HUSKY
FM
2 Channel FM Radio Control System
USER'S GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ken and is the answer not in the manual?

Questions and answers

Summary of Contents for Technicstar Ken

  • Page 1 HUSKY 2 Channel FM Radio Control System USER'S GUIDE...

  • Page 2: Table Of Contents

    Table of Contents Features Preparation Husky Adaptation for Left-hander System Mode Functions Antenna Installation Model Name Loading the Batteries Trim Rate Charging LCD Contrast Power switch Frequency Direct Servo Control Data Copy USB Connection Pit Mode Functions Standing Model Select Specification Setting Level Servo Reverse...
  • Page 3 Features Thank you for purchasing a Proton Control Systems product. Before operating your Husky transmitter and Ken receiver, please read this manual carefully. Then retain it for future reference. 1. Features No crystal needed to change frequencies The frequencies of most transmitters and receivers are adjusted by changing the crystals.

  • Page 4: Preparation Husky

    Preparation 2. Preparation - Husky, 2 Channel FM transmitter Adaptation for Left-hander Huskies are produced for right-handers. However the grip direction can be changed for left-handers. 1. Make sure that the Power switch in set to OFF. 2. Carefully remove the 4 screws from the bottom cover of the control panel. 3.

  • Page 5: Antenna Installation

    Preparation Antenna Installation The antenna included with your Husky is safely stored in a slot under the control panel. To remove the antenna, pull back the plastic retainer cap located at the front of your Husky transmitter, then slide the antenna out. Insert the base of the antenna into the antenna receptacle at the top of the control panel.

  • Page 6: Power Switch

    To operate, plug the radio connector end of the DSC cable into the DSC jack loca- ted behind the control panel of your Husky. The other male end of the DSC cable is inserted in the battery slot on your Ken receiver. USB Connection (using optional cable) Your Husky has a USB port located behind the control panel.

  • Page 7: Standing

    Preparation Standing The large control panel at the top of your Husky makes the unit somewhat top- heavy. We recommend your Husky stands as illustrated right. This allows better stability, grip direction and easy of pick-up. Specifications Number of Channels Modulation FM, PPM 190 X 185 X 118 mm (7.48"...

  • Page 8: Specification

    Frequency setting The Ken is a crystal-free receiver. It does not need crystals for changing frequen- cies. Each available frequency has been assigned a two-digit channel number, which you can locate at the back of this manual. There is a two-digit LED display on your Ken receiver with corresponding adjustment buttons.

  • Page 9: Safety

    Safety 2. Safety Transmitter and receiver - Do not operate two or more models on the same frequency at the same time. This will cause interference and loss of control of both models. AM, FM(PPM) and PCM are different methods of modulation. Nonetheless the same frequency cannot be used at the same point in time, regardless of the signal format.

  • Page 10: Battery

    Safety Battery - Ni-Cd batteries can be very dangerous when mishandled and cause chemical damage. - In the unlikely event that battery fluid leaks onto your skin, immediately wash the contaminated skin with soap and plenty of water. Contact your local health care provider.

  • Page 11: Data Setting

    Data Setting 3. Data Setting There are 3 setting modes (System Mode, Pit Mode and Circuit Mode) in your Husky setting program. Control Panel Function Buttons Trim Button Steering Wheel Normal Display When the power switch is set to ON or STANDBY the normal display appears as shown below.

  • Page 12: Function Map

    Data Setting Function Map Mode Function System Model name Trim rate LCD contrast Frequency Data copy Model select Setting level Servo reverse Sub trim Data reset Circuit Basic Standard Expert Response Response Response Dual rate Steering speed 2- Step steering speed Throttle speed 2- Step throttle speed Start...

  • Page 13: Direct Access Functions

    Digital Trim / Dual Rate / Stopwatch Direct Access Functions Direct set programming lets you program quickly using easily accessible buttons on the control panel. Make instant fine adjustments without moving through the main menu. Digital Trim The digital trim button is located on the left side of the control panel. Steering and Throttle trim adjustments can be made by pressing the trim button in one of the 4 available directions.

