GENERAL DESCRIPTION
The NAPCO Freedom Deadbolt-Activated
Home Protection System, a revolutionary new con-
cept in residential security, combines intuitive inter-
active arming with a passive disarming scheme,
providing a system which is not only effortless to
use, but also virtually false alarm resistant during
the arming and disarming sequences.
In addition to the primary F-
TP Touchpad, the F-TPBR Touch-
pad provides a convenient second
keypad through which the system
can be armed and disarmed. The
F-TPBR Touchpad is designed to
be located at a distance from the
primary Exit/Entry area, such as a
bedroom, and allows arming with
exterior AND interior protection on
while staying home.
The F-TPBR Touchpad al-
lows "Night Arming", which pro-
tects all areas of the premises
(perimeter and interior) but deacti-
vates the F-TPBR Touchpad PIR
motion sensor. Night Arming al-
lows increased protection while
maintaining the false alarm reduc-
tion benefits of the Freedom sys-
tem.
The system is armed with a
simple push of a button ([STAY] or
[NIGHT]) on the F-TPBR Touchpad control module.
To disarm, simply Press the Disarm/Silence button.
The F-TPBR Touchpad's integral wide-angle
PIR motion sensor acts as an occupancy sensor
that provides the microprocessor with activity infor-
mation which prevents the user from making errors
during the arming and disarming periods. In addi-
tion, the F-TPBR Touchpad PIR will provide interior
This manual contains the Installation Instructions for the Freedom F-TPBR Touchpad. It is intended to be used in
conjunction with the Freedom F-8 Panel Installation Instructions (WI1431) and the Freedom F-8 Panel Program-
ming Instructions (WI1432).
NAPCO FREEDOM
F-TPBR TOUCHPAD
INSTALLATION INSTRUCTIONS
intrusion protection when the system is armed in
the AWAY mode.
alarm, the system may only be disarmed and si-
lenced by inserting the F-IFOB digital key into the
F-IFOB slot on the F-TPBR Touchpad or F-TP
Touchpad.
traditional numeric keypad interaction, the Freedom
POWER
keypad bus of the F-8 Panel.
Touchpad draws 55mA and an additional 20mA in
alarm.
standby and alarm current, as described in the wir-
ing diagram.
During an entry delay or an
By allowing this level of system control without
System will provide a significant
reduction in false alarms due to
user error and also provide com-
fortable use of the system to
t h o s e
technophobic tendencies would
prevent them from arming and
disarming the system using a tra-
ditional keypad.
The
Freedom
prevents the arming of the alarm
system if all deadbolts are not
engaged, a high security feature
normally
elaborate high-end installations.
INSTALLATION
The F-TPBR Touchpad need only
be mounted and wired to the ex-
isting Freedom system.
Freedom system can only support
two F-TP Touchpads or one F-TP
Touchpad
Touchpad.
The F-TPBR Touchpad is powered by the
Deduct these values from the system
WI1450 10/05
c u s t o m e r s
w h o s e
System
also
found
only
in
very
The
and
one
F-TPBR
Each F-TPBR
1
