Sonus Inc

Session Border Controller 5100

For use with AT&T's

IP Toll Free Service

(Using AVPN or MIS/PNT transport connections)

SBC 5100 Configuration Guide

(For MS Lync 2010 4.0.7577.0)

Table of Contents

Need help?

Do you have a question about the 5100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sonus 5100

Page 1 Sonus Inc Session Border Controller 5100 For use with AT&T’s IP Toll Free Service (Using AVPN or MIS/PNT transport connections) SBC 5100 Configuration Guide (For MS Lync 2010 4.0.7577.0)
Page 2 Copyright © 2012 Sonus Inc. All rights reserved. Sonus is a registered trademark of Sonus Inc. All other trademarks, service marks, registered trademarks or registered service marks may be the property of their...
Page 3: Table Of Contents
Introduction ......................4 Special Notes ..................... 4 Network Topology ..................5 Call Routing for Virtual Extension Testing ........... 6 SBC 5100 Hardware Configuration ............7 SBC 5100 Software Configuration ............8 SBC 5100 Configuration ..................9 Configure Interfaces ................. 9 Configuring Zone ..................
Page 4: Introduction
Controller) when connecting to AT&T IP Toll Free service using AVPN or MIS/PNT transport. The Sonus SBC 5100 is a Session Border Controller that connects disparate SIP trunks, SIP PBXs, and communication applications within an enterprise. It can also be used as a SIP routing and integration engine.
Page 5: Network Topology
1.1.3 Suppress 183 Session in progress from MS Lync globally. Sonus SBC 5100 will be used to suppress 183 Session in progress from MS Lync globally by using a SMM Rule. This SMM Rule is called IGNORE-183 in the configuration present in this document and shall be applied on the Output Adapter Profile of AT&T Trunk Group from...
Page 6: Call Routing For Virtual Extension Testing
MS Lync Side Configuration Response Groups +17890112 +17890114 +17890116 WORK FLOW QUEUE GROUPS Groups are Associated with Associated with Assigned as Hunt Groups Agents Groups or IVR © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 7: Sbc 5100 Hardware Configuration
Device not present (Unknown (0x81)) FRU Device Description : FRU DB1 (ID 5) Device not present (Unknown (0x81)) System Memory : 6121852 kB =============================== ====================================== © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 8: Sbc 5100 Software Configuration
=================================================== SERVER: NBS51K2 BMC: v2.0.0 BIOS: v2.0.0 01.08.01-R000 SonusDB: sonusdb-V03.00.01-R001 EMA: ema-V03.00.01-R001 SBC: sbc-V03.00.01-R001 =================================================== Installed host role: active Current host role: active =================================================== © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 9: Sbc 5100 Configuration
SBC 5100 Configuration Guide 2 SBC 5100 Configuration The SBC 5100 configuration is possible using the CLI as well as the EMA. This guide lists the configuration in 3 steps 1. The CLI Commands used for configuring the SBC 5100 2.
Page 10 SBC 5100 Configuration Guide admin@NBS51K2% show addressContext A1 ipInterfaceGroup LIF1 ipInterface pkt0_v4 { ceName NBS51K2; portName pkt0; ipAddress 172.16.103.162; prefix 24; mode inService; state enabled; GUI Configuration © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 12 "inService" state "enabled" commit admin@NBS51K2% show addressContext A1 ipInterfaceGroup LIF2 ipInterface pkt1_v4 { ceName NBS51K2; portName pkt1; ipAddress 119.226.79.126; prefix 24; mode inService; state enabled; GUI Configuration © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 13: Configuring Zone
