Power Blower
Operator's Manual
MODEL
PB-411
WARNING
DANGER
X750-002 11 0
X750109-250 0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PB-411 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Echo PB-411

  • Page 1 Power Blower Operator's Manual MODEL PB-411 WARNING DANGER X750-002 11 0 X750109-250 0...
  • Page 2 INTRODUCTION WARNING DANGER THE OPERATOR S MANUAL TABLE OF CONTENTS...
  • Page 3 OWER LOWER PERATOR ANUAL MANUAL SAFETY SYMBOLS AND IMPORTANT INFORMATION WARN- DANGER IMPORTANT NOTE SAFETY DECALS HOT DECAL -WARNING- - ADVERTENCIA -DANGER- - PELIGRO Lea y obedezca todas las precauciones de seguridad que Read and follow all safety aparecen en el Manual del precautions in the operator's Operador.
  • Page 4: International Symbols

    INTERNATIONAL SYMBOLS Symbol Symbol Symbol Symbol Symbol form/shape Symbol form/shape Symbol form/shape Symbol form/shape description/application description/application description/application description/application Ignition Read and understand Fuel and oil mixture Engine choke ON/OFF Operator's Manual. control. Finger Severing Wear eyes, ears and Emergency stop head protection Primer bulb Wear hand...
  • Page 5: Personal Condition And Safety Equipment

    OWER LOWER PERATOR ANUAL FUEL WARNING DANGER VERY IMPORTANT After Refueling; After use; DO NOT 3 m (10 ft.) MINIMUM PERSONAL CONDITION AND SAFETY EQUIPMENT WARNING DANGER Physical Condition --...
  • Page 6 Eye Protection -- Hand Protection -- Breathing Protection -- Hearing Protection -- Proper Clothing -- Hot Humid Weather --...
  • Page 7: Safe Operation

    OWER LOWER PERATOR ANUAL SAFE OPERATION Determine Operation Area -- Use Proper Clothing & Equipment 15 m (50 ft.) Keep A Solid Stance Noise Control Avoid Hot Surfaces...
  • Page 8: Extended Operation

    EXTENDED OPERATION EXTREME CONDITIONS Vibration and Cold -- Repetitive Stress Injuries --...
  • Page 9: Emission Control

    OWER LOWER PERATOR ANUAL AIR INDEX TAG DESCRIPTION The Air Index Tag indicates, for purposes of consumer awareness, how this product's EMISSION CONTROL emissions compare to other products under the standards enacted by the California Air California Tier 2 Resources Board. An Emission Control Label PRODUCT EMISSION DURABILITY The 300 hour emission durability period is the time span selected by the manufacturer certifying the engine...
  • Page 10 AIR CLEANER - SPARK PLUG - MUFFLER/SPARK ARRESTOR - RECOIL STARTER HANDLE - CHOKE LEVER - FUEL TANK CAP - THROTTLE LEVER - STOP SWITCH - SHOULDER HARNESS - BLOWER PIPES - FLEXIBLE PIPE -...
  • Page 11: Specifications

    Spark Arrestor Muffler w / Catalyst Fuel Mixed (Gasoline and Two-stroke Oil) Fuel/Oil Ratio 50:1 ECHO High Performance, two-stroke air cooled engine oil Gasoline 89 Octane unleaded. DO NOT use fuel containing methyl alcohol. Gasoline may contain 15% MTBE (methyl tertiary-butyl ether).
  • Page 12: Install Blower Pipes

    ASSEMBLY WARNING DANGER INSTALL BLOWER PIPES INSTALL STICK HANDLE...
  • Page 13: Pre-Operation

    OWER LOWER PERATOR ANUAL PRE-OPERATION FUEL Fuel Requirements Gasoline - Two Stroke Oil - Mixing - IMPORTANT Handling Fuel WARNING DANGER VERY IMPORTANT...
  • Page 14 After Refueling - After use - Storage - 3 m (10 ft.) MINIMUM IMPORTANT T W T 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31...
  • Page 15: Operation

    OWER LOWER PERATOR ANUAL OPERATION STARTING COLD ENGINE NOTE STARTING WARM ENGINE NOTE STOPPING ENGINE WARNING DANGER...
  • Page 16: Operating Blower

    OPERATING BLOWER WARNING DANGER IMPORTANT NOTE...
  • Page 17: Skill Level

    ECHO Service Dealer for maintenance. To help you decide whether you want to DO-IT-YOURSELF or have the ECHO Dealer do it, each maintenance task has been graded. If task is not listed, see your ECHO Dealer for repairs.
  • Page 18: Air Filter

    AIR FILTER Level 1. NOTE FUEL FILTER Level 1. WARNING DANGER VERY...
  • Page 19: Spark Plug

    OWER LOWER PERATOR ANUAL WARNING DANGER SPARK PLUG Level 2. 0.65 mm (0.026 in.) COOLING SYSTEMS Level 2. IMPORTANT INTAKE GRILL Cleaning Grill...
  • Page 20: Exhaust System

    Cleaning Cylinder Fins EXHAUST SYSTEM Spark Arrestor Screen Level 2. IMPORTANT NOTE Cylinder Exhaust Port Level 3. IMPORTANT...
  • Page 21: Carburetor Adjustment

    OWER LOWER PERATOR ANUAL CARBURETOR ADJUSTMENT Engine Break-In High Altitude Adjustment Level 2. NOTE...
  • Page 22: Troubleshooting

    No fuel at Fuel strainer clogged Clean Cranks carburetor carburetor Fuel line clogged Clean Carburetor See your ECHO dealer Fuel at No fuel at Carburetor See your ECHO dealer cylinder cylinder Muffler wet Fuel Mixture is too rich Open choke...
  • Page 23 OWER LOWER PERATOR ANUAL STORAGE WARNING DANGER Long Term Storage (Over 30 Days) WARNING DANGER Drain completely...
