENT ........................1 Validity, purpose and scope of the document and legal provisions............1 Symbols- and note explanation ........................1 SAFETY INSTRUCTIONS .......................... 2 Personnel and qualifications ........................2 Safety precautions ............................3 General safety information .......................... 4 PRODUCT INTRODUCTION ........................ - Page 4 You have obtained an innovative, high-quality product with unique features and consistently high efficiency. RCT Power Battery has a modular design, is highly flexible and robust, thus the system is easy to use. Therefore it can be adapted to individual customer requirements. These devices will bring more profit from your PV system.
-
Page 5: About This Document
This document is valid for Power Battery 5.7, 7.6, 9.6 and 11.5. Power Battery 5.7, Power Battery 7.6, Power Battery 9.6 and Power Battery 11.5 will be referred to as “battery”, “battery system”, “accumulator”, ”stack”, “device” or “product” hereinafter unless specified otherwise. -
Page 6: Safety Instructions
2 Safety instructions Personnel and qualifications To prevent personal injury or material damage, the inverter and the battery must only be installed, wired, connected, commissioned, maintained and serviced by qualified personnel. Qualified personnel eligible to perform the tasks described in this document have following skills and knowledge: ... -
Page 7: Safety Precautions
Make sure other persons keep away from cables and inner battery parts. Use only accessories and spare parts approved by RCT Power GmbH. Never modify the battery or components of the Power Battery. Risk of death or serious injury due to electric arc! Installations, service and maintenance work may only be carried out by Qualified electrician. -
Page 8: General Safety Information
General safety information Symbol and Description Note Acid traces in the eyes or on the skin clean with lot of clear water. Then consult a doctor immediately! Wash contaminated clothing with plenty of water. Fire- extinguisher for abatement from initial fire. Warning! Metal parts of the batteries are always under voltage. -
Page 9: Product Introduction
The Power Battery is not designed for any other application or connection with other devices. Any use that differs from or goes beyond the intended usage is considered misuse. RCT Power GmbH shall not be liable for any damage resulting from misuse. Any misuse will cause the termination of the warranty, guarantee and general liability of the manufacturer. -
Page 10: Product Description
If you notice any damage to the packaging or the PowerBattery, please immediately inform the transport company. Check the content for completeness according to Fig. 3-2. Power Battery 5.7 – 11.5 = Power Battery Master + Power Battery Stack (3-6). 3-6x... - Page 11 Power Battery Master Unpack box and check the content for completeness according to Fig. 3-2.1. Inspect the Power Battery Master for visible damages. Contact your supplier, if the delivery is incomplete or damaged. Do not install, connect and operate the Power Battery Master, if any damage is detected. Fig.
- Page 12 Power Battery Stack Unpack box and check the content for completeness according to Fig. 3-2.2. Inspect the Power Battery Stack for visible damages. Contact your supplier, if the delivery is incomplete or damaged. Do not install, connect and operate the Power Battery Stack, if any damage is detected. Fig.
-
Page 13: Product Appearance
3.2.2 Product Appearance Front view Back view Item Description Power Battery Master Power Battery Stack (3-6 Units) Floor plate Wall bracket DC connection Protective conductor RJ45 – interface, communication Terminal resistor Leveling feet Reels... - Page 14 Power Battery Master Front view Back view Item Description Power Battery Master Output DC (-) for DC-battery connection to the Power Storage Batt (-) CAN – interface, communication to the Power Storage PE connection On / Off switch Intern DC connection (+) for the Power Battery Stack Output DC (+) for DC-battery connection to the Power Storage Batt (+) CAN –...
- Page 15 Power Battery Stack Front view Back view Item Description Power Battery Stack DC connection (-), for the Power Battery Stack or Power Battery Master Fuse cover RJ45 – interface, communication to the Power Battery Stack or Power Battery Master PE connection DC connection (+), for the Power Battery Stack or Power Battery Master RJ45 –...
-
Page 16: Name Plate And Warnings
3.2.3 Name plate and warnings Fig. 3-4 Name plate Item Description Serial Number Technical Data Symbols: This symbol indicates that the user manual must be read and understood before putting the unit into operation. Warning of electrical voltage. DC voltage present in cables and inner parts of Power Battery Master. - Page 17 Fig. 3-4 Name plate Item Description Serial Number Technical Data Symbols: This symbol indicates that the user manual must be read and understood before putting the unit into operation. Warning of electrical voltage. DC voltage present in cables and inner parts of Power Battery Stack.