2.2.1 Internal Zone (Towards MS Lync Mediation Server) 2.2.1.1 IP Peer CLI Configuration Commands set addressContext "A1" zone "INTERNAL" ipPeer "LYNCMED_IPP" ipAddress "172.16.103.73" ipPort "5068" commit © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 14 A1 zone INTERNAL ipPeer ipPeer LYNCMED_IPP { ipAddress 172.16.103.73; ipPort 5068; policy { description ""; sip { fqdn ""; fqdnPort 0; packetServiceProfile ""; ipSignalingProfile ""; GUI Configuration © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 15 "A1" zone "INTERNAL" sipSigPort "1" mode "inService" state "enabled" admin@NBS51K2% show addressContext A1 zone INTERNAL sipSigPort sipSigPort 1 { ipInterfaceGroupName LIF1; ipAddressV4 172.16.103.162; portNumber 5060; state enabled; transportProtocolsAllowed sip-udp,sip-tcp; GUI Configuration © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 16 "172.16.103.74" "32" set addressContext "A1" zone "INTERNAL" sipTrunkGroup "LYNCMED TG" policy media admin@NBS51K2% show addressContext A1 zone INTERNAL sipTrunkGroup sipTrunkGroup LYNCMED_TG { state enabled; © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 17 { transportPreference { preference1 tcp; rel100Support disabled; media { mediaIpInterfaceGroupName LIF1; earlyMedia { forkingBehaviour firstProvResponse; ingressIpPrefix 172.16.103.71 32; ingressIpPrefix 172.16.103.73 32; ingressIpPrefix 172.16.103.74 32; © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 18 SBC 5100 Configuration Guide [ok][2012-08-30 22:02:20] GUI Configuration Sip Trunk Group: Fig (1 of 11) © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 19 SBC 5100 Configuration Guide Sip Trunk Group: Fig (2 of 11) Sip Trunk Group: Fig (3 of 11) © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 28 A1 zone EXTERNAL ipPeer ipPeer ATT-IPTF_IPP { ipAddress 207.242.225.210; ipPort 5060; policy { description ""; sip { fqdn ""; fqdnPort 0; packetServiceProfile ""; ipSignalingProfile ""; GUI Configuration © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 29 "A1" zone "EXTERNAL" sipSigPort "2" mode "inService" state admin@IOTSBX2% show addressContext A1 zone EXTERNAL sipSigPort 2 ipInterfaceGroupName LIF2; ipAddressV4 119.226.79.126; portNumber 5060; mode inService; state enabled; dscpValue GUI Configuration © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 30 "A1" zone "EXTERNAL" sipTrunkGroup "ATT-IPTF_STG" policy signaling ipSignalingProfile "ATT-IPTF_IPSP" set profiles digitParameterHandling prefixProfile NA_DIAL_PLAN entry 00 0 0 10 numberLeadingPrefixDigits 0 numberLeadingPrefixDigitsToStrip 0 callType national digitType nationalType © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 31 ""; services { classOfService DEFAULT_IP; signaling { ipSignalingProfile ATT-IPTF_IPSP; signalingProfile ""; signaling { messageManipulation { outputAdapterProfile IGNORE-183; media { maxPtimeDefault mediaIpInterfaceGroupName LIF2; sourceAddressFiltering disabled; © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 32 SBC 5100 Configuration Guide ingressIpPrefix 207.242.225.210 32; [ok][2012-08-30 22:26:27] GUI Configuration Sip Trunk Group: Fig (1 of 10) © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 35 SBC 5100 Configuration Guide Sip Trunk Group: Fig (4 of 10) Sip Trunk Group: Fig (5 of 10) © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 42: Configure Static Routes
A1 staticRoute staticRoute .0 24 .1 LIF1 pkt0_v4 { 172.16.103 172.16.103 preference 100; } staticRoute 207.242.225.210 32 119.226.79.126 LIF2 pkt1_v4 { preference 100; } GUI Configuration © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 43: Configure Profiles
"ATT-G726" packetSize "30" law "ULaw" set profiles media codecEntry "ATT-G726" fax toneTreatment "faxRelay" set profiles media codecEntry "ATT-G726" dtmf relay "rfc2833" commit © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 44 { failureHandling continue; toneTreatment faxRelay; modem { failureHandling continue; toneTreatment none; dtmf { relay rfc2833; removeDigits enable; codecEntry ATT-G729 { codec g729ab; packetSize preferredRtpPayloadType 100; © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 45 SBC 5100 Configuration Guide fax { failureHandling continue; toneTreatment faxRelay; modem { failureHandling continue; toneTreatment none; dtmf { relay rfc2833; removeDigits enable; GUI Configuration ATT-G711U © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 49 { g711SidRtpPayloadType 13; heartbeat enable; aal1PayloadSize codec { codecEntry1 ATT-G729; codecEntry2 ATT-G711U; codecEntry3 ATT-G726; codecEntry4 ""; © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 