MicroStrain V-Link Quick Start Manual

Wireless voltage node

Advertisement

Quick Start Guide
®
V-Link
Wireless Voltage Node
Firmware Version 5.00 and higher
Software Version 1.5.26 and higher
Issued: 5 April 2010
Document #: 8501-0004

Software Installation

• Place the Node Commander
screen instructions to install MicroStrain's Node Commander

Hardware Installation

• Install the antenna on the base station antenna connector. Tighten hand tight; do
not over tighten.
• If you have a serial base station
serial port on your PC and to the serial base station RS-232 connector. Connect
the external power supply to the power connector on the serial base station and
plug it into a proper power receptacle. Turn the serial base station power switch
on and the green LED will illuminate indicating the base station is powered
• If you have a USB base station, plug the USB connector into any USB port on
your PC. The blue LED will illuminate indicating the base station is powered.
• If you have an analog base station, connect the USB cable to any USB port on
your PC and to the analog base station USB connector on the back panel.
Connect the external power supply to the power connector on the back panel of
the analog base station and plug it into a proper power receptacle. Depress the red
power button on the front panel and the green LED will illuminate indicating the
base station is powered.
• Install the antenna on the V-Link
over tighten. Insure the V-Link
USB
®
CD in your CD-ROM drive and follow the on-
(see Figure
1), connect the RS-232 cable to a
®
antenna connector. Tighten hand tight; do not
®
is turned off (switch towards power connector).
Serial
Figure 1
®
software.
Analog
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V-Link and is the answer not in the manual?

Questions and answers

Summary of Contents for MicroStrain V-Link

  • Page 1 Depress the red power button on the front panel and the green LED will illuminate indicating the base station is powered. • Install the antenna on the V-Link ® antenna connector. Tighten hand tight; do not ®...
  • Page 2 • Right-click on the node and a pop-up menu will appear. • Click Configure. The Configuration window will appear. See Figure • Click the Channels tab. Check the box to enable V-Link ® ’s channel 1 (differential input channel). By default, channel 1’s physical units will be in bits and the hardware gain will be set to 210.
  • Page 3 Node ® Commander software manual to learn how to successfully put your wireless data acquisition system to work. Further Support MicroStrain Support Engineers are always available by phone, email or SKYPE to support you in any way we can. Figures...
  • Page 4 Figure 2 Figure 3 Figure 4...
  • Page 5 Figure 5 Figure 6 Figure 7...
  • Page 6 Figure 8 Figure 9 MicroStrain, Inc. 459 Hurricane Lane, Unit 102 ph: 800-449-3878 Williston, VT 05495 USA fax: 802-863-4093 Copyright © 2010 MicroStrain, Inc. www.microstrain.com support@microstrain.com...