-
Page 18: Mechanical Installation
4 Mechanical installation Place of installation Installation, service and maintenance work may only be carried out by qualified electrician. When moving the Power Battery the battery system can tilt. Use the wall bracket to secure the Power Battery. ... - Page 19 Place the battery in an upright position. Minimum clearance to allow sufficient cooling air convection. Do not place battery inside a closed cabinet. Make sure, that there is sufficient air convection around the battery. Overheating of the battery due to poor cooling will result in decreasing lifetime.
-
Page 20: Mounting
Mounting Mounting Procedure: First place, the ground plate to the place where the Power Battery to stand later. Keep a distance of 20cm away from the wall. The side marked by the arrow has to stand opposite the wall. Next, place a Power Battery Stack with the included mounting handle on the ground plate, so that the connections look towards the wall. - Page 21 Put another Power Battery Stack on the first one, so that they match with each other. Repeat this until all Power Battery Stacks are set To attach the wall bracket, remove the two screws on the top stack (preferred Torx T20). First take the wall bracket and attach it to the top Power Battery Stack.
-
Page 22: Electrical Connection
5 Electrical connection Wiring Power Battery In the following sections is described the wiring of the Power Battery: 5.1.1 Protective earth 5.1.2 Communication 5.1.3 DC wiring Before starting wiring, make sure that the Power Battery Master On / Off switch is set to off “0”. After the Power Battery has been built up, the cabling on the back of the housing can be started. -
Page 23: Communication Connection
Connect all other modules with a protective conductor in series from the lower protective earth connection on the housing. 5.1.2 Communication connection For the communication between the individual modules use the enclosed patch cables and terminating resistor. First, connect the terminating resistor to the bottom of the lowest module. -
Page 24: Dc Connection
5.1.3 DC connection All Power Battery Stacks are connected in series. Therefore Power Battery Master has to be connected to the first and the last Power Battery Stack. The Power Battery Stacks in between has to be connected to the next one. Connect the positive DC cable from the Power Battery Plug the negative DC cable from the lowest Power Master in the positive connector of the lowest Power... -
Page 25: Battery Connection To The Inverter
Battery connection to the inverter Risk of death or serious injury due to electric shock! Touching voltage conductors parts can result in death! Prepare all battery cables before connecting the Power Battery to the Power Storage. Cables may only be connected or disconnected in a voltage-free state. ... -
Page 26: Preparation For Wiring To The Inverter
Preparation for wiring to the inverter Risk of death or serious injury due to electric shock! Only by RCT Power GmbH specified and certificated battery systems are allowed to be connected here! Check cables for correct polarity. Cables may only be connected or disconnected in a voltage-free state. -
Page 27: Fix The Power Battery On The Wall
Install the electrical connection to the Power Battery Master but do not plug it to the inverter yet, before it is mechanically fixed! Plug the communication link into the Power Battery Connect the DC cable into the Power Battery Master. Master 5.2.3 Fix the Power Battery on the wall... -
Page 28: Maintenance
7 Maintenance Maintenance The Power Battery contains not any parts to be serviced. In case of faults, please contact the service of RCT Power GmbH. Incident announcement The Power Battery has a status signal. About the permanently integrated LED in the housing, displayed are the following states:... -
Page 29: Exclusion Of Liability
RCT Power GmbH. RCT Power GmbH shall assume no guarantee for damage caused by faulty or lost data, due to incorrect operation or the malfunction of the inverter, the software, additional devices or PCs. -
Page 30: Appendix
10 Appendix Installer Company Name Address E-Mail Phone Power Battery Power Battery Serial number Date of install Power Battery Master Power Battery Stack 1.9 Power Battery Stack 1.9 Power Battery Stack 1.9 Power Battery Stack 1.9 Power Battery Stack 1.9 Power Battery Stack 1.9... -
Page 31: Technical Data
11 Technical Data Power Battery 11.5 Order Number BPB057N1AE0 BPB076N1AE0 BPB096N1AE0 BPB115N1AE0 ELECTRICAL PARAMETERS Nominal capacity 5,7kWh 7,6kWh 9,6kWh 11,5kWh Usable capacity 4,6kWh 6,1kWh 7,7kWh 9,2kWh Cycle Life (at 80% remaining capacity) 5000 180 V … 260 V 240 V … 346 V 300 V …... - Page 32 RCT Power GmbH Line Eid Str. 1 78467 Konstanz, Deutschland Tel.: +49 (0)7531 996 77-0 Mail: info[at]rct-power.com Internet: www.rct-power.com 07/2017...