50 1; maxBitRate 14.4Kbits_s; numberOfRedundantPackets secureRtpRtcp { cryptoSuiteProfile ""; flags { allowFallback disable; enableSrtp disable; preferredRtpPayloadTypeForDtmfRelay 100; videoCalls { maxVideoBandwith videoBandwidthReductionFactor 0; audioOnlyIfVideoIsPrevented enable; © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 51 SBC 5100 Configuration Guide mediaPacketCos honorRemotePrecedence disable; sendRoutePSPPrecedence disable; [ok] © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 52 SBC 5100 Configuration Guide GUI Configuration Packet Service Profile ( Fig. 1 of 4 ) Packet Service Profile ( Fig. 2 of 4 ) © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 55 "ATT-IPTF_IPSP" ingressIpAttributes flags sendSdpIn200OkIf18xReliable "enable" set profiles signaling ipSignalingProfile "ATT-IPTF_IPSP" ingressIpAttributes flags sendSdpInSubsequent18x "enable" set profiles signaling ipSignalingProfile “ATT-IPTF_IPSP” commonIpAttributes relayFlags statusCode4xx6xx © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 57 { alertInformationHeader disable; authcodeHeaders disable; contactHeader disable; errorInfo disable; fromHeader disable; historyInfo disable; maxForwardsHeader disable; © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 58 { bciInterworkEncountered disable; bciIsdnAddess disable; domainName { useSipDomainNameInFromField disable; useSipDomainNameInRequestUri disable; © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 59 { includeCic disable; includeCpcInformation disable; includeNpi disable; includeOlip disable; includePKAdn disable; includePstnParameters disable; includeQvalue disable; skipCSeqCheckInEarlyDialog disable; transparencyForDestinationTrunkGroupParameter disable; © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 60 { generateTerminatingCa disable; generateTerminatingCic disable; [ok] GUI Configuration Sip Signaling Profile: Fig (1 of 12) © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 66 SBC 5100 Configuration Guide Sip Signaling Profile: Fig (5 of 12) Sip Signaling Profile: Fig (6 of 12) © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 72 SBC 5100 Configuration Guide Sip Signaling Profile: Fig (11 of 12) Sip Signaling Profile: Fig (12 of 12) © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 73 "TCP_IPSP" ingressIpAttributes flags sendSdpInSubsequent18x "enable" set profiles signaling ipSignalingProfile “TCP_IPSP” commonIpAttributes relayFlags statusCode4xx6xx Above IPSP is for LYNCMED_TG which is the Trunk Group towards MS Lync. © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 74 1 { criterion 1 { type message; message { messageTypes response; methodTypes invite; statusCode 183; action 1 { type ignore; [ok][2012-09-02 23:45:52] GUI Configuration © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 77: Configure Global
ATT-IPTF_RL { overflowNumber ""; overflowNOA none; overflowNPI none; routePrioritizationType sequence; script ""; action routes; routingLabelRoute 1 { trunkGroup ATT-IPTF_STG; ipPeer ATT-IPTF_IPP; © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 78 ""; action routes; routingLabelRoute 1 { trunkGroup LYNCMED_TG; ipPeer LYNCMED_IPP; proportion 0; cost 1000000; inService inService; testing normal; GUI Configuration © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 80 CLI Configuration admin@NBS51K2% show global callRouting route route trunkGroup ATT-IPTF_STG NBS51K2 standard Sonus_NULL 1 all all ALL none Sonus_NULL { routingLabel LYNCMED_RL; } [ok] GUI Configuration © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 81: Ms Lync 2010 Configuration
SBC 5100 Configuration Guide 3 MS Lync 2010 Configuration The MS Lync configuration which is used along with the Sonus SBC 5100 is as per the details provided in the MS Lync Configuration information provided in Technet Site: http://technet.microsoft.com/en-us/library/gg398616 © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
Page 82: Troubleshooting
CCG, even if AT&T or its suppliers have been advised of the possibility of such damage. © 2012 Sonus Inc. Confidential and Proprietary. All Rights Reserved. Do not distribute without permission.
