- Page 1 User Manual AP-1001g-P 802.11g 54Mbps Wireless Access Point and Wireless Bridge...
-
Page 2: Fcc Compliance
FCC Compliance NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. - Page 3 End Product Labeling This transmitter module is authorized only for use in device where the antenna may be installed such that 20cm may be maintained between the antenna and users (for example: Notebook, Assist Point, Router and similar product). The final end product must be labeled in a visible area with the following: “Contains TX FCC ID: PXPAP1001G”.
-
Page 4: Table Of Contents
Contents INTRODUCTION......................1 ........................1 RODUCT ......................1 RODUCT EATURES IP N ....................2 ASIC ETWORKING LAN B ....................3 IRELESS ASICS GETTING STARTED ...................... 5 AP1001G CONFIGURATION ..................5 ..................... 5 ONFIGURATION ....................... 6 ASIC ONFIGURATION ......................6 DMINISTRATION ........................ -
Page 5: Introduction
Introduction The Product The product is based on the IEEE 802.11g standard, which is the latest 54Mbps Wireless LAN (WLAN) standard. This standard is five times faster than the widely deployed WiFi (802.11b) products that are found in homes, airport and public wireless hotspots. Because 802.11g uses the same 2.4GHz frequency band, the product is fully interoperable with existing WiFi cards and devices. -
Page 6: Basic Ip Networking
Basic IP Networking IP = Internet Protocol IP stands for Internet Protocol. In an IP network, every device has a unique IP Address (For example: 192.168.1.35) to identify itself. There are two ways of assigning an IP address to a PC or Router: Static and Automatic (DHCP). -
Page 7: Wireless Lan Basics
Wireless LAN Basics A Wireless LAN (WLAN) is a computer network that transmits and receives data with radio signals instead of using cables. WLANs have become common in homes, offices, airports and public Hotspots. WLAN can support the same applications and software that run on a wired network (LAN). - Page 8 Make sure that the WLAN signals do not have to pass through too many concrete walls and metal structures to reach the client. Make sure that APs are located far away from one another to avoid interference. Interference Interference happens when 2 APs with the same channels are placed near to one another. The speed of the network drops and the signal strength fluctuates wildly.
-
Page 9: Getting Started
GETTING STARTED AP1001G CONFIGURATION Web Configuration AP1001g can be configure using a web server. 1. Connect the network as shown previously. If you are accessing the web server via Ethernet cable, check that the upper LED lights up on AP1001g. If your PC is wireless, check the PC’s card utility to make sure that the signal strength is good and that the bottom LED lights up on AP1001g. -
Page 10: Basic Configuration
Basic Configuration Administration This page allows you to change the Username and Password for admin user. The default username and password is admin / admin. After every factory reset, the Username and Password reverts to this combination. Device name allows you to give APRT-2001g2 a name. Device Name: admin User Name:... -
Page 11: Ip Configuration
IP Configuration This page allows you to choose the type of IP Static IP mode DHCP mode IP Address: Subnet Mask: Default Gateway Address: Domain Name Server IP Address: Static IP mode: When you boot up the AP1001g for the first time, it is in Static mode. You assign a Static IP to AP1001g. -
Page 12: Operation Mode
Operation Mode Operation Mode: Access Point Bridge RfNetech SSID: Suppress SSID: 2.4GHz 54Mbps (802.11g) Wireless Mode: SmartSelect Radio Frequency: Bridge Mode Settings: Remote AP MAC List: 00:00:00:00 Enable 11b AP Support: Remote AP MAC 1: 00:00:00:00 Remote AP MAC 2: Notes: Set only when remote 00:00:00:00... -
Page 13: Advance Configuration
Advance Configuration Radio Setting Data Rate: best Transmit Power: Half ( 50%) Beacon Interval (20 - 1000): Data Beacon Rate (DTIM) (1 - 255): Fragment Length (256 - 2346): 2346 RTS/CTS Threshold (256 - 2346): 2346 Short Preamble: Disable Enable Allow 2.4GHz 54Mbps Stations Only: Disable Enable... -
Page 14: Wpa Security
Protection Type: Select either CTS only or RTS-CTS Short Slot Time: Enable or disable short time slot usage WPA Security This section allows you to configure wireless encryption to prevent unwelcome parties from reading your traffic. Authentication can also be configured to block outsiders from accessing your network. -
Page 15: Security Server Settings
Security Server Settings RADIUS Server: RADIUS Port: 1812 RADIUS Secret: 2.4GHz Key Source: Local Remote RADIUS Server: Enter the IP Address of the RADIUS Server (for 802.1x authentication purposes). This is used only when you have a RADIUS Server and want to use it for authenticating the Wireless Clients. - Page 16 Enable Non-WPA Security: Tick the box to enable the following suite of Encryption and Authentication features. Enabling non-WPA security will disable WPA security. Open System: No encryption and authentication features in this mode. When the AP1001g is in this mode, any Client can associate with it. This is the default setting for the non-WPA Security setting.
-
Page 17: Protocol
Remember that after every configuration change, it is necessary to: Click Update on the page. Reboot AP1001g. The changes take effect only AFTER Reboot. Protocol Filter AppleTalk Packet: Filter IPX Packet: Wireless Isolation: Filter AppleTalk Packet: Selecting this option will disallow all AppleTalk packets to pass through Filter IPX Packet: Selecting this option will disallow all IPX packets to pass through Wireless Isolation: Selecting this option will disallow wireless clients associated with this device to communicate with each other... - Page 18 Restore settings from the backup: Allows you to retrieve the “Good Config” that you have saved previously. Remember that after every configuration change, it is necessary to: Click Update on the page. Reboot AP1001g. The changes take effect only AFTER Reboot.
-
Page 19: Status
Status System Status This page presents a convenient overview of the overall status of the AP1001g. The most common configuration parameters are shown here, for a quick look. DHCP mode IP Mode: IP Address: 192.168.1.20 255.255.252.0 Subnet Mask: Gateway Address: 0.0.0.0 SSID: RfNetech... -
Page 20: Super User
Super User Super User This page allows you to change the Username and Password for admin user. The default username and password is admin / admin. After every factory reset, the Username and Password reverts to this combination. AP1001g does not allow you to set the same Username for both admin and super users. -
Page 21: Firmware Version
Remember that after every configuration change, it is necessary to: Click Update on the page. Reboot AP1001g. The changes take effect only AFTER Reboot. Firmware Version This page presents information of the firmware version of AP1001g. Factory Reset In case you forget the password or IP address of the wireless bridge and is unable to configure the wireless bridge, you can restore it back to factory setting by doing a factory reset.
