Unitech RP901BTF Quick Manual

Mobile uhf reader
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
Mobile UHF Reader
Quick Guide
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS.
Mobile UHF Reader Quick Guide (Rev1)
P/N: 8012-0064000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RP901BTF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Unitech RP901BTF

Summary of Contents for Unitech RP901BTF

  • Page 1 Mobile UHF Reader Quick Guide CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS. Mobile UHF Reader Quick Guide (Rev1) P/N: 8012-0064000...
  • Page 2 Federal Communications Commission (FCC) Statement WARNING AND CAUTION 15.21 1. Take any metals into contact with the terminals in connectors. You are cautioned that changes or modifications not expressly approved by the 2. Use the scanner where any inflammable gases. partresponsible for compliance could void the user’s authority to operate the equipment.

  • Page 3: Specifications

    OUT OF THE BOX INTRODUCTION Trigger Button Function Button LED Indicator Micro USB port Mobile UHF Reader Quick Guide SPECIFICATIONS Frequency 915 MHz (US)/ 868 MHz (EU) Standard EPC Gen2/ ISO 18000-6C Read Range Up to 100CM (3.3ft.) Memory Housing PC + ABS Weight 103.5g (w/ battery)

  • Page 4: Reading Rfid Tags

    READING RFID TAGS BEEPER INDICATION Below figures show the optimal orientation of reader and RFID Single long beep Power up Single beep Good read Tag for reading. Two beeps i. Wireless connection RFID Tag ii. The reader successfully enters or exits configuration mode 90˚...
  • Page 5 SHUT DOWN POWER UP Press the Trigger Button for 2 seconds. The unit will emit one (1) METHOD 1: long beep and light the LED red as confirmation that the reader By default, the unit shuts down automatically after 5 minutes of has successfully powered up.

  • Page 6: Getting Connected

    GETTING CONNECTED Connecting to a PC/ Notebook Connecting to an Apple iOS Device 1. Press and hold the Trigger Button for 2 seconds to power up the 1. Press and hold the Trigger Button for 2 seconds to power up the unit, after which the blue indicator LED will flash continuously.

  • Page 7: Connecting To An Android Device

    GETTING CONNECTED Connecting to an Android Device 1. Press and hold the Trigger Button for 2 seconds to power up the 6. If a virtual keyboard is required, please do the following: unit, after which the blue indicator LED will flash continuously. (1) Enter “Settings”...
  • Page 8 DEFAULT RFID SETTINGS RFID UTILITY Operation Mode = Trigger Mode RFID Utility enables you to configure the reader with your PC/Laptop via USB connection. For more information on RFID Utility Read Tag Mode = Single Tag , please contact your local distributor. Tag Info = EPC Code Tag List Counter...
