- Page 1 Mobileye C2-Series Mobileye C2-270 Mobileye C2-200 Quick Reference Guide Our Vision. Your Safety.™...
- Page 2 You are now helping to turn our environment into a safer one for drivers, passengers and pedestrians. Mobileye’s Quick Reference Guide will take you step by step through the functionalities of Mobileye C2-270/C2-200 in the best and most useful way.
-
Page 3: Important Safety Information
Mobileye C2-270/C2-200 is not an automated driving system and it does not act as a substitute for any aspect of driver vehicle control or safe driving practices. Drivers are strongly cautioned not to rely on Mobileye C2-270/C2-200 as a substitution, to even the slightest degree, for the exercise of due caution in assuring that they are driving safely and avoiding accidents. -
Page 4: Alert Types
Refrain from touching the Camera Unit during or immediately after operation. Alert Types Mobileye C2-270 is an Advanced Driver Assistance System that supplies the following alerts: Forward Collision Warning (FCW) (including motorcycle detection) l Warns of an imminent collision with the vehicle ahead of you. - Page 5 Mobileye Forward Collision Warning (FCW) HOW DOeS MOBILeYe FCW WOrk? Mobileye FCW alerts you up to 2.7 seconds before a possible collision with the vehicle ahead of you. WHeN IS MOBILeYe FCW OPerATIONAL? Mobileye FCW is always operational when the system is turned on.
- Page 6 Mobileye Headway Monitoring and Warning (HMW) HOW DOeS MOBILeYe HMW WOrk? Mobileye HMW displays your headway in relation to the vehicle in front of you. If you get closer than a set distance (calculated in seconds), it alerts you to the danger. MOBILeYe HMW AUDIO ALerT A single chime when headway is equal to or lower then the predefined headway.
- Page 7 WHeN IS MOBILeYe IHC FUNCTIONAL? IHC active Mobileye IHC is active at night, on dark roads (with no street lights), without nearby traffic. Mobileye IHC is active at speeds greater than 35 km/h (21 mph). Mobileye IHC is active only if enabled.
- Page 8 (bad weather, lane is detected ahead of you. Colored direct sunlight , dirt on windshield, etc). green or red according to safe or unsafe Mobileye C2-270 continues to work but headway. there may be degradation in detection 4. HeADWAY-DISTANCe MeTer ability.
-
Page 9: Control Panel
2. To enable Mobileye LDW alerts, make sure the Mobileye LDW sensitivity level is set to either level 1 or 2. Changing Mobileye PCW Sensitivity: a. Press the ( ) 4 times. b. Press the (-) to decrease the Mobileye PCW sensitivity, or press (+) to increase it. Activating and de-activating Mobileye IHC: a. Press ( ) 5 times. -
Page 10: Volume Control
Press the (–) button repeatedly to decrease volume; press the (+) button repeatedly to increase volume. There are 6 volume levels (0–5). Note: When the volume is set to zero, the Mobileye LDW and Mobileye HMW sounds are disabled, but Mobileye FCW sound volume will default to level “3”. - Page 11 Mobileye Forward Collision Warning (FCW) HOW DOeS MOBILeYe FCW WOrk? Mobileye FCW alerts you up to 2.7 seconds before a possible collision with the vehicle ahead of you. WHeN IS MOBILeYe FCW OPerATIONAL? Mobileye FCW is always operational when the system is turned on.
- Page 12 NOTE: This feature is available only in certain geographical areas. Mobileye Lane Departure Warning (LDW) HOW DOeS MOBILeYe LDW WOrk? Mobileye LDW alerts you when you unintentionally begin to depart from your lane. If you signal when moving between lanes, an alert is not generated. WHeN IS MOBILeYe LDW FUNCTIONAL? Mobileye LDW is active at speeds greater than 55 km/h (34 mph).
-
Page 13: System Limitations
Mobileye Headway Monitoring and Warning (HMW) HOW DOeS MOBILeYe HMW WOrk? Mobileye HMW displays your headway in relation to the vehicle in front of you. If you get closer than a set distance (calculated in seconds), it alerts you to the danger. MOBILeYe HMW AUDIO ALerT A single chime when headway is equal to or lower then the predefined headway. -
Page 14: License And Warranties
Mobileye product is the proprietary of Mobileye. the purchaser is granted solely with a non-exclusive license to use the software as provided by Mobileye, and shall not: (a) modify, adapt, alter, translate, or create derivative works from any software residing in or provided by Mobileye...
