- Page 1 HD/SD Digital Video Switcher DSC928. User’s Manual DSC928 HD/SD SDI Master Control Switcher User's Manual DVLab...
-
Page 2: Table Of Contents
LOGO 1, LOGO 2, CLOCK Transition Main Unit - Rear Panel MULTI-VIEW Multi-VIEW information: DSC928 Connections How to connect DSC928 to the PC through Ethernet (TCP / IP) The switcher’s IP address DSC928 Software DSCConfig.exe DSCRemote.exe Titling Program «TitleMaster» How to update the DSC928 Firmware... -
Page 3: Overview
HD/SD Digital Video Switcher DSC928. User’s Manual Overview The DVLab DSC928 is a cost effective HD/SD Master Control Switcher featuring six channels. It has been designed for live productions that may need to combine a number of video sources with a mixed audio feed. -
Page 4: Construction
HD/SD Digital Video Switcher DSC928. User’s Manual Construction Main Unit: RACK 2U 19`: The Front Panel The Rear Panel Remote Control Console: Multi-screen: You can use any HD TV set with HDMI input 1920х1080 pix. DVLab... -
Page 5: Inputs / Outputs
The mixer has 4 SDI and 2 HDMI Inputs, which may be the HD and SD - determined by the user settings. You can use SD Video Anamorphic format – DSC928 has accordingly settings 4:3 or 16:9 format for inputs and outputs SD signals. -
Page 6: Remote Control Console
HD/SD Digital Video Switcher DSC928. User’s Manual Remote control Console PC Control On /Off SHIFT Program to Multi-screen Source selection Preview OSD Menu Key Cut & AUTO Take Wipes Effects, MIX, FREEZE T-BAR end position LED indicators PiP 1, PiP 2, Titles T-Bar Logos &... -
Page 7: The Shift Key
BLACK button – Built -in BLACK Field signal generator PC Control button. Press the PC Control button for placed DSC928 into PC Control mode. All DSC928 software can working in this mode only. In this mode the Remote Control Console is blocked. -
Page 8: Transition Selection
HD/SD Digital Video Switcher DSC928. User’s Manual Press any arrows button and the Main Menu list is displayed on the HDMI 1 Multi-view output. Press the up, down, left, and right arrow buttons to navigate the menu options and to change values. -
Page 9: Pip And Titles
DSK Mode The DSC928 has two titling methods: Luma Key and Titles + a Channel selected in the OSD menu. Luma Key mode. You can use any video sources (HD/SD SDI, CVBS,HDMI, Still Pictures ) to replace the black parts of this image with the video from another source. -
Page 10: Logo 1, Logo 2, Clock
The Title Masters software Titles can be controlled by SHIFT/ Preset row keys:Play/pause, >>, << LOGO 1, LOGO 2, CLOCK The DSC928 has the ability to store seven static logos and one dynamic logo. The logo files are transferred to the DSC928 from a Windows PC using the Ethernet connection and the supplied DSCConfig software. -
Page 11: Transition
HD/SD Digital Video Switcher DSC928. User’s Manual Video Transition This performs a simple immediate switch from the current main source to the selected sub source. The selected transition wipe or dissolve is not used. AUTO TAKE This performs an automated switch from the current program source to the selected preset source. -
Page 12: Main Unit - Rear Panel
HD/SD Digital Video Switcher DSC928. User’s Manual Main Unit - Rear Panel Inputs 1-4 HD/SD-SDI;5,6-HDMI Analog Audio Inputs Outputs Analog Audio Outputs Multiscreen Remote Control Console (DB9F -DB9F) Ethernet (RG45)I TALLY (DB9M) Grounding Terminal DC In 12V, 50W 6 Additional Options... - Page 13 HD/SD Digital Video Switcher DSC928. User’s Manual HDMI MULTIVIEW OUT HDMI outputs (1920 х 1080i x 50 Hz) which can be used to display a preset combination of inputs plus program and preset. ETHERNET RG45 Connector for Upgrade, Logos, Configuration, Time setting and Remote Control.
- Page 14 HD/SD Digital Video Switcher DSC928. User’s Manual Grounding Terminal When connecting this unit to any other component, make sure that it is properly grounded by connecting this terminal to an appropriate point. When connecting, use the socket and be sure to use wire with a cross-sectional area of at least 1.0 mm.
