Page 3
Use a 7-pin DIN-DIN straight wired lead i.e. pin 1 - pin 1, pin 2 - pin 2, pin 3 - pin 3 etc. Connect from the output of the IF32 to the input of the power pack. Ensure that the +10V terminal inside the power pack is linked to the ENABLE terminal.
Page 4
This may damage the IF32. Connect the power supply voltage output from the slave pack to either pin 6 or pin 7 or both on the IF32 7-pin DIN sockets. Whilst it is only necessary to connect the power supply from one power pack to each half of the IF32, it is advisable to connect them all.
Page 5
IF32 User Guide If only half of the IF32 is being used, it is not necessary to connect a power supply to the other half. Only one power indicator will light in this case. Connect the 0-10V analogue outputs from the IF32 to the analogue inputs of the power pack.
Page 6
241 to 256 128, 64, 32, 16 Do not set all switches ON The DMX address for each half of te IF32 can be set independently. The 0 to 10 Volt analogue control signals corresponding to the DMX channels selected appear on the 7-pin DIN sockets.
Page 7
IF32 User Guide For a switching power pack: DMX data < 76 output definitely off DMX data > 180 output definitely on DMX data between 76 and 180: do not use - output may be on or off. DM X.
Page 9
IF32 User Guide Te c h n ic a l S p e c ific a t ion . Dimensions: 482 × 110 × 44mm Power requirements: +15V DC @ 100mA Minimum: +12V DC Maximum: +20V DC Input: DMX512 DMX Connectors: ¼”...