  • Page 14: System Mode Functions

    Model Name / Trim Rate System Mode Functions This mode contains programming features, model name, trim rate, LCD contrast, frequency, data copy and data reset. These basic settings manage the transmitter system regardless of the pit and circuit mode setting. The System Mode menu is ac- cessible as below.

  • Page 15: Lcd Contrast

    LCD Contrast / Frequency / Data Copy LCD Contrast This function allows an eight-step contrast adjustment of the LCD screen. 1. Press button until the cursor is at LCD contrast. 2. Press button to display LCD contrast screen. 3. Press button until the desired contrast is achieved.

  • Page 16: Pit Mode Functions

    Model Select / Setting Level Pit Mode Functions This mode contains programming for setup during model building, electronics installation and maintenance. Pit Mode programming features include model select, setting level, servo direction and sub trim. The Pit Mode menu is accessible as follows.

  • Page 17: Servo Reverse

    Servo Reverse / Sub Trim / Data Reset Servo Reverse This function allows you to change the direction a servo rotates, clockwise or coun- ter clockwise. NOTE When the trim position deviates from the center, the deviation will be on the opposite side when the servo is reversed.

  • Page 18: Circuit Mode Functions

    Circuit Mode Functions Circuit Mode contains the most commonly used programming features that you'll likely be changing on the circuit. Circuit Mode programming is laid out in 3 levels that are accessed in user's capability and the kind of race. The Circuit Mode menu is accessible as shown below.

  • Page 19: Response

    Response Response This function is used to change the sensitivity of the steering and throttle servos around the neutral position. It has no effect on the maximum servo travel. For the throttle servo, the function changes the sensitivity of the throttle servo in the throttle trigger forward side and brake side directions independently.

  • Page 20: 2-Step Steering Speed

    2-Step Steering Speed / Throttle Speed 2-Step Steering Speed This function is similar to Steering Speed, but it has speed change points. You ad- just the steering servo's speed independently away from center (turning), and back to center (return), as above. You can also select points in both turn and return, and the speed between each point can be independently selected.

  • Page 21: 2-Step Throttle Speed

    2-Step Throttle Speed / Start 2-Step Throttle Speed This function is similar with Throttle speed but it has speed change points. You ad- just the throttle servo's speed independently away from neutral (at acceleration), and back to neutral (at deceleration), as above. You can also select points in both acceleration and deceleration, and the speed between each point can be indepen- dently selected.

  • Page 22: 3-Step Abs

    3-Step A.B.S / A.B.S 3-Step A.B.S This function allows you to select 1 of 3 A.B.S settings based on circuit and race conditions. 1. Press button until the cursor is at 3-Step ABS. 2. Press button to display the 3-Step ABS screen. 3.

  • Page 23: Auto Steering Control

    Auto Steering Control Auto Steering Control This function allows two steering servo speeds, automatically adjusted at high- and low-speed range of throttle. When it is activated, "ASC" appears on the lower side of the Normal LCD display. If you want sensitive steering at corners and less sensitive steering on the straight- away, reduce the auto steering speed value at high-speed range and increase the value at low-speed range.

  • Page 24: Punch

    Punch Punch The Punch throttle feature is used to reduce or eliminate the dead throttle area that exists from neutral to the starting point of throttle and from neutral to the starting point of braking. This area is sometimes known as dead band. As more throttle trim (also known as static brake) is applied, more of the dead trigger area right off neutral exists.

  • Page 25: Limited Warranty

    Limited Warranty / Approval 4. Limited Warranty Proton Control Systems, Inc. guarantees your Husky and Ken to be free from de- fects in materials and workmanship for a period of 120 days from original date of purchase (verified by dated, itemized sales receipt). Warranty does not cover incor-...

  • Page 26: Frequency List

    Frequency List 6. Frequency List - 40MHz, Europe 50 40.665 51 40.675 52 40.685 53 40.695 54 40.715 55 40.725 56 40.735 57 40.765 58 40.775 59 40.785 81 40.815 82 40.825 83 40.835 84 40.865 85 40.875 86 40.885 87 40.915 88 40.925 89 40.935...