-
Page 15: Multi-View
HD/SD Digital Video Switcher DSC928. User’s Manual MULTI-VIEW DSC928 Multi-view monitoring is available via one HDMI monitor (not supplied). The all of Video and Audio sources, including embedded audio is available to see on the Multi -view. The audio level indicator is presented for each of inputs, Preview and Program. -
Page 16: Multi-View Information
HD/SD Digital Video Switcher DSC928. User’s Manual Multi-View information: 1) Name of Channels. 2) Selected inputs (Program / Preset / PIP). 3) Transition Effects 4) Audio mix type (V or X). 5) Clock 6) Menu 7) Audio Level Indicators 8) LOCKED or UNLOCKED 9) PC CONTROL or CONSOLE CONTROL. -
Page 17: Dsc928 Connections
HD/SD Digital Video Switcher DSC928. User’s Manual DSC928 Connections Multi screen is connected by standard HDMI Cable PC is connected by LAN cable (UTP RG45) Direct PC connection by Crossover. Connection via HUB by Direct. DVLab... -
Page 18: How To Connect Dsc928 To The Pc Through Ethernet (Tcp / Ip)
HD/SD Digital Video Switcher DSC928. User’s Manual How to connect DSC928 to the PC through Ethernet (TCP / IP) Connecting to a PC is required in the following cases: Settings – the program "DSCConfig". Uploading logos and Still pictures – the program "DSCConfig". -
Page 19: The Switcher's Ip Address
So in the our example PC IP address is 192.168.31.31 but DSC928 IP address is 192.168.22.1 In this case the IP address of the DSC928 must be 192.168.31.XX, where XX - is not involved in any of the network number, for example 192.168.31.25. You can set it in the Network... -
Page 20: Dsc928 Software
1. Install the supplied SEConfig software on a Computer. 2. Double click the DSCConfig icon to launch the application: 1.Press PC Control button in the MENU area of the DSC928 keyboard 2. Select Ethernet to display the Computer’s IP Address. Click the Find button to find and display the SE-2800 Switcher’s IP Address in the drop down list. - Page 21 You can choose the method of connection between the computer and the switcher. In this case the DSC928 is connected using selected Ethernet IP addresses. Note that the first three numbers in the IP addresses of the switcher and computer should be the same.
- Page 22 Inputs one slide can store in the device memory. Logos tab The DSC928 can store up to seven still and 1 dynamic logos in its memory. Using logos tab you can use the “Load” button to browse for a logo stored on the computer. This logo is then loaded into the application window.
- Page 23 As the Logo can be any image format BMP, PNG, TGA size of 256x128 pixels, 24 bits. Dynamic Lables tab The DSC928 can store one dynamic moving logo in its memory. The dynamic logo can be a targa (TGA) sequence, GIF or AVI. It must be no longer than 75 frames/images long.
-
Page 24: Dscremote.exe
1. Connect an Ethernet cable between the PC and the DSC928. 2. Turn on the PC and DSC928. 3. Placed DSC928 into PC Control mode. To do this press the PC Control button on its Control Panel . 4. Launch the DSCRemote software on the PC. - Page 25 HD/SD Digital Video Switcher DSC928. User’s Manual The PC used must be in the same IP network as the DSC928. So the first three octets (numbers) in the PC’s IP Address must match the first three octets of the switcher’s IP address.
- Page 26 HD/SD Digital Video Switcher DSC928. User’s Manual «TitleMaster». This Software allows using the HDMI input of the DSC928 Switcher as a source of a-channel Titles. The system is designed for video and broadcast design and includes PC with installed Title Master software and switcher DSC928.
- Page 27 HD/SD Digital Video Switcher DSC928. User’s Manual TGA ( with alpha channel , if there is one) . PNG ( with alpha channel , if there is one) . JPG GIF ( with transparency , if there is one) .
- Page 28 HD/SD Digital Video Switcher DSC928. User’s Manual SD card Media Player The DSC924 pl switcher has Media Player as a built it function. The media files is stored to the SD Card Flash Memory inserted into the corresponding slot on the face panel of the main block.
-
Page 29: How To Update The Dsc928 Firmware
To update the DSC928 firmware: 1. Switch off the DSC928 and Computer in the normal way. 2. Connect the Ethernet cable between the DSC928 rear panel and the Computer. 3. Turn on the Windows 7 Computer. Double click the firmware update icon to launch the Flash Update Utility. - Page 30 HD/SD Digital Video Switcher DSC928. User’s Manual In the next window you can POWER ON the DSC928 and it will be discovered by the Computer. Select Automatically update the device to latest firmware version then click NEXT. Click the Yes button to confirm you wish to perform the firmware update.
-
Page 31: Specification
HD/SD Digital Video Switcher DSC928. User’s Manual Specification Inputs Video 9 inputs : 8 HD /SD SDI, 1HDMI Inputs Audio 4 Analog Audio Balanced, 4 x XLR 3 pin Outputs Video 1x HDMI for Multi-screen 4 BNC for HD/SD-SDI outputs... -
Page 32: Dimensions
HD/SD Digital Video Switcher DSC928. User’s Manual Dimensions DVLab... -
Page 33: Warranty
HD/SD Digital Video Switcher DSC928. User’s Manual Warranty Warranty period – 24 months from the selling date The manufacturer does not take any responsibility for defects occurred at the customer’s fault or trading company’s during careless transportation, improper storage, technical service or usage, mechanical damages, violating the operation rules. -
Page 34: Environment Requirement
HD/SD Digital Video Switcher DSC928. User’s Manual Apps Environment Requirement ℃ ℃ ， 0~45 (short time) ， Environment Temperature 5~40 (sustainable) installing air-conditioning is recommended Power Requiring device power, air-conditioning power and lighting power are independent to each other. Device power requires AC power 220V 50Hz. Please carefully check before running.
