OWNER’S MANUAL LED LCD TV / LCD TV PLASMA TV Please read this manual carefully before operating your set and retain it for future reference. www.lg.com...
Do not attempt to modify this product in to the point of the cable entry as practical. any way without written authorization from LG Electronics. Unauthorized modifi cation could void the user’s authority to operate this product.
SAFETY INSTRUCTIONS Important Safety Instructions Read these instructions. Protect the power cord from being walked on or pinched particularly at Keep these instructions. plugs, convenience receptacles, and Heed all warnings. the point where they exit from the apparatus. Follow all instructions. Do not use this apparatus near water.
Page 4
SAFETY INSTRUCTIONS Never touch this apparatus or antenna WARNING - To reduce the risk of fi re during a thunder or lighting storm. or electrical shock, do not expose this product to rain, moisture or other liquids. Do not touch the TV with wet When mounting a TV on the wall, make hands.
Page 5
ANTENNAS Ventilation Outdoor antenna grounding Install your TV where there is proper ventilation. Do not install in a confi ned If an outdoor antenna is installed, follow space such as a bookcase. Do not the precautions below. An outdoor cover the product with cloth or other antenna system should not be located materials (e.g.) plastic while plugged in the vicinity of overhead power lines...
When you click, display the PDF fi le. NOTE If the web page does not appear automatically, open the Owner’s Manual fi le directly. Open the “My computer” Open the “LG” Open the “index.htm” fi le.
PREPARATION Accessories Ensure that the following accessories are included with your TV. If an accessory is missing, please contact the dealer where you purchased the TV. The accessories included may differ from the images below. 1.5V 1.5V Owner’s Manual CD Manual Remote Control, Batteries (AAA) Polishing Cloth Power cable...
Stand Instructions Image shown may differ from your TV. INSTALLATION DETACHMENT Carefully place the TV screen side Carefully place the TV screen side down on a cushioned surface to down on a cushioned surface to protect the screen from damage. protect the screen from damage.
Desktop Pedestal Installation Image shown may differ from your TV. For proper ventilation, allow a clearance of 10.1 cm (4 inches) on all four sides from the wall. 10.1 cm (4 inches) 10.1 cm 10.1 cm (4 inches) 10.1 cm (4 inches) (4 inches) CAUTION Ensure adequate ventilation by following the clearance recommendations.
EXTERNAL EQUIPMENT SETUP Connecting Your TV To connect an additional equipment, see the External Equipment Setup section in CD Manual. * Typical Layout Connection Order HDMI is the best way to connect a device. If it’s not available, move down the list in ANTENNA/ order until you fi...
WATCHING TV 2. Time Setting Turning on the TV First, connect power cord correctly. Step2. Time Setting Current Time Setting At this moment, the TV switches Auto to standby mode. Year ---- In standby mode to turn TV on, Month press the POWER button.
On-Screen Menus Selection Your TV’s OSD (On Screen Display) may differ slightly from that shown in this manual. CHANNEL OPTION Auto Tuning: All available TV channels Language: Set the on-screen menus are searched and stored automatically. and audio languages. Manual Tuning: User can do manual Input Label: Set the label for each channel selection and add or delete input source.
APPENDIX Troubleshooting Abnormal Operation The remote control Check to see if there is any object between the product doesn’t work and the remote control causing obstruction. Ensure you are pointing the remote control directly at the TV. Ensure that the batteries are installed with correct polarity (+ to +, - to -).
Page 14
Video Problems Lines or streaks in Check antenna (Change the direction of the antenna). pictures No picture when If an HDMI cable doesn’t support High Speed HDMI, it can connecting HDMI cause fl ickers or no screen display. In this case use the latest cables that support High Speed HDMI.
Maintenance Early malfunctions can be prevented. Careful and regular cleaning can extend the amount of time you can enjoy your new TV. Caution: Be sure to turn the power off and unplug the power cord before you begin any cleaning. Cleaning the Screen Here’s a great way to keep the dust off your screen for a while.
MPL LIBRARIES: Nanox, spidermonkey LG Electronics offers to provide source code to you on CD-ROM for a charge covering the cost of performing such distribution, such as the cost of media, shipping and handling upon e-mail request to LG Electronics : opensource@lge.com...
Product Specifi cations Models 32LD400 42LD400 47LD500 Resolution 1920 x 1080 Brightness (cd/m Contrast Ratio 1400:1 1450:1 1450:1 1.06B colors @ 10 bit Number of Colors 8 bit, 16.7M 8 bit, 16.7M Color Depth (D) Actual Diagonal 31.55 42.02 46.96...
Page 19
Register your product Online! www.lg.com The extended owner’s manuals that contain informa- (For 42/47/55LE5400, 42/47/55LE5500, 42/47/55LE7500, tion on the advanced features of this LG TV are 47/55LE8500, 42/47/55LX6500) located on the CD-ROM provided in an electronic version. “factory default (Home Use)” setting.
